- Page 1 The power behind competitiveness Delta UPS - Ultron Family HPH Series, Three Phase 20/30/40 kVA User Manual www.deltapowersolutions.com...
- Page 2 (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc. (“Delta”). The Manual can only be applied to the operation or the use of this product. Any disposition, duplication, dissemination, reproduction, modification, translation, extraction, or usage of this Manual in whole or in part is prohibited without the prior written permission of Delta.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Chapter 1 : Important Safety Instructions ------------------------------------------ 1 Placement Warnings ----------------------------------------------------------------- 1 Connection Warnings ---------------------------------------------------------------- 1 Usage Warnings ---------------------------------------------------------------------- 1 Storage Warnings --------------------------------------------------------------------- 2 Glossary of Symbols ----------------------------------------------------------------- 3 Standard Compliance ---------------------------------------------------------------- 4 Chapter 2 : Introduction ------------------------------------------------------------------ 5 Product Introduction ------------------------------------------------------------------ 5 Package Inspection ------------------------------------------------------------------ 5 Functions and Features ------------------------------------------------------------- 6... - Page 4 Main Menu ---------------------------------------------------------------------------- 46 Measure ------------------------------------------------------------------------------- 47 Maintenance ------------------------------------------------------------------------- 48 Chapter 9 : Optional Accessories ----------------------------------------------------51 Chapter 10 : Maintenance ---------------------------------------------------------------52 Chapter 11 : Troubleshooting ----------------------------------------------------------53 Appendix 1 : Technical Specifications ----------------------------------------------55 Appendix 2 : Warranty --------------------------------------------------------------------57 Ultron HPH Series UPS...
-
Page 5: Chapter 1 : Important Safety Instructions
Chapter 1 Important Safety Instructions Chapter 1 : Important Safety Instructions Placement Warnings Install the UPS in a well-ventilated indoor area, away from excess moisture, heat, dust, flammable gas or explosives. Leave adequate space around all sides of the UPS for proper ventilation. Please refer to 6.2 Installation Environment. -
Page 6: Storage Warnings
Idle batteries must be recharged fully approximately every three months if the UPS needs to be stored for an extended period of time. The charging time must not be less than 24 hours each time. SHUT DOWN YES ( NO ( Ultron HPH Series UPS... -
Page 7: Glossary Of Symbols
Chapter 1 Important Safety Instructions Glossary of Symbols Symbol Description Online mode LED indicator: green NORMAL Battery mode LED indicator: yellow BATTERY Bypass mode LED indicator: yellow BYPASS Fault LED indicator: red FAULT ON key OFF key Goes back to previous screen or cancels current selec- tion. -
Page 8: Standard Compliance
This product meets the following safety standards and electromagnetic compatibility (EMC) inspection standards: IEC62040-1 GB7260.2-2009/ IEC62040-2 C2 GB17626-2/ IEC61000-4-2 (ESD) Level 4 GB17626-3/ IEC61000-4-3 (Radiated Field) Level 3 GB17626-4/ IEC61000-4-4 (EFT) Level 4 GB17626-5/ IEC61000-4-5 (Surge) Level 4 Ultron HPH Series UPS... -
Page 9: Chapter 2 : Introduction
Chapter 2 Introduction Chapter 2 : Introduction Product Introduction The HPH series UPS is a three-phase four-wire online uninterruptible power supply which provides reliable and stable sine-wave power to your electronic devices. The UPS applies the latest design of DSP digital control technology and highest quality assembly, with an output power factor up to unity. -
Page 10: Functions And Features
Please keep them well after unpacking. You might use them for installation. : The cable connects the UPS and a Delta Mini SNMP card, Mini USB card, Mini Relay I/O card, or Mini Modbus card. The above-mentioned cards are op- tional. - Page 11 Chapter 2 Introduction You can parallel at maximum four UPS units for N+X parallel redundancy, capacity expan- sion and reliability enhancement. It is convenient to set the parameters (output voltage, charging current, output frequency and password setting, etc.) on the LCD panel. The operating conditions, such as load, input and output voltage, input and output frequen- cy, battery voltage, of the device are available on LCD so that management personnel can see them accurately and clearly.
