TI01683F/00/EN/01.22-00
71575906
2022-06-01
Products
Technical Information
Micropilot FMR60B
HART
Free space radar
Level measurement in liquids
Application
• Continuous, non-contact level measurement of liquids, pastes and sludges
• Process connections: Thread or mounting bracket
• Maximum measuring range: 50 m (164 ft)
• Temperature: –40 to +200 °C (–40 to +392 °F)
• Pressure: –1 to +20 bar (–14.5 to +290 psi)
• Accuracy: ±1 mm (±0.04 in)
Your benefits
• PVDF, PTFE Drip-off or PEEK antenna for small process connections
• Reliable measurement thanks to very good signal focusing, even with small process
connections
• Easy, guided commissioning with intuitive user interface
• Bluetooth®wireless technology for commissioning, operation and maintenance
• SIL2 as per IEC 61508, SIL3 for homogeneous redundancy
• Easy guided proof testing for SIL and WHG
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Micropilot FMR60B

Summary of Contents for Endress+Hauser Micropilot FMR60B

  • Page 1 Products Solutions Services TI01683F/00/EN/01.22-00 71575906 2022-06-01 Technical Information Micropilot FMR60B HART Free space radar Level measurement in liquids Application • Continuous, non-contact level measurement of liquids, pastes and sludges • Process connections: Thread or mounting bracket • Maximum measuring range: 50 m (164 ft) •...

  • Page 2: Table Of Contents

    Micropilot FMR60B HART Table of contents Important document information ....4 Process ........35 Symbols .
  • Page 3 Micropilot FMR60B HART Documentation ......62 Document function ......

  • Page 4: Important Document Information

    Micropilot FMR60B HART Important document information Symbols Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.

  • Page 5: Graphic Conventions

    Micropilot FMR60B HART Graphic conventions • Installation, explosion and electrical connection drawings are presented in simplified format • Devices, assemblies, components and dimensional drawings are presented in reduced-line format • Dimensional drawings are not to-scale representations; the dimensions indicated are rounded off to 2 decimal places •...

  • Page 6: Input

    Micropilot FMR60B HART D = (c ∆t) / 2 where c is the speed of propagation of the wave. In summary, D can be calculated from the measured difference frequency Δf. D is then used to determine the content of the tank or silo.
  • Page 7 To measure absorbing gases, either use a guided radar, measuring devices with another measuring frequency or another measuring principle. If measurements must be performed in one of these media, please contact Endress+Hauser. For the dielectric constants (DC values) of many media commonly used in industry, please refer •...
  • Page 8 Micropilot FMR60B HART Integrated antenna, PEEK, 20 mm (0.75 in) in storage vessel Media group Measuring range A0 (ε 1.2 to 1.4) 1.5 m (5 ft) A (ε 1.4 to 1.9) 2.5 m (8 ft) B (ε 1.9 to 4) 5 m (16 ft) C (ε...
  • Page 9 Micropilot FMR60B HART PTFE Drip-off antenna, 50 mm (2 in) in storage vessel Media group Measuring range A0 (ε 1.2 to 1.4) 7 m (23 ft) A (ε 1.4 to 1.9) 12 m (39 ft) B (ε 1.9 to 4) 23 m (75 ft) C (ε...
  • Page 10 Micropilot FMR60B HART PTFE Drip-off antenna, 50 mm (2 in) in buffer vessel Media group Measuring range A0 (ε 1.2 to 1.4) 4 m (13 ft) A (ε 1.4 to 1.9) 7 m (23 ft) B (ε 1.9 to 4) 13 m (43 ft) C (ε...

  • Page 11: Operating Frequency

    Micropilot FMR60B HART Encapsulated antenna, PVDF, 40 mm (1.5 in) in vessel with agitator Media group Measuring range A0 (ε 1.2 to 1.4) 1 m (3.3 ft) A (ε 1.4 to 1.9) 1.5 m (5 ft) B (ε 1.9 to 4) 3 m (10 ft) C (ε...

  • Page 12: Signal On Alarm

    Micropilot FMR60B HART The current output offers a choice of three different operating modes: • 4.0 to 20.5 mA • NAMUR NE 43: 3.8 to 20.5 mA (factory setting) • US mode: 3.9 to 20.8 mA Signal on alarm Current output Failure mode (according to NAMUR Recommendation NE 43): •...

