- Page 1 NEED HELP? SCAN OR CLICK HERE TO CONTACT US Air-Met Scientific www.airmet.com.au TIGER XTL Instrument User Manual V1.0 Pioneering Gas Sensing Technology. ionscience.com...
- Page 2 TIGER XTL Instrument User Manual V1.0 Register your instrument online for extended warranty Thank you for purchasing your ION Science instrument. The standard warranty of your instrument can be extended to two years. To receive your extended warranty, you must register your instrument online within one month of purchase (terms and conditions apply.)
- Page 3 TIGER XTL Instrument User Manual V1.0 Pioneering Gas Sensing Technology. Page 3 of 56 ionscience.com...
- Page 4 TIGER XTL Instrument User Manual V1.0 Pioneering Gas Sensing Technology. Page 4 of 56 ionscience.com...
-
Page 5: Table Of Contents
Turning On / Off ..........................19 Turning On .............................19 Turning Off .............................19 Setup Functions ..........................19 6. Using the Tiger XTL PC Software and Downloading Data ............22 PC Requirements ..........................22 Installation of Tiger XTL PC Software ....................22 Connecting a TIGER XTL to a PC ......................22 Opening Tiger XTL PC ........................23... - Page 6 TIGER XTL Instrument User Manual V1.0 Downloading Data Logged Readings and Instrument Settings .............25 Taking Snapshots ...........................26 Instrument Summary Screen ......................27 Configuration Screen ........................27 Firmware Screen ..........................31 Datalog Screen ..........................34 Snapshots Screen ...........................36 7. Calibration ..........................39 Calibration ............................39 Custom Calibration ........................39 Maintenance .............................41...
- Page 7 TIGER XTL Instrument User Manual V1.0 Technical Specifications ........................54 Warranty ............................55 ION Science Contact Details ......................56 Pioneering Gas Sensing Technology. Page 7 of 56 ionscience.com...
-
Page 8: Safety
• To the extent permitted by law, ION Science shall not be liable to any person or entity for any loss or damage which may arise from the use of this manual. •... -
Page 9: Disposal
When using the Probe part numbers A-861414, A-861413 the Safety rating of the TIGER XTL Instrument drops from II 1 G Ex ia IIC T4 Ga to II 1 G Ex ia IIB T4 Ga. The temperature performance of the unit is unaffected. -
Page 10: Product Overview
TIGER XTL Instrument User Manual V1.0 2. Product Overview The TIGER XTL is a portable gas detector that uses photo-ionization technology to detect a large range of Volatile Organic Compounds (VOCs) which can be dangerous from both a poisoning and explosive perspective. - Page 11 TIGER XTL Instrument User Manual V1.0 Pioneering Gas Sensing Technology. Page 11 of 56 ionscience.com...
-
Page 12: Tiger Xtl Pc Software
We recommend you install the software and set up your TIGER XTL as described in Tiger LT PC Software. TIGER XTL Kit ION Science provides a range of TIGER XTL kits and accessories. The content of a standard kit is: • TIGER XTL instrument •... -
Page 13: Keypad Function Descriptions
The Enter / On / Off key is used to accept changes, select functions, and to turn the TIGER XTL on and off. In general, setup and application settings are selected and adjusted using the soft keys. Options are selected using the arrow keys and confirmed using the Enter key or a soft key. -
Page 14: Getting Started
Switching your TIGER XTL Off Press and hold the Enter / On / Off key for 3 seconds to turn TIGER XTL Off. A 3-second countdown will be displayed on the screen. While this is happening, a continuous beep will sound, and the lights will flash red. -
Page 15: Checking The Battery Charge
TIGER XTL Instrument User Manual V1.0 Checking the Battery Charge Check that your TIGER XTL has sufficient charge for use. The battery icon should show at least two full segments. If not, the instrument should be charged to at least this level before use. -
Page 16: Understanding The Display Screen
TIGER XTL Instrument User Manual V1.0 4. Understanding the Display Screen IF AN ALARM STATE IS TRIGGERED THE USER SHOULD LEAVE THE HAZARDOUS ENVIRONMENT AND ACT IN ACCORDANCE WITH NATIONAL SAFETY REGULATIONS. Overview The main central viewing screen will display readings in large numbers only, up to 4 digits and decimal place will display 0.0 ppm to 5,000 ppm. -
