Use Adjust Length to ensure that lines in CAD drawings are printed at exactly the right length.
In the Adjust Length menu, choose the mode of length adjustment ( A:High or B:Standard/Draft ) that suits your
particular printing application.
• A:High : This setting is applied when Highest or High is selected in Print Quality in the printer driver.
• B:Standard/Draft : This setting is applied when Standard or Draft is selected in Print Quality in the printer
driver.
Check the Feed Priority setting before using Adjust Length . (→Selecting a Feed Amount Adjustment Method (Feed
Priority), User Manual)
• Use paper of the same type and size for adjustment as you will use for printing.
• If you have selected Easy Settings on the printer, follow these steps to confi rm the Print Quality setting.
• Windows: Click View Settings on the Main tab to display the View Settings dialog box.
• Mac OS X: Click View set. on the Main pane to display the View settings dialog box.
Paper to
Prepare
Follow these steps to change the Adjust Length setting.
1
Load the paper.
(→ , Attaching the Roll Holder to Rolls)
(→ , Loading Rolls in the Printer)
(→ , Loading Sheets in the Printer)
• Always make sure the loaded paper matches the type of paper specifi ed in the settings. Adjustment
cannot be completed correctly unless the loaded paper matches the settings.
2
Press the Menu button to display MAIN MENU .

If Line Length Does Not Match

Adjust the length of printed lines as follows.
• Rolls
An unused roll at least 10 inches wide
• Sheets
One sheet of unused paper of at least A4/Letter size