-
Page 12: Chapter 3 : Appearance And Mechanism
DRY CONTACT DETECTION AUTHORIZED SERVICE PERSONNEL CAN OPEN AND OPERATE IT. MAIN INPUT BREAKER BYPASS INPUT BREAKER OUTPUT BREAKER AC INPUT UPS OUTPUT 240V DC 240V DC BATTERY INPUT (Figure 3-2: 30/ 40kVA UPS Appearance and Dimensions) Ultron HPH Series UPS... -
Page 13: Front Panel
Chapter 3 Appearance and Mechanism Front Panel NORMAL BATTERY BYPASS FAULT (Figure 3-3: Front Panel) Item Description This indicates that the UPS is operating in online mode and NORMAL the utility AC power is normal. This indicates that the UPS is operating in battery mode and BATTERY the external batteries are discharging. -
Page 14: Rear Panel
Chapter 5 : Communication Interfaces. Parallel Ports For UPS parallel usage. For detailed information, please refer to Chapter 5 : Communication Interfaces. Output Dry Contacts Receive the UPS’s event information. Please refer to Chap- ter 5 : Communication Interfaces. Ultron HPH Series UPS... - Page 15 Chapter 3 Appearance and Mechanism Item Description Input Dry Contacts Receive external information of devices connected to the input dry contacts. Please refer to Chapter 5 : Communi- cation Interfaces. REPO Port When an emergency event occurs, it can disconnect the UPS power supply rapidly and shut down the UPS safely and immediately.
-
Page 16: Chapter 4 : Operation Modes
When the input voltage and frequency of the utility AC power are within the normal range, the UPS runs in standby mode and charges the batteries. The bypass and the inverter have no output. BYPA. LOAD Rectifier Inverter MAIN Batteries (Figure 4-2: Path of Electrical Power through the UPS in Standby Mode) Ultron HPH Series UPS... - Page 17 Chapter 4 Operation Modes eCO Mode You can manually set the UPS to ECO mode. In ECO mode, when the utility input voltage is within the range of rated voltage ±10%, the load is supplied by the utility power and the BYPASS LED indicator ( ) illuminates (yellow);...
- Page 18 The critical load is directly supplied by the utility power and the batteries are charged. During by- pass mode, the BYPASS LED indicator ( ) illuminates (yellow). BYPASS BYPA. LOAD Rectifier Inverter MAIN Batteries (Figure 4-5: Path of Electrical Power through the UPS in Bypass Mode) Ultron HPH Series UPS...
- Page 19 Chapter 4 Operation Modes Converter Mode When the UPS is manually set in converter mode, the output frequency can be set as 50Hz or 60Hz. After the output frequency is set up, the system will automatically disable the bypass func- tion.
-
Page 20: Chapter 5 : Communication Interfaces
ModBus communication functions respectively. MINI Slot This MINI slot is for mini cards. You can install a Delta Mini SNMP, Mini Relay I/O, Mini USB, Mini ModBus, or Mini TVSS card in this slot to give the system network communication, dry contact, USB communication, ModBus communication, and surge protection functions respectively. - Page 21 MINI slot and the UPS’s CNY7 connector if you use a Delta Mini SNMP card, Mini USB card, Mini Relay I/O card, or Mini Modbus card. For installation information, please contact service personnel.
- Page 22 Please refer to the table below. event Description Load on inverter 1. The UPS works in normal mode. 2. Default: Pin 1 & 2 Ultron HPH Series UPS...
- Page 23 Chapter 5 Communication Interfaces event Description Load on bypass 1. The UPS works in bypass mode. 2. Default: Pin 3 & 4 Battery discharge/ 1. When the main AC source fails, it is the batteries to sup- Main input NOK ply power to the equipment loads.
