Alpine i509-WRA-JK Installation Manual page 13

i509-WRA-JK Wiring Diagram
To Vehicle Connectors
To OBDII Connector
16-pin Green Connector
Not Not
Used Used
10-Pin Chime 18-Pin
iDatalink MAESTRO Module
3-Pin 4-Pin 10-Pin
Not
Blue
Used
Not
Used
MANUAL TRANSMISSION VEHICLES
White/Gray Manual Transmission Reverse Input
For manual transmission vehicles ONLY. Connect the
White/Gray wire to the White/Gray wire located
on the passenger side kick panel.
Yellow -12V+
Red - Acc 12V+
Black - Ground
Rear View Camera
If using
WARNING!
HCE-TCAM1-WRA
The use of this connection
see page 17
is intended for Alpine
HCE-TCAM1-WRA rear
view camera ONLY.
Power/Speaker Antenna
Connection
Red
Not
Reset
Used
Button
3-Pin 4-Pin
Blue/White Amp Turn-on
Blue Power Antenna
AUX Power
3-pin Black Connector
Rear View Camera
6-pin Black Connector
i509-WRA-JK
AMPLIFIED VEHICLES
WARNING!
Failure to follow this procedure will
result in no audio from Navigation and
Bluetooth sources.
For factory amplified vehicles switch the
speaker connectors, front to rear and
rear to front.
Black (Data) USB
Gray (Charging Only) USB
USB's get ran to where you want to plug in
at in the vehicle. OEM and flush mount adapters
may cause issues. Plug directly into the extension.
i509 Source Unit
IN OUT
DISPLAY
USB
EX KEY
MAIN
Power Harness
Jeep Wrangler
20220404v1
GPS
Antenna
To Optional To Dash Cam
Cameras See Page 10
CAMERA
GPS
SXM
PREOUT
REMOTE
ANTENNA
To SXM Tuner
See Page 10
HDMI Remote Out
AUX Remote Out
i509 - Display
˜ 13/22