Page 17: Status Icons
TIGER XTL Instrument User Manual V1.0 Status Icons Memory Status: Four sections within the border fill as the data log memory is filled. Empty border = 100% memory available through to full, where all segments are present. The icon fills as data log memory is filled. It will flash when multi-logging is activated. -
Page 18: Soft Key Options
The following icons are displayed in the soft key areas as soft key options. They are selected using the Up and Down keys. These icons can be reorganised or hidden using the Tiger XTL PC software. Refer to the Configuration section of Tiger XTL PC for details. -
Page 19: Using The Tiger Xtl
Turning On / Off Turning On To switch the TIGER XTL on press the Enter / On / Off key once. The device will display logo and info screens during the start-up sequence. The device will then zero before displaying the main running screen. We encourage users to leave the device running for 10 to 15 minutes prior to use. - Page 20 Pressing the Information soft key provides access to a list of screens which display the current settings of the TIGER XTL. Use the Up and Down keys to scroll through the list and press Enter to view a screen. Press Esc to return to the main running screen.
- Page 21 Press the Zone soft key to display the name of the currently selected Zone: . The TIGER default is '001'. Zones are set up in Tiger XTL PC. Use the Up and Down keys to select other zones. Data Logging: Single-log (push-to-log) Press the Single Data Log soft key to take a single data log reading.
-
Page 22: Using The Tiger Xtl Pc Software And Downloading Data
LCD display fails to show an intelligible and uncorrupted display the instrument must not enter a hazardous area. Connect your TIGER XTL to the PC. The (type B) USB port of the TIGER XTL is located at the back of the instrument, above the charging connectors. -
Page 23: Opening Tiger Xtl Pc
Before opening Tiger XTL PC, connect your TIGER XTL to the PC. Double-click the Tiger XTL icon on your desktop or in the Start menu to open Tiger XTL PC (or run Tiger.exe in the installation folder). The Home page will be displayed: Pioneering Gas Sensing Technology. -
Page 24: Help Screen
This screen will inform you if a new version of PC software is available. You can then install the upgrade if required. We recommend that Tiger XTL PC is kept up to date to ensure that the latest functionality is available to you. -
Page 25: Downloading Data Logged Readings And Instrument Settings
TIGER XTL Instrument User Manual V1.0 Downloading Data Logged Readings and Instrument Settings Click Instrument(s). The page that is then displayed lists the instruments that Tiger XTL PC has previously listed. To download data from the connected instrument (and to add it to the instrument list if it hasn’t been listed with Tiger XTL PC before) click Read. -
Page 26: Taking Snapshots
TIGER XTL Instrument User Manual V1.0 Taking Snapshots The first time you “read” an instrument a snapshot is taken automatically (see Snapshots Screen). On subsequent occasions this pop-up is displayed: Click Yes or No as required. To take a snapshot of a connected instrument at any time, click on the IRN of the instrument in the Instrument(s) list, then click Take Snapshot on the screen that is then displayed. -
Page 27: Instrument Summary Screen
Once an instrument has been read, expand its entry in the menu and click on Summary to display Instrument Summary screen. This screen shows the current status and properties of your TIGER XTL. Configuration Screen Use this screen to configure your TIGER XTL. Backlight Choose from: • Permanently off Pioneering Gas Sensing Technology. - Page 28 Volume is adjusted using the slider. Vibrate Use to set your TIGER XTL to vibrate under alarm conditions. Calibration Use this area to define your Custom Calibration parameters. Pioneering Gas Sensing Technology.
- Page 29 Zeroing The following options are available: • When selected, the TIGER XTL will automatically set its Zero reading based on ambient air when it is switched on. When deselected the instrument will use its calibration Zero. • When selected, TIGER XTL uses the fixed calibration Zero. If used in conjunction with the ‘Zero at switch on’...