- Page 24 (Figure 5-6: Input Dry Contact Configuration I) Figure 5-7 shows the 2 type of input dry contact configuration. It requires external power with a voltage range between 6~12Vdc. 2K(1206) 2K(1206) +12VSF 2K(1206) 2K(1206) (Figure 5-7: Input Dry Contact Configuration II) Ultron HPH Series UPS...
- Page 25 Chapter 5 Communication Interfaces RePO Port The REPO port is for remote emergency shutdown. When an emergency event occurs, it can dis- connect the UPS power supply rapidly and shut down the UPS immediately. The configuration is shown as follows and it requires external power with a voltage range between 6~12Vdc. (Figure 5-8: REPO Port Configuration) Charger Detection Port The charger detection port is used to connect with an external charger box.
-
Page 26: Chapter 6 : Installation And Wiring
If you want to install the UPS by yourself, installation must be under the supervision of authorized Delta engineers or service personnel. If you use a forklift or other equipment to move the UPS, please make sure its load bearing is sufficient. For the weight of the UPS, please refer to Appendix 1 : Technical Specifications. -
Page 27: Ups Transportation & Handling
Chapter 6 Installation and Wiring UPS Transportation & Handling There are four casters at the bottom of the UPS. Please pay attention to the movement of the casters to avoid accidents when you remove the UPS from its pallet. The casters are designed to move on level ground. - Page 28 UPS on the ground and use the M6 screws to reinstall the balance supports (that have been removed from the UPS during the unpacking process) on the UPS. Please refer to the figure below. M6 Screw x 8 Balance Support x 4 (Figure 6-3: Balance Support Installation) Ultron HPH Series UPS...
-
Page 29: Wiring
6.5.1 Precautions Prior to Wiring The wiring must be performed by qualified professional personnel. If you want to install the UPS by yourself, installation must be under the supervision of authorized Delta engineers or service personnel. Before wiring or making any electrical connection, make sure the power supplied to the in- put and output of the UPS is completely cut off. - Page 30 When connecting with the external battery cabinet, please confirm the polarity. Do not re- verse the polarity. The grounding cable of the external battery cabinet must be connected to the ( ) termi- nal of the battery terminal block. Ultron HPH Series UPS...
-
Page 31: 6.5.2 Single Input/ Dual Input Modification
AC Input Block's neutral (N) terminal. 6.5.2 Single Input/ Dual Input Modification WARNING: 1. Only authorized Delta engineers or service personnel can modify single input/ dual input setup. 2. For dual input, the main AC source’s Neutral (N) must be connected with the by- pass source’s Neutral (N). - Page 32 UPS OUTPUT AC INPUT UPS OUTPUT 240V DC 240V DC 240V DC 240V DC BATTERY INPUT BATTERY INPUT (Figure 6-6: Remove the Four Cables that Connect the AC Input Terminal Block and the Main Input Breaker) Ultron HPH Series UPS...
-
Page 33: 6.5.3 Single Unit Wiring
Chapter 6 Installation and Wiring 2. Or remove the four cables that connect the AC input terminal block and the bypass input breaker (please see Figure 6-7). When wiring, connect the bypass source’s R, S, T and N cables to the bypass input breaker. (20kVA Model) (30/ 40kVA Model) MAIN INPUT BREAKER... - Page 34 (N) terminals. For the UPS ground- Includes one grounding terminal. UPS Output Connects the critical Includes three-phase (R, S, T) and Terminal Block loads. neutral (N) terminals. For the critical loads’ Includes one grounding terminal. grounding Ultron HPH Series UPS...
- Page 35 Chapter 6 Installation and Wiring No. Item Function Description Battery Input Connects an external Includes three terminals, positive Terminal Block battery cabinet. (+), negative (-) and neutral (N). For the external bat- Includes one grounding terminal. tery cabinet’s ground- The UPS rating voltage is 220/ 380Vac, 230/ 400Vac or 240/ 415Vac, and the battery rating voltage is ±240Vdc.
