OWNER'S MANUAL
Instructions for the installation, operation
and maintenance of all Traulsen:
Reach-In & Roll-In Even Thaw Refrigerator Models
*Traulsen's even thaw's are solely intended for thawing, and not for use as holding cabinets
Reach-In: RET132EUT, RET232EUT & RET232NUT
This Traulsen unit is built to our highest quality standards. We build our refrigerators, freezers and heated
cabinets this way as a matter of pride. This philosophy has made Traulsen the leader in commercial
refrigeration since 1938. We thank you for your choice and confidence in Traulsen equipment and we know
you will receive many years of utility from this equipment.
All Traulsen units are placed on a permanent record file with the service department. In the event of any
future questions you may have, please refer to the model and serial number found on the name tag affixed
to the unit. Should you need service, however, call us on our toll free number, 800-825-8220 between 7:30
am and 4:30 pm CST, Monday thru Friday. It is our pleasure to help and assist you in every possible way.
COMPLETE THE FOLLOWING INFORMATION PRIOR TO UNIT INSTALLATION
INITIAL START DATE:
MODEL TYPE:
COMPANY/INDIVIDUAL NAME:
INSTALLER:
FORM NUMBER TR35849 (REV. 07-31-15)
Quality Refrigeration
Roll-In: RET232LUT
INSTALLER
SERIAL NO.
.
P/N 375-60214-00

Advertisement

Table of Contents
loading

Related Manuals for Traulsen RET232LUT

Summary of Contents for Traulsen RET232LUT

  • Page 1 All Traulsen units are placed on a permanent record file with the service department. In the event of any future questions you may have, please refer to the model and serial number found on the name tag affixed to the unit.

  • Page 2: Table Of Contents

    I. THE SERIAL TAG The serial tag is a permanently affixed sticker on which is recorded vital electrical and refrigeration data about your Traulsen product, as well as the model and serial number. This tag is located in the upper right interior compartment on all reach-in/pass-thru and roll-in/roll-thru refrigerator, freezer and dual-temp models.

  • Page 3: Receipt Inspection

    II. RECEIPT INSPECTION III. INSTALLATION (continued) All Traulsen products are factory tested for performance and III. c - INSTALLING LEGS OR CASTERS: are free from defects when shipped. The utmost care has 6” high stainless steel legs are supplied standard for been taken in crating this product to protect against damage all Traulsen reach-in and pass-thru units.

  • Page 4: D-Tray Slides

    Refer to the wiring diagram for any service work performed The Traulsen Even-Thaw cabinet is a refrigerator, with two on the unit. Should you require one, please contact Traulsen important additional features: 1) the ability to introduce small Service at (800) 825-8220, and provide the model and serial amounts of heat into the cabinet, and 2) increased air flow, number of the unit involved.

  • Page 5: D-Batch Loading

    The most important thing you can do to insure a long, reli- load, or up to twenty eight (28) 18” x 26” pans of product. Use able service life for your Traulsen is to regularly clean the of aluminum pans is highly recommended. Product should be condenser coil.

  • Page 6: C-Replacing The Gaskets

    Traulsen service agent. A complete list of authorized service agents was provided along with your Traulsen unit. If you cannot locate this, you may also obtain the name of a service agent from the SERVICE & PARTS button of our website: www.

  • Page 7: Gen'l Use, Operation & Service

    SHOOTING VII. a - INTRODUCTION/OVERVIEW: VIII. a - INTRODUCTION: The Traulsen Even Thaw is designed to be used as a Even thaw performance is a function of many factors, espe- thawing cabinet. While it may be utilized in a refrigeration cially those involving product types and loading.

  • Page 8: E-Incomplete Thawing

    If improper loading has been eliminated as a possible cause for extended thaw cycle times, there are several system checks which can be done to diagnose the Traulsen Even- Thaw unit. First, the amp draw should be checked early in the thaw cycle.

  • Page 9: Trouble Shooting Guide

    IX. TROUBLE SHOOTING GUIDE FIND YOUR PROBLEM HERE REMEDY 1. Condensing unit fails to start. Check if cord & plug has been disconnected. 2. Condensing unit operates for Are doors closing properly? prolonged periods or continuously. Dirty condenser or filter. Clean properly. Evaporator coil iced.

  • Page 10: Spare Parts List

    SER-28583-00 MULLION BLOWER ASSEMBLY115V SER-60545-00 MULLION BLOWER ASSEMBLY230V SER-60545-01 EVAPORATOR BLOWER ASSEMBLY 230V SER-60545-03 EVAPORATOR BLOWER ASSEMBLY 115V SER-60545-02 RET232LUT-FHS FULL HEIGHT DOOR GASKET 341-16473-00 TXV VALVE 404A 325-60080-39 LIGHT BULB 358-29776-00 MIT II CONTROL MODULE 110V 337-60317-61 OFF/ON POWER SWITCH...

  • Page 11: Wiring Diagrams

    XI. WIRING DIAGRAM ALL ONE SECTION MODELS ONLY -10-...
  • Page 12 XI. WIRING DIAGRAM ALL TWO SECTION 120V MODELS ONLY -11-...
  • Page 13 XI. WIRING DIAGRAM ALL TWO SECTION 208V MODELS ONLY -12-...

  • Page 14: Warranty Information

    “Defective Part Return” – All claimed defective r e p l a c e m e n t part(s) must be returned to TRAULSEN for i n s p e c t i o n within 30 days from the date of the repair.
  • Page 15 Notes:...
  • Page 16 HOURS OF OPERATION: Monday thru Friday 7:30 am - 4:30 pm CST Traulsen 4401 Blue Mound Road Fort Worth, TX 76106 Phone: (800) 825-8220 Fax-Svce: (817) 740-6757 Website: www.traulsen.com Quality Refrigeration © 2015 Traulsen - All Rights Reserved...