- Page 30 Select 24- or 12-hour format. If required, select one of the following: • To set the time on your TIGER XTL. Set the time and date in the fields provided. • To synchronise the instruments time with that of the PC.
-
Page 31: Firmware Screen
Click View Release Notes for a description of the changes in the new version. To install a firmware update, connect TIGER XTL to your computer as detailed previously. Check that the Battery Pack is sufficiently charged (at least two bars). - Page 32 The following message is displayed: To continue, click Yes. The following message is displayed: Check that the instrument is connected and click Yes. Important: Do not operate your TIGER XTL during the update process. Pioneering Gas Sensing Technology. Page 32 of 56 ionscience.com...
- Page 33 TIGER XTL Instrument User Manual V1.0 The firmware will now be sent to the TIGER XTL. A bar at the bottom of the screen will indicate the progress of the update. The new firmware version will be shown on the screen.
-
Page 34: Datalog Screen
The firmware is now installed on the instrument. It will then restart automatically. Datalog Screen This screen is used to view data logged readings downloaded from your TIGER XTL, if a relevant upgrade has been installed. New readings are downloaded from the TIGER XTL when the instrument read. - Page 35 Important: The Delete option on the menu deletes all logged data from your TIGER XTL. Ensure all valuable data is exported to your PC before selecting it. Pioneering Gas Sensing Technology. Page 35 of 56...
-
Page 36: Snapshots Screen
TIGER XTL Instrument User Manual V1.0 Snapshots Screen A snapshot records the calibration settings of your TIGER XTL at a point in time. If required, your TIGER XTL can be reset to a snapshot’s settings. The Snapshots screen lists those stored on the PC. - Page 37 On the restore pop-up that is then displayed: Click Yes to load the snapshot. When the loading is complete, click Close and restart your TIGER XTL. Your TIGER XTL will now be restored to the settings and calibration data stored at the time of that snapshot.
- Page 38 TIGER XTL Instrument User Manual V1.0 Expand the menu until the relevant snapshot is displayed. Double-click on the snapshot. All the data stored in that snapshot can now be viewed. Click Delete to remove a selected snapshot. Pioneering Gas Sensing Technology.
-
Page 39: Calibration
Before doing so, first set up the calibration parameters in Tiger LT PC. TIGER XTL scales its linear output across a Zero level (clean air reference) and the SPAN 1 user-defined gas concentration. Due to the linear output of the ION Science MiniPID 2 Sensor, a two-point calibration is often adequate. - Page 40 On confirming the selection, the user is presented with a 30 second count down. Remove both caps from the Carbon Filter (A-31057) and then fit onto the probe of your TIGER XTL. Press Enter to start the ‘zero’ countdown. At the end of the count down a tick '✓' will appear, indicating that the Zero has been accepted.
-
Page 41: Maintenance
Please repeat annually. Ensure the TIGER XTL is charged for at least 7 hours before using it for the first time. To ensure optimum charging, the TIGER XTL should be switched off. If left on, the TIGER XTL will take longer to Pioneering Gas Sensing Technology. - Page 42 To charge your TIGER XTL, connect the Charge Cradle to the mains. A red light on the charger indicates that it is ready. Place the TIGER XTL in the Charge Cradle so that the contacts on the TIGER XTL are aligned with those in the cradle.
