OWNER'S MANUAL
Instructions for the installation, operation
and maintenance of all Traulsen:
R & A Series Reach-In & Roll-In Refrigerators
R & A Series Pass-Thru & Roll-Thru Refrigerators
R & A Series Reach-In & Roll-In Freezers
R & A Series Reach-In Refrigerator/Freezers
R & A Series Reach-In & Roll-In Hot Food Cabinets
R & A Series Pass-Thru & Roll-Thru Hot Food Cabinets
This Traulsen unit is built to our highest quality standards. We build our refrigerators, freezers and heated
cabinets this way as a matter of pride. This philosophy has made Traulsen the leader in commercial
refrigeration since 1938. We thank you for your choice and confidence in Traulsen equipment and we know
you will receive many years of utility from this equipment.
All Traulsen units are placed on a permanent record file with the service department. In the event of any
future questions you may have, please refer to the model and serial number found on the name tag affixed
to the unit. Should you need service, however, call us on our toll free number, 800-825-8220 between 7:30
am and 4:30 pm CST, Monday thru Friday. It is our pleasure to help and assist you in every possible way.
COMPLETE THE FOLLOWING INFORMATION PRIOR TO UNIT INSTALLATION
INITIAL START DATE:
MODEL TYPE:
COMPANY/INDIVIDUAL NAME:
INSTALLER:
FORM NUMBER TR35743 REV. 10/04
Quality Refrigeration
INSTALLER
SERIAL NO.
P/N 375-60176-00

Advertisement

Table of Contents
loading

Related Manuals for Traulsen R & A Series

Summary of Contents for Traulsen R & A Series

  • Page 1 All Traulsen units are placed on a permanent record file with the service department. In the event of any future questions you may have, please refer to the model and serial number found on the name tag affixed to the unit.

  • Page 2: Table Of Contents

    The serial tag is a permanently affixed sticker on which is recorded vital electrical and refrigeration data about your Traulsen product, as well as the model and serial number. This tag is located in the upper right interior compartment on all reach-in/pass-thru and roll-in/roll-thru refrigerator, freezer and dual-temp models.

  • Page 3: Receipt Inspection

    (return authorization). III. INSTALLATION III. a - LOCATION: Select a proper location for your Traulsen unit, away from extreme heat or cold. Allow enough clearance between the unit and the side wall in order to make use of the °...

  • Page 4: D-Shelf Pins

    III. c - INSTALLING LEGS OR CASTERS (cont’d): Please note that Traulsen units are not designed to be moved while on legs. If the unit requires moving, a pallet jack or forklift should be used to prevent damage. For installing casters, the casters are “plate” type, and...

  • Page 5: H-Remote Installation

    III. l - CLEARANCE: In order to assure optimum performance, the condensing unit of your Traulsen unit MUST have an adequate supply of air for cooling purposes. Therefore, the operating location must either have a minimum of 12”...

  • Page 6: Operation

    ® V. a - CLEANING THE CONDENSER: The most important thing you can do to insure a long, reliable service life for your Traulsen is to regularly clean the condenser coil. The condensing unit requires regularly scheduled cleaning to keep the finned condenser clean of lint and dust accummulation.

  • Page 7: B-Hinge Replacement

    V. a - CLEANING THE CONDENSER: Once the screws are removed, the panel can be pivoted upwards allowing full access to the front facing condenser (see figure 9). Fig. 7 Lift-Up Louver Assembly Vacuum or brush any dirt, lint or dust from the finned condenser coil, the compressor and other cooling system parts (see figure 10).

  • Page 8: G-Replacing The Light Bulb

    @ www.traulsen.com. VI. c - WARRANTY REGISTRATION: For your convenience, the warranties on your new Traulsen unit may be registered with us by one of two methods. Completing the enclosed warranty card (shipped with the unit). VI. OTHER...

  • Page 9: A-Control Features

    VII. The INTELA-TRAUL Your new Traulsen Refrigerator, Freezer or Hot Food cabinet is equipped with a state-of-the- art electronic microprocessor INTELA-TRAUL and provides alarms when problems occur. It is supplied from the factory completely ready for use and requires no adjustment (except Hot Food units which are set in the “OFF”...

  • Page 10: Intela-Traul

    VII. INTELA-TRAUL VII. a - ALARM EXPLANATIONS: *NOTE: Explanation of alarms assume the audible alarm style is set at a 3-second burst or a continuous audible alarm. References to the audible alarm do not apply if the audible alarm style is set to OFF (Refer to page 19 for setting the audible alarm style). High Cabinet Air Temperature: The audible alarm* will sound and the display will read HI CAb when the temperature inside the cabinet rises above a pre-programmed limit.

  • Page 11: C-Control Panel

    VII. c - CONTROL PANEL: ° LED FOR 3-DIGIT (RED) LED DISPLAY ALARM CANCEL BUTTON DEFROST ICON W / LED VII. d - PARTS ASSEMBLY: (Reach-In & Roll-In Cabinets) RH SENSOR* (refrigerator & freezer only) 337-60080-00 DEFROST COMPRESSOR RELAY POWER LINE IN 2 (refrigerator &...

  • Page 12: E-Notes To The User

    VII. e - NOTES TO THE USER: You only have 20-30 seconds between button pushes. If you take longer than 30 seconds, the controller will revert back to displaying the cabinet temperature. If you enter the wrong security code, the controller will revert back to displaying the cabinet temperature.

