GA-8ITX Series Motherboard
A / E / S : PWR_FAN / SYS_FAN / CPU_Fan Connector
1
PWR_FAN
The CPU fan connector supports Max. current up to 1A and Max. power up to 10W.
B / K: RIMM LED & STR LED Connector*
RIMM LED
C: ATX Power
+12V
5V SB (Stand by +5V)
Power Good
GND
VCC
GND
VCC
GND
3.3V
3.3V
"*" For GA-8ITXR only.
Sense
+12V/Control
1
GND
SYS_FAN
1
STR LED Connector
20
VCC
VCC
-5V
GND
GND
GND
PS-ON(Soft On/Off)
GND
-12V
3.3V
1
1 8
+12V/Control
Do not remove memory modules while
RIMM LED is on. It might cause short or
other unexpected damages due to the
2.5V stand by voltage. Remove memory
modules only when STR function is
disabled by jumper and AC Power cord is
disconnected.
AC power cord should only be connected
to your power supply unit after ATX power
cable and other related devices are firmly
connected to the mainboard.
1
GND
Sense
CPU_FAN
