- Page 1 MU12B Single 12 Subwoofer " With Built-in Crossover MU Series Pro Loudspeaker System User Manual UM- MU1 2 B - 2 0 0 9 1 2 2 5 v e r A...
- Page 2 SAFETY INSTRUCTIONS PLEASE READ THIS MANUAL FIRST Thank you for a buyin product. Read this manual first as it will help you operate the system properly. Please keep this manual for future reference. WARNING: This product must be installed by professionals. When using hanging brackets or rigging other than those supplied with the product, please ensure they comply with the local safety codes.
-
Page 3: Table Of Contents
MU12B CONTENT MU Series Pro Loudspeaker System CONTENT INTRODUCTION Feature Description Application CONNECTION Terminal Plate Nl4 Connection System Connection Reference Loudspeaker Connection INSTALLATION Installation Accessories Installation Reference TECHNICAL SPECIFICATION Technical Sheet Frequency Response And Impedance Curve Frequency Response And Impedance Curve... -
Page 4: Introduction
MU12B INTODUCTION MU Series Pro Loudspeaker System MU12B Single 12 subwoofer with built-in crossover " Feature Single 12 subwoofer, phase inverted configuration. " Advanced free protection design assure the reliability of tweeter. Sensitivity 92dB, Max.SPL 117dB. Rated power 300W, peak power 1200W. -
Page 5: Connection
MU12B CONNECTION MU Series Pro Loudspeaker System MU12B has two Nl4 connectors, one is connected to full range output from amplifier, another one is only for Mu8 connection. Terminal Plate MU12B Warranty does not cover damage caused by incorrect installation, operation or overload. -
Page 6: Loudspeaker Connection
MU12B CONNECTION MU Series Pro Loudspeaker System Speaker Wiring 1. Banana plugs to NL4 Connect to amplifier Connect to speaker 2:NL4至NL4 2. NL4 to NL4 Connect to amplifier Connect to speaker 3. Consumption curve of connection cable(Only for reference, the result is different if adopting the different cables) -
Page 7: Installation
MU12B INSTALLATION MU Series Pro Loudspeaker System Mounting Accessories Installation Reference The support flange in the top of MU12B is for the pole 1. Stack mounting application with MU18. MU12B Warning: Make sure the mounting accessories safety factor not less than 5:1 or meet the local... -
Page 8: Technical Specification
MU12B TECHNICAL SPECIFICATION MU Series Pro Loudspeaker System Specification Speaker Testing Method System: Passive low-frequency speaker 1. Frequency response 1 12"Woofer Woofer: Use Pink noise to test the speaker in the anechoic room, adjust the level to make the speaker work at its rated impedance and... -
Page 9: 2D Dimension
MU12B TECHNICAL SPECIFICATION MU Series Pro Loudspeaker System 2D Dimension Top view 320mm [12.60in] 460mm [18.11in] Side view Front view Back view Bottom view... - Page 10 Notes:...
