Fpga Configuration - Xilinx ML628 User Manual

X-Ref Target - Figure 1-7

FPGA Configuration

[Figure
The FPGA is configured in JTAG mode only using one of the following options:
•
•
•
•
Detailed information on the System ACE controller is available in
DS080, System ACE CompactFlash Solution.
The FPGA is configured through one of the aforementioned cables by connecting the cable
to the JTAG cable connector, J1.
The FPGA is configured through the System ACE controller by setting the 3-bit
configuration address DIP switches (SW3) to select one of eight bitstreams stored on a
CompactFlash memory card (see
The JTAG chain of the board is illustrated in
isolation jumpers described in
on header J162 automatically bypasses the FMC modules, GTH transceiver power supply
module and GTX transceiver power supply module in the chain.
ML628 Board User Guide
UG771 (v1.0.1) June 28, 2011
Figure 1-7: Fan Power Connector (J101)
1-2, callout 2]
Platform Cable USB
Parallel Cable IV
Parallel Cable III
System ACE controller
www.xilinx.com
Configuration Address DIP Switches, page
Figure 1-8 (the four System ACE interface
JTAG Isolation Jumpers are not shown). Shorting pins 1 – 2
Detailed Description
UG771_c1_07_022211
19).
17
