GA-8ITX Series Motherboard
Creating a Security Array With An Existing Data Drive
NOTE: This motherboard permits only two drives to be used for a single Mirrored array in Auto
Setup.
You would use this method if you wish to use a drive that already contains data and/or is the bootable
system drive in your system. You will need another drive of identical or larger storage capacity.
WARNING: Backup any necessary data before proceeding. Failure to follow this
accepted PC practice could result in data loss.
WARNING: If you wish to include your current bootable drive using the Windows
NT 4.x or Windows 2000 operating system as part of a bootable Mirrored (RAID 1)
array on your system, do NOT connect the hard drive to the motherboard controller
yet. You MUST install the Windows NT4 or 2000 driver software first (see RAID
Manual of the IUCD) to this drive while it is still attached to your existing hard
drive controller. For all other Operating Systems, proceed here.
Follow these steps:
1. Using the Spacebar, choose "Security" under the Optimize Array for section.
2. Press <Ctrl-Y> keys to Save your selection. The window below will appear.
Do you want the disk image to be duplicated to another? (Yes/No)
Y - Create and Duplicate
N - Create Only
3. Press "Y" for the Create and Duplicate option. The window below will appear asking you to select
the Source drive to use. FastBuild will copy all data from the Source drive to the Target drive.
Channel:ID
Channel:ID
Channel:ID
1 :Master
2 :Master
Drive Model
Drive Model
[Please Select A Source Disk]
Drive Model
QUANTUMCR8.4A
QUANTUMCR8.4A
[ ] Up [ ] [ESC] Exit [Ctrl-Y] Save
Source Disk
Target Disk
8063
8063
8 0
Capacity (MB)
Capacity (MB)
Capacity (MB)