-
Page 43: Taking Off The Rechargeable Battery Packs
Charge Cradle to the mains. A red light on the charger indicates that it is ready. Place the TIGER XTL in the Charge Cradle so that the contacts on the lithium ion battery pack are aligned with those in the cradle. To hold the lithium ion battery in place, use the battery lid catch pn/912255 and connect to the top of the charge cradle. -
Page 44: Inlet Probe Assembly
TIGER XTL Instrument User Manual V1.0 Replacement of Non-rechargeable Batteries BATTERY REPLACEMENT: NEVER REPLACE PRIMARY ALKALINE BATTERY CELLS WHILE IN A POTENTIALLY EXPLOSIVE OR HAZARDOUS LOCATION. USE ONLY INDUSTRIAL BY DURACELL ID1500 BATTERIES. Fitting batteries or connecting the Battery Pack with the wrong polarity may result in damage to the instrument. -
Page 45: Ptfe Filter Disc
TIGER XTL Instrument User Manual V1.0 PTFE Filter Disc It is essential that the TIGER XTL is always used with a supplied 0.5 micron PTFE Filter Disc fitted to the front of the instrument. Without the filter, particles of debris and dust can be drawn into the MiniPID 2 Sensor inhibiting the function of the instrument. -
Page 46: When To Clean Or Replace The Lamp
When to Clean or Replace the Lamp The TIGER XTL MiniPID uses an ultraviolet light source ionising VOC gases as they pass across the Lamp window. This process may result in a fine layer of contamination on the detector window that must be removed on a regular basis. -
Page 47: Removing And Refitting The Sensor Cover
TIGER XTL Instrument User Manual V1.0 Removing and refitting the sensor cover To remove the sensor cover from the instrument body, unscrew the bottom left screw using a 3mm A/F allen key. The screw will stay retained in the sensor cover when fully loosened. - Page 48 TIGER XTL Instrument User Manual V1.0 To refit the sensor cover to the instrument body, line up the sensor cover with the back of the instrument ensuring it is align with the inlet/outlet ports. Gently push the right side of the sensor cover and the instrument body together until you hear and feel it is engaged.
-
Page 49: Removing The Minipid 2 Sensor
Before Lamp cleaning or replacement, the the MiniPID 2 Sensor must be removed. First ensure that the TIGER XTL is turned off and that you are in a clean environment so that the sensor parts will not be contaminated by dust, oil or grease. -
Page 50: Lamp Removal And Examination
Lamp Removal and Examination The TIGER XTL is a sensitive detector. Internal components must be handled with clean hands and clean tools. The TIGER XTL Lamp is fragile. Handle with great care. Never touch the window and do not drop. -
Page 51: Replacing A Lamp
TIGER XTL Instrument User Manual V1.0 The cleaning procedure is as follows: 1. Open the vial of Aluminium Oxide polishing compound. With a clean cotton bud collect a small amount of compound. 2. Use this cotton bud to polish the Lamp detection window. Use a circular action applying light pressure to clean the detection window. -
Page 52: Replacing The Minipid Electrode Stack
TIGER XTL Instrument User Manual V1.0 Replacing the MiniPID Electrode Stack At this point the MiniPID Electrode Stack can be replaced. Electrode Stack O-ring Lamp Spring Sensor Body Discard the removed (old) Electrode Stack, carefully removing the Lamp if still attached. -
Page 53: Troubleshooting
Diagnostics Basic faults or diagnostics are presented as symbols. Most faults can be corrected by pressing Enter or Esc to clear the fault message. All fault conditions cause the TIGER XTL to alarm. Pump failure Pump blocked or pump failure The flow of gas through the instrument has fallen below 50cc/minute. -
Page 54: Appendix And Supporting Documents
TIGER XTL Instrument User Manual V1.0 Technical Specifications Minimum Resolution 0.1 ppm Detectable Range 0.1 ppm to 5,000 ppm Response Time T90 < 2 seconds Accuracy ± 5% display reading ± one-digit (at calibration point) • Intrinsically Safe Approvals II 1G Ex ia IIC T4 Ga •... - Page 55 TIGER XTL Instrument User Manual V1.0 Warranty Standard Warranty can be extended to up to 2 years on the TIGER XTL when registering your instrument via the ION Science website. To receive your Extended Warranty, you need to register within one month of purchase (Terms and Conditions apply).
- Page 56 TIGER XTL Instrument User Manual V1.0 ION Science Contact Details ION Science Ltd – UK/Head Office Tel: +44 (0)1763 208 503 Web: www.ionscience.com | Email: info@ionscience.com ISM ION Science Messtechnik – Germany Office Tel: +49 (0) 2104 1448-0 Web: https://www.ism-d.de/en/ | Email: sales@ism-d.de...
