Appendix A - System Specifications
Pin
1
2
3
6
Cable must be shielded category 5.
Table 15. RS-232 DB-25 OSS Interface to HMU (DTE) - Male Connector
Pin
2
3
5
6
7
15
17
20
24
Cable must be shielded.
78
Table 14. RJ-45 Pinout for 10BASE-T Interface to HMU (J34)
Description
+XMT
-XMT
+RCV
-RCV
Description
TD
RD
CTS
DSR
GND
TXCLK (DTE)
RXCLK (DCE)
DTR
TXCLK (DCE)
September 29, 2000
output
output
input
input
output
input
input
input
input
input
input
output
output