  • Page 13: G-Customer Service Parameters

    VII. g - CUSTOMER SERVICE PARAMETERS: Listed below are the available parameters in the order they appear, using the down arrow key on the controller. You can use either the up or down arrow keys to scroll through the options. Thermostat Set Point High* Thermostat Set Point Low Temperature Scale*...

  • Page 14: I-Adjusting Thermostat Set Point Low

    VII. i - ADJUSTING THE THERMOSTAT SET POINT LOW: This parameter sets the low point of the desired cabinet temperature range. Typically, freezers will range from -6° F to -4° F (-21° C to -20° C) and refrigerators will range from 32° F to 34° F ( 0° C to 1° C) for this parameter setting.

  • Page 15: K-Setting The 24-Hour Clock

    VII. k - SETTING THE 24-HOUR CLOCK: The internal timeclock must be set in order for the data storage memory to correctly log events and to allow any defrost lockout to occur at the correct time of day. If the clock is not set, the control assumes the time is 12 a.m.

  • Page 16: L-Setting The Date

    VII. l - SETTING THE DATE: The date must be set in order for the data storage memory to correctly log events. Follow the instruc- tions to enter the customer access code on page 11. When the control displays Set Point High, press the down arrow key the set button .

  • Page 17: N-Starting A Manual Defrost

    FREEZER NOTE: Traulsen refrigerator units also have an off-cycle defrost once an hour, at which time the control will read . This defrost is temperature terminated and can last from 3 - 10 minutes (dEF will be displayed for 22-27 minutes).

  • Page 18: O-Setting Defrost Lockouts

    VII. o - SETTING THE DEFROST LOCKOUTS: The defrost lockout parameters allow the customer to prevent the unit from going into a defrost cycle for two hours during a set timeframe. Customers can set up to four defrost lockout parameters. They are all programmed the same way.

  • Page 19: P-Adjusting The Door Perimeter Heaters

    VII. INTELA-TRAUL (continued) ® VII. p - ADJUSTING THE DOOR PERIMETER HEATERS: This parameter allows the customer to turn ON and OFF the anti-condensate door perimeter heaters. This parameter is set to the highest setting (100) at the factory so that the door heaters stay on continu- ously.

  • Page 20: R-Setting The Audible Alarm Style

    VII. r - SETTING THE AUDIBLE ALARM STYLE: This parameter will allow the customer to turn on/off the audible alarm feature on the INTELA-TRAUL control. The audible alarm is preset from the factory to OFF. The customer can choose ® between an audible alarm that sounds for 3 seconds then automatically turns off, or a continuous audible alarm that must be manually acknowledged.

  • Page 21: T-Hot Food Units - Adjusting The Thermostat

    VII. t - HOT FOOD UNITS, ADJUSTING THE THERMOSTAT & TURNING THE UNIT OFF/ON: This parameter sets the desired cabinet temperature. Please note that hot food units are delivered from the factory set to the OFF position. Follow the instructions to enter the customer access code on page 11. When the control reads Thermostat Set Point High, press the set button Use the arrow keys shows the temperature you want press the set button...

  • Page 22: Trouble Shooting Guide

    VIII. TROUBLE SHOOTING GUIDE FIND YOUR PROBLEM HERE 1. Condensing unit fails to start. 2. Condensing unit operates for prolonged periods or continuously. 3. Food compartment is too warm. 4. Food compartment is too cold. 5. Condensation on the exterior surface. 6.

  • Page 23: Spare Parts List

    PART Bulb, Fluorescent Bulb, Incandescent Bulb Cover Caster, 6” High Caster, 4” High W/O Brake Caster, 4” High W/Brake Caster Bolt (4 req’d per caster) Door Handle, Stainless Steel Door Lock, Sliding Glass Hinge Cam Hinge Cover Hinge, Spring Assist Hinge Assembly W/Stop Feature Hinge Assembly Key, Master...

  • Page 24: Stainless Steel Overview

    R-Series models are constructed using 300 series stainless steel (anodized aluminum is used for A-Series). The stainless steel finish on Traulsen R & A Series should retain its appearance throughout the products usable lifetime. However, some care is required to maintain this appearance.

  • Page 25: Xiii. Care Of Stainless Steel

    XIII. CARE OF STAINLESS STEEL (cont’d) XIII. c - CLEANING SUMMARY - DO’S & DONT’S: To summarize the proper cleaning of Traulsen refrigeration products, always follow the below guidelines. use only cleaning products designed for stainless steel, or cleaning products which do not contain chlorides.

  • Page 26: Warranty Information

    TRAULSEN warrants to the original purchaser the Refrigeration Equipment manufactured and sold by it to be free from defects in material and workmanship under normal use and service for a period of one (1) year from date of shipment. Under this warranty, TRAULSEN will reimburse the purchaser for the replacement of any part of said equipment (excluding dryers &...

  • Page 27: Index

    Alarms Audible Alarm Styles Cleaning 5, 6 Casters Condensate Evaporator Cord & Plug Condenser Clean 5-6, 8 Clearance Customer Access Code Customer Service Parameters 11-12 Daylight Savings Time Defrost Defrost Lockouts Data Storage Gaskets, Replacing The Hinge Replacement Internal Time Clock INTELA-TRAUL 5, 8-20 Legs, Installing The...
  • Page 28 HOURS OF OPERATION: Monday thru Friday 7:30 am - 4:30 pm CST Quality Refrigeration Traulsen 4401 Blue Mound Road Fort Worth, TX 76106 Phone: (800) 825-8220 Fax-Svce: (817) 740-6757 Website: www.traulsen.com © 2004 Traulsen - All Rights Reserved...
