Alpine i509-WRA-JK Installation Manual page 7

Factory Unit Disassembly Process
DISCONNECT THE BATTERY BEFORE
CONTINUING. FAILURE TO DO SO WILL
DISABLE MANY FEATURES.
1
Remove the rubber cover from the top center
storage area and extract (1) 7mm screw.
3
Remove the window switch pod using a panel
removing tool and extract (1) 7mm screw.
5
Extract (4) 7 mm screws and remove the factory
radio.
i509-WRA-JK
2
Remove the knee cover panel and extract (2) 7mm
screws located to the right and left sides of the
steering wheel column.
Left side of
steering wheel
column.
4
Remove the dash panel.
6
Extract (2) 7 mm screws from the factory radio
bracket and remove it.
Jeep Wrangler
20220404v1
˜ 7/22
Right side of
steering wheel
column.