  • Page 13: Wireless Hart Data

    Micropilot FMR60B HART Device type ID: 0x11C1 Device revision: HART specification: DD version: Device description files (DTM, DD) Information and files under: • www.endress.com On the product page for the device: Documents/Software → Device drivers • www.fieldcommgroup.org HART load: Min. 250 Ω...

  • Page 14: Power Supply

    Micropilot FMR60B HART Multidrop current: 4 mA Time to establish connection: < 30 s Power supply Terminal assignment Single compartment housing A0042594  3 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal Dual compartment housing A0042803 ...

  • Page 15: Available Device Plugs

    Micropilot FMR60B HART Dual compartment housing, L-form A0045842  5 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal Terminals • Supply voltage and internal ground terminal: 0.5 to 2.5 mm (20 to 14 AWG) •...

  • Page 16: Supply Voltage

    Micropilot FMR60B HART Measuring devices with Harting plug Han7D – + – Han7D – A0041011 Electrical connection for devices with Harting plug Han7D View of the plug-in connection on the device Brown  Green/yellow Blue Material CuZn, gold-plated plug-in jack and plug contacts...

  • Page 17: Cable Entries

    Devices without optional overvoltage protection Equipment from Endress+Hauser fulfills the requirements of the product standard IEC / DIN EN 61326-1 (Table 2 Industrial Environment). Depending on the type of port (DC power supply, input/output port) different testing levels according...

  • Page 18: Performance Characteristics

    Micropilot FMR60B HART Overvoltage category Overvoltage category II Performance characteristics Reference operating • Temperature = +24 °C (+75 °F) ±5 °C (±9 °F) conditions • Pressure = 960 mbar abs. (14 psia) ±100 mbar (±1.45 psi) • Humidity = 60 % ±15 % •...

  • Page 19: Influence Of Ambient Temperature

    Micropilot FMR60B HART The following step response times apply (in accordance with DIN EN IEC 61298-2 / DIN EN IEC 60770-1) when damping is switched off: • Pulse frequency ≥ 5/s (cycle time ≤ 200 ms) at U= 10.5 to 35 V, I= 4 to 20 mA and T = –50 to +80 °C (–58 to +176 °F)

  • Page 20: Mounting

    Micropilot FMR60B HART Mounting Mounting location A0016882 Recommended distance from wall to nozzle outer edge ~ 1/6 of the vessel diameter. The device should never be mounted closer than 15 cm (5.91 in) to the tank wall. Use of a weather protection cover; protection from direct sunlight or rain...

  • Page 21: Installation Instructions

    Micropilot FMR60B HART Avoiding interference echoes A0031813 Metal deflector plates, installed at an angle to scatter the radar signals, help prevent interference echoes. Vertical alignment of antenna axis Align the antenna so that it is perpendicular to the product surface.
  • Page 22 Micropilot FMR60B HART PTFE Drip-off antenna 50 mm (2 in) Information about the mounting nozzle The maximum nozzle length H depends on the nozzle diameter D. Maximum nozzle length H as a function of the nozzle diameter D D 50 to 80 mm (2 to 3.2 in) 750 mm (30 in) 80 to 100 mm (3.2 to 4 in)

  • Page 23: Beam Angle

    Micropilot FMR60B HART Maximum nozzle length H as a function of the nozzle diameter D ØD 40 to 50 mm (1.6 to 2 in) 400 mm (16 in) 50 to 80 mm (2 to 3.2 in) 550 mm (22 in) 80 to 100 mm (3.2 to 4 in)
  • Page 24 Micropilot FMR60B HART Drip-off, PTFE 50 mm (2 in) antenna, α = 6 ° W = D × 0.10 5 m (16 ft) 0.52 m (1.70 ft) 10 m (33 ft) 1.04 m (3.41 ft) 15 m (49 ft) 1.56 m (5.12 ft) 20 m (66 ft) 2.08 m (6.82 ft)

  • Page 25: Special Mounting Instructions

    Micropilot FMR60B HART Special mounting Measurement through a ball valve instructions A0034564 • Measurements can be performed through an open full bore ball valve without any problems. • At the transitions, no gap exceeding 1 mm (0.04 in) may be left.

