Nortel Passport 2430 Manual

Hide thumbs Also See for Passport 2430:

Advertisement

Quick Links

Download this manual
Upgrading Memory in the
Passport 2430 Multiservice
Access Switch
Part No. 309894-A Rev 00
January 2000
4401 Great America Parkway
Santa Clara, CA 95054

Advertisement

loading

Related Manuals for Nortel Passport 2430

Summary of Contents for Nortel Passport 2430

  • Page 1 Part No. 309894-A Rev 00 January 2000 4401 Great America Parkway Santa Clara, CA 95054 Upgrading Memory in the Passport 2430 Multiservice Access Switch...
  • Page 2 Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 European Requirements Only EN 55 022 Statement This is to certify that the Nortel Networks Passport 2430 Multiservice Access Switch is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22).

  • Page 5: Verifying Shipment Contents

    ™ 2430 Multiservice Access Switch supports a broad array of primary and backup connectivity devices. This guide refers to the Passport 2430 Multiservice Access Switch as the Passport 2430. If you want to upgrade your router by adding more DRAM, you can install a 16 or 32 MB single inline memory module (SIMM).

  • Page 6: Installing The Simm

    In addition to the shelf kit shipping contents you will need a Phillips screwdriver. Installing the SIMM You install a SIMM in the Passport 2430 with the following steps: Turn off the Passport 2430. Take the cover off the chassis.
  • Page 7 Upgrading Memory in the Passport 2430 Multiservice Access Switch Remove the Cover from the Chassis To take the cover off the Passport 2430 chassis: Turn the Passport 2430 upside down and remove the four screws as shown in Figure 2. ATTACH WALL MOUNT BRACKET HERE...
  • Page 8 Upgrading Memory in the Passport 2430 Mutiservice Access Switch Carefully turn the Passport 2430 rightside up, grasp the cover near the front and pull up and remove as shown in Figure 3. VLK0053A Figure 3. Removing the Chassis Cover Locate the SIMM slot (Figure 4).

  • Page 9: Removing A Simm

    Upgrading Memory in the Passport 2430 Multiservice Access Switch Removing a SIMM To remove a SIMM currently in the Passport 2430: Pull the tabs on either side of the SIMM as shown in Figure 5. The SIMM pops up. VLK0058A Figure 5.
  • Page 10 Upgrading Memory in the Passport 2430 Mutiservice Access Switch Inserting a SIMM To insert the SIMM: Position the SIMM so that the notch on the SIMM lines up with the socket key on the SIMM slot. Gently push the SIMM into the slot as shown in Figure 6.

  • Page 11: Replacing The Chassis Cover

    Figure 7. Passport 2430 10/100 Console Modem Boot Fail Link TX/RX Flash PCMCIA VLK0059A Figure 7. Replacing the Chassis Cover Turn the Passport 2430 upside down and replace the four screws. 309894-A Rev 00...
  • Page 12 Upgrading Memory in the Passport 2430 Mutiservice Access Switch Starting the Passport 2430 After you install the SIMM and replace the chassis cover, start the Passport 2430 by plugging the power supply into the wall receptacle and pressing the power switch to the on (1) position.
