- Page 1 MU18Ba 18" Active Subwoofer MU Series Pro Loudspeaker System User Manual U M- MU 1 8 B a - 2 0 1 0 0 7 0 6 v e r A...
- Page 2 SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thanks for buying products. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using the hanging and rigging parts that are not appointed, please ensure the intensity of the structure comply with the local safety criterion.
-
Page 3: Table Of Contents
MU18Ba CONTENT MU series professional loudspeaker system CONTENT INTRODUCTION Features Description Applications AMPLIFIER MODULE Rear Panel INSTALLATION Installation Accessories Installation Reference TECHNICAL SPECIFICATION Technical Sheet Frequency Response Curve 2D Dimension Product information may be updated without notification, please visit www.elderaudio.com for... -
Page 4: Introduction
The sound is very clean, powerful and stretchy. Description Applications β3 MU18Ba is a brand new design subwoofer in MU family. Conference Room It adopts one 18" LF woofer, built-in crossover and single Small Auditorium channel amplifier. -
Page 5: Amplifier Module
MU18Ba AMPLIFIER MODULE MU series professional loudspeaker system Introduction Of Amplifier Module HIGH CUT USE ONLY WITH A 250V FUSE OUTPUT LIMIT MU18Ba ACTIVE HE MAX. CONSUMPTION POWER 500W ACTIVE SUB WOOFER VOLUME No.: ELDER AUDIO MANUFACTURE Co.,Ltd. ~ 115V/230V 50Hz/60Hz,T5AL... -
Page 6: Installation
MU18Ba INSTALLATION MU series professional loudspeaker system Installation Accessories Installation Reference The support flange in the top of MU18Ba is for the pole 1. Stack mounting application with MU series. 1. Speaker stand MUseries MU18Ba Warning: Make sure the mounting accessories safety factor not less than 5:1 or meet the local standard during installation . -
Page 7: Technical Specification
MU18Ba TECHNICAL SPECIFICATION MU series professional loudspeaker system Specification Frequency response(-3dB): 45Hz-250Hz Max.SPL(1m): 124dB/130dB(PEAK) 1X 18" Woofer, 8ohm, 500W Transducer: Input: One input and one output. Connector: XLR for input, XLR for output Input impedance(line): 20Kohm balanced input Input level: 0 dBu (0.775 V rms, 1.4 V peak)Line-100Hz... -
Page 8: 2D Dimension
MU18Ba TECHNICAL SPECIFICATION MU series professional loudspeaker system 2D Dimension Top view 600mm [23.62in] Front view Side view Back view Bottom view... - Page 9 Notes:...
- Page 10 www.beta3pro.com...