  • Page 26: Environment

    Micropilot FMR60B HART If process temperatures are high, the device should be included in the usual container insulation system (2) to prevent the electronics from heating as a result of thermal radiation or convection. The rib structure (1) must not be insulated.
  • Page 27 Micropilot FMR60B HART A0048826  9 Plastic housing material; process temperature range: 0 to +150 °C (+32 to +302 °F) with CSA C/US approval = T : 0 °C (+32 °F) |  T : +76 °C (+169 °F) = T : +76 °C (+169 °F) |  T : +76 °C (+169 °F) = T...
  • Page 28 Micropilot FMR60B HART A0032024  12 Plastic housing material; process temperature range: –40 to +80 °C (–40 to +176 °F) = T : –40 °C (–40 °F) |  T : +76 °C (+169 °F) = T : +76 °C (+169 °F) |  T : +76 °C (+169 °F) = T : +80 °C (+176 °F) | ...
  • Page 29 Micropilot FMR60B HART A0048826  15 Plastic housing material; process temperature range: 0 to +130 °C (+32 to +266 °F) with CSA C/US approval = T : 0 °C (+32 °F) |  T : +76 °C (+169 °F) = T : +76 °C (+169 °F) |  T : +76 °C (+169 °F) = T...
  • Page 30 Micropilot FMR60B HART A0032024  18 Plastic housing material; process temperature range: –40 to +200 °C (–40 to +392 °F) = T : –40 °C (–40 °F) |  T : +76 °C (+169 °F) = T : +76 °C (+169 °F) |  T : +76 °C (+169 °F) = T : +200 °C (+392 °F) | ...
  • Page 31 Micropilot FMR60B HART A0032024  21 Aluminum housing material; process temperature range: –20 to +200 °C (–4 to +392 °F) = T : –20 °C (–4 °F) |  T : +79 °C (+174 °F) = T : +79 °C (+174 °F) |  T : +79 °C (+174 °F) = T : +200 °C (+392 °F) | ...
  • Page 32 Micropilot FMR60B HART A0032024  24 Aluminum housing material; process temperature range: –40 to +150 °C (–40 to +302 °F) = T : –40 °C (–40 °F) |  T : +79 °C (+174 °F) = T : +79 °C (+174 °F) |  T : +79 °C (+174 °F) = T : +150 °C (+302 °F) | ...
  • Page 33 Micropilot FMR60B HART A0032024  27 316L housing material; process temperature range: –20 to +200 °C (–4 to +392 °F) = T : –20 °C (–4 °F) |  T : +77 °C (+171 °F) = T : +77 °C (+171 °F) |  T : +77 °C (+171 °F) = T : +200 °C (+392 °F) | ...

  • Page 34: Storage Temperature

    Micropilot FMR60B HART A0032024  30 316L housing material; process temperature range: –40 to +200 °C (–40 to +392 °F) = T : –40 °C (–40 °F) |  T : +77 °C (+171 °F) = T : +77 °C (+171 °F) |  T : +77 °C (+171 °F) = T : +200 °C (+392 °F) | ...

  • Page 35: Process

    Micropilot FMR60B HART Process Process pressure range WARNING The maximum pressure for the device depends on the lowest-rated component with regard to pressure (components are: process connection, optional mounted parts or accessories). ‣ Only operate the device within the specified limits for the components! ‣...

  • Page 36: Dielectric Constant

    Micropilot FMR60B HART Process connection UNI flange PP Seal Process pressure range FKM Viton GLT –40 to +80 °C (–40 to +176 °F) –1 to 3 bar (–14.5 to 43.5 psi) EPDM –40 to +80 °C (–40 to +176 °F) –1 to 3 bar (–14.5 to 43.5 psi)

