Figure 1-7
GTH IBERT demonstration.
X-Ref Target - Figure 1-7
QUAD_117
TX/RX Loopback Connections
Figure 1-7: Cable Connections for Quad 117 GTH IBERT Demonstration
Configuring the FPGA
This section describes how to configure the FPGA using the CF cards included with the
board. The FPGA can also be configured through ChipScope Pro or iMPACT software
using the .bit files which are available online (as collection rdf0116_13-1.zip) at:
To configure from the CF card:
1.
2.
3.
ML628 IBERT Getting Started Guide
UG806 (v1.0) May 20, 2011
shows the ML628 board with the cable connections required for the Quad 117
http://www.xilinx.com/products/boards/ml628/reference_designs.htm
Insert the CF card labeled IBERT #1 into the CF card reader slot located on the
bottom-side (upper-right corner) of the board.
Plug the 12V output from the power adapter into connector J122.
Connect the programming cable to the host computer. Any of these cables can be used:
•
Platform Cable USB-II (DLC10)
•
Platform Cable USB (DLC9, DLC9G or DLC9LP)
www.xilinx.com
Running the GTH IBERT Demonstration
CLKOUT1_N
CLKOUT1_P
UG806_c1_07_051111
11
