- Page 1 Satin Standard, ® Fiber Optic and Disposable Laryngoscope Blades and Handles Directions for Use ®...
-
Page 2: Device Description And Intended Use
American Diagnostic Corp. (ADC ® ), are intended as procedures compatible with specific ma- terials. Sterilization must be performed to approved hospital protocol. ADC ® cannot guarantee that any of the recommended methods will guarantee sterility. This must be validated by the hospital and/or sterilization equipment manufacturer. - Page 3 Optic models are clearly delineated by a green indicator on both handle and blade. Cleaning, Disinfecting, and Sterilization Procedures ® Satin™ Laryngoscope blades are crafted from rugged stainless steel. ADC ® Disposable Fiberoptic Laryngoscope blades are crafted from poly-carbonate, and are for single use only and should not be cleaned or sterilized.
- Page 4 Disinfection/Sterilization Warnings for All Laryngoscope Blades CAUTION: ADC ® laryngoscope blades do not come sterilized. The Sterrad process is NOT to be used with disposable fiberoptic blades or fiberoptic blades. WARNING: Flash autoclaving and hot air sterilization are not recommended, these processes will damage the instrument.
- Page 5 High Level Disinfection for Standard and Fiberoptic Blades To achieve high level disinfection, a 2.4% glutaraldehyde solution (Cidex ® or equivalent) must be prepared at 77°F (25°C) to the manufacturer’ s instructions. The blades should be fully immersed in the disinfectant for a minimum of 45 minutes.
-
Page 6: Repair/Maintenance
Lamp Replacement: (Standard Models) For correct illumination, alignment, and assurance of watertight seal during immersion/ autoclave, we recommend using only ADC #4500-1 and #4501-1 replacement lamps for standard blades. 1) To remove lamp on standard blades, grip lamp collar and rotate lamp counterclockwise until free. -
Page 7: Test Procedures
Lamp Replacement: (Fiberoptic Models) For correct illumination and alignment we recommend using only ADC replacement lamp model #5111N-4 (Figure 4). 1) Prior to removal, allow lamp time to cool. 2) Unscrew the laryngoscope head from the barrel of the handle in a counterclockwise direction. -
Page 8: Replacement Parts Chart
REPLACEMENT PARTS CHART DESCRIPTIONS STANDARD MODELS Laryngoscope Standard Replacement Lamp Standard Blade Item 4070 Mac 0 4500 4071 Mac 1 4500 4072 Mac 2 4500 Mac 3 4073 4501 Mac 4 4074 4501 Miller 00 4080-0 4500 4080 Miller 0 4500 4081 Miller 1... - Page 9 REPLACEMENT PARTS CHART DESCRIPTIONS STANDARD MODELS Laryngoscope Fiberoptic Fiberoptic Fiberoptic Item Replacement Lamp Blade Light Guide Mac 0 4070F 4070FLP-00 Mac 1 4071F 4071FLP-00 Mac 2 4072F 4072FLP-00 Mac 3 4073F 4073FLP-00 Mac 4 4074F 4074FLP-00 Miller 00 Miller 0 4080F 4080FLP-00 Miller 1...
- Page 10 REPLACEMENT PARTS CHART DESCRIPTIONS SPU MODELS Laryngoscope Fiberoptic Item Blade Mac 0 4071D-20 Mac 1 4072D-20 Mac 2 4073D-20 Mac 3 Mac 4 4074D-20 4080-0D-20 Miller 00 Miller 0 4080D-20 Miller 1 4081D-20 Miller 2 4082D-20 4083D-20 Miller 3 Miller 4 4084D-20 Wisconsin 0 Wisconsin 1...
-
Page 11: Limited Warranty
2. Your Laryngoscope is warranted for one year from date of purchase (all parts). What is Covered: Replacement of parts, and labor. What is Not Covered: Transportation charges to and from ADC ® . Damages caused by abuse, misuse, accident, or negligence.
