NetBackup 5200
Product Description
Name
Management
network port
Service
network port
(NIC 1)
Service
network port
(NIC 2)
8Gb FC port
Table 1-5
Table 1-8

1.5 Features

This section describes the features of the NetBackup 5200, such as energy saving, large capacity,
reliability, and manageability.
Table 1-10

Table 1-10 Features of the NetBackup 5200

Feature
Energy saving
Issue 02 (2011-03-28)
Quantity
1
1
1
6
lists the indicators of the rear view.
lists the indicators of the 8Gb FC HBA.
NOTE
When the NetBackup 5200 is configured with only one power module, the power module is installed in
position 18 in Figure 1-7
lists the features of the NetBackup 5200.
Description
l
l
l
Symantec Corporation
Model Function
RJ45 Device hardware is managed through this
Fast Ethernet (FE) port.
RJ45 NIC 1 is a management network port and its
IP address is 192.168.1.1/24. Through this IP
address, the user can log in to the OS for
configuration. NIC 1 is connected to the
management computer.
RJ45 Connects to the backup network.
SFP+
l
l
and position 19 in Figure 1-9.
Supports disk soft start after power-on, controlling the disk startup
current and reducing the overall power consumption of the device.
Supports high-efficiency power modules, reducing power
consumption.
Supports intelligent fan speed control, reducing the power
consumption of devices.
1 Product Introduction
Connects to a tape library.
Connects to the backup network.
1-15