- Page 36 When there are two AC power sources, single unit wiring procedures are as follows. Follow 6.5.2 Single Input/ Dual Input Modification to modify the UPS into dual in- put. Please note that only authorized Delta engineers or service personnel can modi- fy single input/ dual input setup.
- Page 37 Chapter 6 Installation and Wiring (20kVA Model) R S T N MAIN INPUT BREAKER BYPASS INPUT BREAKER OUTPUT BREAKER (*CS: 4-Pole Contactor Contactor Solenoid) R S T N Protective Device AC INPUT UPS OUTPUT 240V DC 240V DC BATTERY INPUT R S T N Connects the bypass source For the external...
- Page 38 Protective Solenoid) For the UPS Device R S T N grounding( ) (Disconnect Device) Protective Device R S T N Connects the bypass source (Figure 6-14: 30/ 40kVA UPS Single Unit Dual Input Wiring II Diagram) Ultron HPH Series UPS...
-
Page 39: 6.5.4 Parallel Units Wiring
Chapter 6 Installation and Wiring 6.5.4 Parallel Units Wiring NOTe: Prior to wiring, please read 6.5.1 Precautions Prior to Wiring first. Single Input (Parallel Units) When there is only one AC power source, parallel unit's wiring procedures are as follows. Please follow steps stated in section Single Input (Single Unit). - Page 40 When there are two AC power sources, parallel units’ wiring procedures are as follows. Follow 6.5.2 Single Input/ Dual Input Modification to modify the UPS into dual in- put. Please note that only authorized Delta engineers or service personnel can modi- fy single input/ dual input setup.
-
Page 41: External Battery Cabinet Connection Precautions
Chapter 6 Installation and Wiring WARNING: 1. When UPSs are paralleled, the length of each unit’s input cables/ output ca- bles must be equal. This ensures that the parallel UPSs can equally share the equipment loads in bypass mode. 2. Only UPSs with the same capacity, voltage and frequency can be paralleled; otherwise, parallel functions will fail. - Page 42 To extend battery backup time, you can connect several external battery cabinets to the UPS. When connecting a non-Delta external battery cabinet to the UPS, it is compulsory to in- stall an appropriate non-fuse DC breaker and fast-acting fuses (when short-circuit occurs, the melting current must be 5~6 times of the battery fuse’s rating current).
- Page 43 The breaker must be a 4-pole non-fuse DC breaker with characteristics of 1-pole 250Vdc, 2-pole 500Vdc and 3-pole 750Vdc. Please follow Figure 6-17 or Figure 6-18 to install a 4-pole non-fuse DC breaker and fast-acting fuses between the UPS and the non-Delta ex- ternal battery cabinet.
- Page 44 21 batteries. You should use three cables to connect a non-Delta external battery cabinet with the ‘+’, ‘-’ and ‘N’ termi- nals marked on the UPS. When connecting a non-Delta external battery cabinet with the UPS, you must install an appropriate 4-pole non-fuse DC breaker and fast-acting fuses.
-
Page 45: Chapter 7 : Operation
Chapter 7 Operation Chapter 7 : Operation Connecting the UPS with the Utility AC Power Connect the UPS with an external battery cabinet, and switch the battery cabinet’s switch/ breaker to the ON position. Switch on the bypass input breaker and press the ON key ( ) to start the LCD. - Page 46 YES ( NO ( WARNING: You can remove the UPS only after the screen on the LCD is off, the fans stop run- ning, the utility AC power is shut off and the batteries are removed. Ultron HPH Series UPS...
