If Line Length Does Not Match - Canon imagePROGRAF iPF6300S Basic Guide No.2 Basic Manual

To ensure that lines in CAD drawings are printed at exactly the right length, use Adjust Length to adjust the
amount that paper is advanced.
There are two options in Adjust Length : AdjustmentPrint and Change Settings .
• AdjustmentPrint
After a test pattern is printed, you will measure the discrepancy based on the results of printing.
• Change Settings
No test pattern is printed. Instead, you will measure a document already printed to determine the discrepancy.
Additionally, two modes are available in both AdjustmentPrint and Change Settings : A:High or B:Standard/
Draft . Choose the mode that suits your particular printing application.
• A:High
This setting is applied when Highest quality or High is selected in Print Quality in the printer driver.
• B:Standard/Draft
This setting is applied when Standard or Fast is selected in Print Quality in the printer driver.
• Always check the Adj. Priority values before using Adjust Length .
(→"Selecting a Feed Amount Adjustment Method (Feed Priority)," User's Guide)
• Use paper of the same type and size for adjustment as you will use for printing.
Items to Prepare
Perform adjustment as follows.
1
Load paper.
(→ , Loading Rolls on the Roll Holder)
(→ , Loading Rolls in the Printer)
(→ , Loading Sheets in the Printer)
• Always make sure the loaded paper matches the type of paper specifi ed in the settings. Adjustment
cannot be completed correctly unless the loaded paper matches the settings.
2
On the Tab Selection screen of the Control Panel , press
◄ or ► to select the Settings/Adj. tab (
• If the Tab Selection screen is not displayed, press the Menu button.

If Line Length Does Not Match

Adjust the length of printed lines as follows.
• When Using Rolls
An unused roll at least 10 inches wide
High-precision ruler
• When Using Sheets
One sheet of unused paper of at least A4/Letter size
High-precision ruler
).
30
Ready
OK:Setting/Adj. Menu
Maint.C Remain.: 80%
Tot.Print Area(m2):
678
