Icom IC-2720H Instruction Manual page 14

QUICK REFERENCE GUIDE
3. Selecting the operating frequency band
The IC-2720H has 2 m and 70 cm bands for each left and
right band. The operating band can be exchanged between
them, and the same bands, V/V and U/U settings are also
possible.
Push the desired band's
[MAIN•BAND] for 1 sec.
[DIAL]
MAIN
T X
Frequency band initial is displayed.
➥ Push the desired band's (left or right) [MAIN•BAND] for
1 sec. then rotate the appropriate band's [DIAL].
• Push the [MAIN•BAND] momentarily to return to frequency indi-
cation.
IX
MAIN
T X
M M
4. Tune the frequency
The tuning dial will allow you to dial in the frequency you want
to operate. Pages 13 and 14 will instruct you on how to set
the tuning speed.
Rotate the desired [DIAL].
Using the HM-133
You can directly enter the frequency with the HM-133 keypad
for the main band.
[EXAMPLE]: Setting frequency to 145.3625 MHz.
Push
Push
Push
Push
MAIN
T X
MAIN
T X
MAIN
T X
MAIN
T X