  • Page 37: Mechanical Construction

    Micropilot FMR60B HART Contact Endress+Hauser for applications with lower dielectric constants than indicated. Mechanical construction The dimensions of the individual components must be added together for the total dimensions. Dimensions Plastic single compartment housing 94 (3.7) 107.5 (4.23) A0048768  31...
  • Page 38 Micropilot FMR60B HART Aluminum single compartment housing 101 (3.98) 45 (1.77) 125 (4.92) A0038380  32 Dimensions of aluminum single compartment housing Height with cover with glass viewing window (devices for Ex d, dust Ex) Height with cover with plastic viewing window...
  • Page 39 Micropilot FMR60B HART Dual compartment housing 132 (5.2) 121 (4.76) 115 (4.53) 118 (4.65) 64 (2.52) 54 (2.13) 78 (3.07) 143 (5.63) A0038377  33 Dimensions of dual compartment housing Height with cover with glass viewing window (devices for Ex d, dust Ex)
  • Page 40 Micropilot FMR60B HART Dual compartment housing, L-form 110 (4.33) 101 (3.98) 140 (5.51) 138 (5.43) A0038381  34 Dimensions of dual compartment housing, L-form Height with cover with glass viewing window (devices for Ex d, dust Ex) Height with cover with plastic viewing window Cover without viewing window Encapsulated antenna, PVDF, 40 mm (1.5 in)
  • Page 41 Micropilot FMR60B HART Encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange 50 mm 43.7 (1.72) A0048829  36 Dimensions of encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange. Unit of measurement mm (in) Reference point of measurement Bottom edge of housing UNI flange 3"/DN80/80A...
  • Page 42 Micropilot FMR60B HART UNI flange 4"/DN100/100A 20 (0.79) A0048848  38 Dimensions of UNI flange 4"/DN100/100A. Unit of measurement mm (in) Suitable for ASME B16.5, 4" 150lbs / EN1092-1; DN100 PN16 / JIS B2220; 10K 100A Material: PP, weight 0.70 kg (1.54 lb) UNI flange 6"/DN150/150A...
  • Page 43 Micropilot FMR60B HART Drip-off antenna 50 mm (2 in), threaded process connection 55 mm 42.5 (1.67) A0046479  40 Dimensions of Drip-off antenna 50 mm (2 in), threaded process connection. Unit of measurement mm (in) Process temperature version ≤150 °C (302 °F) Process temperature version ≤200 °C (392 °F)
  • Page 44 Micropilot FMR60B HART Drip-off antenna 50 mm (2 in), UNI flange process connection 42.5 (1.67) A0046480  41 Dimensions of Drip-off antenna 50 mm (2 in), UNI flange process connection. Unit of measurement mm (in) Process temperature version ≤150 °C (302 °F) Process temperature version ≤200 °C (392 °F)
  • Page 45 Micropilot FMR60B HART UNI flange 4"/DN100/100A 20 (0.79) A0048848  43 Dimensions of UNI flange 4"/DN100/100A. Unit of measurement mm (in) Suitable for ASME B16.5, 4" 150lbs / EN1092-1; DN100 PN16 / JIS B2220; 10K 100A Material: • PP, weight 0.70 kg (1.54 lb) •...
  • Page 46 Micropilot FMR60B HART Integrated antenna, PEEK, 20 mm (0.75 in) 36 mm 23.8 (0.94) 32.2 (1.27) A0046481  45 Dimensions; integrated antenna, PEEK, 20 mm (0.75 in); process connection, thread 3/4". Unit of measurement mm (in) Process temperature version ≤150 °C (302 °F) Process temperature version ≤200 °C (392 °F)

  • Page 47: Weight

    Micropilot FMR60B HART Integrated antenna, PEEK, 40 mm (1.5 in) 42.5 (1.67) 54.8 (2.18) A0046482  46 Dimensions; integrated antenna, PEEK, 40 mm (1.5 in); process connection, thread 1-1/2". Unit of measurement mm (in) Process temperature version ≤150 °C (302 °F) Process temperature version ≤200 °C (392 °F)

  • Page 48: Materials

    Micropilot FMR60B HART Materials Materials not in contact with process Plastic housing • Housing: PBT/PC • Blind cover: PBT/PC • Transparent cover: PA12 • Cover with viewing window: PBT/PC and PC • Cover seal: EPDM • Potential equalization: 316L • Seal under potential equalization: EPDM •...
  • Page 49 Micropilot FMR60B HART Drip-off antenna 50 mm (2 in) A0046603  48 Material; Drip-off antenna 50 mm (2 in) Antenna: PTFE, seal material can be selected (order option) Threaded sleeve: 316L / 1.4404 Process connection: 316L / 1.4404 Housing adapter: 316L / 1.4404...

