Nortel BayStack 380 model 24T Specifications

Nortel Networks
BayStack 380 Switches
Highlights
• High-density desktop switching
and server farm aggregation
(BayStack 380-24T)
• High-density wiring closet Layer 2
aggregation (BayStack 380-24F)
• Resilient connectivity for minimal
network downtime
• Traffic prioritization
• Secure access and data traffic protection
• Easier configuration and management
• BoSS v3.0 software simplifies software
upgrades
• Lower training and installation costs
Figure 1: The BayStack 380-24T Switch
The BayStack 380-24F Switch
Nortel Networks BayStack* 380 Switches
are designed to provide high-density, high-
bandwidth connectivity to desktops, other
switches, servers, and other network devices.
BayStack 380 Switches offer a resilient
solution that minimizes capital and opera-
tional expenses. Their robust security
features offer protection against unautho-
rized access to data traffic. The switches are
Web-manageable and support Redundant
Power Supply (RPS) and Uninterruptible
Power Supply (UPS) options. BayStack
380 Switches are available in two models—
BayStack 380-24T and BayStack 380-24F
(Figure 1).
BayStack 380-24T—
High-density desktop switching
and server aggregation
The BayStack 380-24T Switch has 24
10/100/1000 Mbps auto-sensing ports and
four SFP (Small Form Factor Pluggable)
GBIC (Gigabit Interface Converter) ports. It
provides high-density Gigabit connectivity
to power-user desktops for high-speed appli-
cations such as graphics, multimedia and
CAD/CAM, as well as server farm aggrega-
tion (Figure 2). Ports 21 through 24 may be
configured as either 10/100/1000 BASE-TX
ports or SFP GBIC ports in any combination.
The BayStack 380-24T is ideal for mid-size
and large businesses that have a need for
high bandwidth to the desktop.

Product Brief

BayStack 380-24F —
High-density wiring closet
switch aggregation
The BayStack 380-24F Switch with 20 SFP
(Small Form Factor Pluggable) ports and
four full-sized GBIC (Gigabit Interface
Converter) ports is an ideal switch for
high-density wiring-closet Layer 2 aggre-
gation. BayStack 470-48T stacks or
BayStack Business Policy Switch/BayStack
450 stacks can be collapsed into the
BayStack 380-24F using the uplink ports
on the wiring closet switches (Figure 3).
The GBIC ports offer an unmatched flexi-
bility of fiber connection types including
SX, LX, ZX, and XD as well as CWDM.
In addition, copper GBIC is also supported.
The BayStack 380-24F's high-density
design results in lower per port price than
its competitors. The BayStack 380-24F is
ideal for small and mid-size businesses
that need simple and cost-effective Layer 2
aggregation.
