- Page 1 Pocket Diagnostic Instruments Use, Care, & Maintenance...
-
Page 2: Device Description And Intended Use
Every component has been carefully designed to maximize performance. This booklet refers to both Otoscope and Ophthalmoscope sets (Models 5110N Series, 5110E, 5111N Series, 5112N Series). -
Page 3: Symbol Definitions
Symbol Definitions The following symbols are associated with your diagnostic instrument. LATEX General Warnings A warning statement in this manual identifies a condition or practice which, if not corrected or discontinued immediately, could lead to patient injury, illness, or death. CAUTION: Because prolonged intense light exposure can damage the retina, the use of the device for ocular examination should not be unnecessarily prolonged, and the bright- ness setting should not exceed what is needed to provide clear visualization of the target... - Page 4 WARNING: The carrying cases provided with these devices are intended for long term storage or transport between facilities or when shipping devices to and from ADC’s facility for repair or servicing. Carry cases (including internal liners) can NOT be cleaned or dis- infected and should be safely discarded if contaminated.
- Page 5 Otoscope Parts and Assembly The Pocket Otoscope consists of a “AA” battery handle (#5160N), fiberoptic Otoscope Instrument Head (5120N Series), with attached movable viewing lens, and disposable specula (2.75mm and 4.25mm). Removing and Attaching the Instrument Head Pocket otoscope heads are threaded and can be removed by ro- tating the threaded connection counterclockwise, or attached by rotating the threaded connection clockwise.
- Page 6 Ophthalmoscope Parts and Assembly The Pocket Ophthalmoscope consists of a “AA” battery handle (5160N) and Ophthalmoscope instrument head (5140N Series). Aperture Selection This unit is equipped with 5 internal apertures - small, large, semi- circle, red-free, and fixation. To select, rotate the aperture selection wheel at the front of the instrument head.
-
Page 7: Cleaning And Disinfection
Battery Replacement This unit requires 2 “AA” batteries. For best performance, we suggest alkaline batteries. To replace, remove the battery cap at the base of the handle by turning counterclockwise and replace batteries, taking care to observe correct polarity. NOTE: This instrument should be turned OFF when not in use. If storing for extended lengths of time, remove batteries completely. -
Page 8: Troubleshooting
Isopropyl alchohol may be substituted with commonly used, EPA-registered hospital disinfectant wipes for cleaning purposes if desired. Please refer to the directions provided by the manufacturer of the wipes for appropriate instructions for use to ensure effective contact time between the wipe and the device. It is important to note that solution residue on the magnifying lenses may decrease de- vice performance. - Page 9 Otoscope and accessories Troubleshooting Guide Possible Cause Trouble Area Corrective Action Specula mount is Specula will not attach Service required damaged properly Loose or misaligned Lens mount is Service required magnifying lens damaged Lens is dirty Clean with lint free cloth Poor or obstructed view through lens Lens is damaged...
- Page 10 Ophthalmoscope Troubleshooting Guide Possible Cause Corrective Action Trouble Area Rotate Aperture dial Aperture dial is between Replace the lamp positions Lamp burned out Replace the lamp No light output Replace with fresh “AA” bat- Wrong lamp installed teries Batteries are depleted Lamp not fully inserted Re-insert lamp Instrument head will not...
- Page 11 RH 95 % (Max) 500 hpa – 1060 hpa, Altitude Max. Operating: 35°C (95°F) LIMITED WARRANTY American Diagnostic Corporation (ADC ® ) warrants its products against de- fects in materials and workmanship under normal use and service as follows: 1. Warranty service extends to the original retail purchaser only and commences with the date of delivery.
- Page 12 Devices should be contained in their transport/storage cases when being returned to ADC ® to ensure that they are not damaged during transport and handling. Do not ship contaminated devices or storage cases to ADC ® ’s fa- cility. Send item(s) postage paid to ADC ®...
- Page 13 Inspected, assembled and packaged in the U.S.A. 55 Commerce Drive Components made in Dubai Hauppauge, NY 11788 tel: 631-273-9600 toll free: 1-800-232-2670 ADC (UK) Ltd. fax: 631-273-9659 Unit 6, PO14 1TH www.adctoday.com United Kingdom info@adctoday.com Printed in the U.S.A. IB p/n 9362-00 rev 7...