  • Page 50: Operability

    Micropilot FMR60B HART Integrated antenna, PEEK, 40 mm (1.5 in) A0046606  50 Material; integrated antenna, PEEK, 40 mm (1.5 in) Antenna: PEEK, seal material can be selected (order option) Process connection: 316L / 1.4404 Housing adapter: 316L / 1.4404...

  • Page 51: Local Operation

    Micropilot FMR60B HART • русский язык (Russian) • Türkçe • 中文 (Chinese) • 日本語 (Japanese) • 한국어 (Korean) • tiếng Việt (Vietnamese) • čeština (Czech) • Svenska Local operation Operating keys and DIP switches on the HART electronic insert Display A0046129 ...

  • Page 52: Remote Operation

    Prerequisite • Measuring device with display including Bluetooth • Smartphone or tablet with Endress+Hauser SmartBlue app or PC with DeviceCare from version 1.07.05 or FieldXpert SMT70 The connection has a range of up to 25 m (82 ft). The range can vary depending on environmental conditions such as attachments, walls or ceilings.

  • Page 53: Pressure Equipment With Allowable Pressure

    Micropilot FMR60B HART Explosion-protected smartphones and tablets If used in hazardous areas, mobile end devices with an Ex approval must be used. Pressure equipment with Pressure instruments with a flange and threaded boss that do not have a pressurized housing do not...

  • Page 54: 302372 Radio Standard

    Micropilot FMR60B HART Country Name of the station Latitude Longitude Switzerland Bleien 47° 20'   26" North 08° 06'   44" East Spain Yebes 40° 31'   27" North 03° 05'   22" West Robledo 40° 25'   38" North 04° 14'   57" West Hungary Penc 47° 47'   22" North 19° 16'   53" East As a general rule, the requirements outlined in EN 302729 must be observed.

  • Page 55: Calibration

    • Automatic verification of exclusion criteria • Automatic creation of the order code and its breakdown in PDF or Excel output format • Ability to order directly in the Endress+Hauser Online Shop Calibration Factory calibration certificate The points of the linearity protocol are spread evenly over the measuring range (0 to 100 %).

  • Page 56: Test, Certificate, Declaration

    Monitoring system and the in-situ verification of devices in the application. The application package can be ordered together with the device or can be activated subsequently with an activation code. Detailed information on the order code is available via the Endress+Hauser website www.endress.com...

  • Page 57: Accessories

    Micropilot FMR60B HART "Loop diagnostics" wizard Using this wizard, changes in the current-voltage loop characteristics (baseline) can be used to detect unwanted installation anomalies such as creep currents caused by terminal corrosion or a deteriorating power supply that can lead to an incorrect 4-20 mA measured value.

  • Page 58: Plastic Weather Protection Cover

    Micropilot FMR60B HART 228.9 (9.01) 136.4 (5.37) 92.5 (3.64) 170.5 (6.71) 81 (3.19) 103 (4.06) A0039231  53 Dimensions. Unit of measurement mm (in) Material • Weather protection cover: 316L • Clamping screw: A4 • Holder: 316L Order number for accessories:...
  • Page 59 Micropilot FMR60B HART A0048745  55 Ceiling or wall mounting 156 (6.14) 35 (1.38) 3 (0.12) 65 (2.56) 32.5 (1.28) 6 (0.24) 9 (0.35) A0048769  56 Dimensions of mounting bracket. Unit of measurement mm (in) Scope of delivery: • 1 × mounting bracket, 316L (1.4404) •...

  • Page 60: M12 Socket

    Micropilot FMR60B HART M12 socket M12 socket, straight • Material: Body: PBT; union nut: nickel-plated die-cast zinc; seal: NBR • Degree of protection (fully locked): IP67 • Pg coupling: Pg7 • Order number: 52006263 M12 socket, angled • Material: Body: PBT; union nut: nickel-plated die-cast zinc; seal: NBR •...

  • Page 61: Gas-Tight Feedthrough

    Micropilot FMR60B HART Connecting cable: • Connecting cable (option) up to 30 m (98 ft) • Standard cable provided by customer onsite up to 60 m (196 ft) Ambient temperature: • –40 to +80 °C (–40 to +176 °F) • Option: –50 to +80 °C (–58 to +176 °F)
  • Page 62 Registered trademark of the FieldComm Group, Austin, Texas, USA Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. Apple®...
  • Page 64 *71575906* 71575906 www.addresses.endress.com...