-
Page 47: Chapter 8 : Lcd Display And Settings
Chapter 8 LCD Display and Settings Chapter 8 : LCD Display and Settings LCD Display Hierarchy (Level 1) (Level 1) (Level 1) ALARM/ FAULT PARALLEL SCREEN MAIN SCREEN INFORMATION (Level 2) MAIN MENU (Level 3) (Level 3) MEASURE MAINTENANCE (Level 4) (Level 4) MODEL NAME MAINS... -
Page 48: Main Screen
When the screen above appears, it means that the UPS is in bypass mode. The main AC source and the batteries are off. If the bypass AC source fails, the critical loads won’t be pro- tected. Ultron HPH Series UPS... -
Page 49: Parallel Screen
Chapter 8 LCD Display and Settings When the screen above appears, it means that the UPS is in normal mode. When the screen above appears, it means that the UPS is in battery mode. When the screen above appears, it means that the UPS is in manual bypass mode. Before maintenance, do not forget to switch the UPS into manual bypass mode and cut off the main AC source and batteries. -
Page 50: Main Menu
Check the UPS’s mains, bypass, inverter, output, battery, temperature and DC BUS read- ings. MAINTeNANCe Check the UPS’s model name, serial number, firmware version, statistics, event log, real time clock, control & test, and language setup. User can set up the last two items. Ultron HPH Series UPS... -
Page 51: Measure
Chapter 8 LCD Display and Settings Measure Route: Main Screen Main Menu Measure Use the function keys ( ) and ( ) to check the UPS’s mains, bypass, inverter, output, battery, temperature and DC BUS readings. Please refer to the charts below. 1.1 MAINS 1.7 DC BUS VPHASE(V) -
Page 52: Maintenance
The screen above shows the UPS’s serial number. Firmware Version Route: Main Screen Main Menu Maintenance 2.3 Firmware Version 2.3 FIRMWARE VERSION INV & SYSTEM The screen above shows the PFC and the INV & SYSTEM’s firmware version. Ultron HPH Series UPS... - Page 53 Chapter 8 LCD Display and Settings Statistics Route: Main Screen Main Menu Maintenance 2.4 Statistics 2.4 STATISTICS RUN TIME DD HH: MM: SS ON BAT COUNTS ON BYPASS COUNTS 2.4 STATISTICS TOTAL OF EVENT LOG 1. RUN TIMe (DD HH: MM: SS): The UPS’s total running time. 2.
- Page 54 2. BeeP eNABLe: Enable or disable buzzer. Language Setup Route: Main Screen Main Menu Maintenance 2.8 Language Setup 2.8 LANGUAGE SETUP LANGUAGE ENGLISH You can change the display language. The default setting is eNGLISH. Ultron HPH Series UPS...
-
Page 55: Chapter 9 : Optional Accessories
Chapter 9 Optional Accessories Chapter 9 : Optional Accessories There are several optional accessories available for this HPH series UPS. Please refer to the table be- low for the optional accessories and their descriptions. Item Function Dust Filter Prevents dust from entering into the UPS to ensure UPS reliabil- ity and to prolong product life. -
Page 56: Chapter 10 : Maintenance
UPS. If not, re- place the fans. NOTe: Please ask your local dealer or customer service for more maintenance information. Do not perform maintenance if you are not trained for it. Ultron HPH Series UPS... -
Page 57: Chapter 11 : Troubleshooting
Chapter 11 Troubleshooting Chapter 11 : Troubleshooting When you see the following problems appear on the LCD, please follow the solutions shown below. No. Alarm Message Possible Cause Solution SHORT CIRCUIT Output has a short circuit issue. Contact service personnel. INVERTER FAIL Inverter is damaged. - Page 58 PUT SCR SHORT 2. Inverter SCR is damaged. BATTERY LOW Battery voltage is low. Charge the batteries. SHUTDOWN NOTe: If all possible causes are eliminated but the alarm still appears, please contact your local dealer or customer service. Ultron HPH Series UPS...
-
Page 59: Appendix 1 : Technical Specifications
Appendix 1 Technical Specifications Appendix 1 : Technical Specifications Model HPH-20K HPH-30K HPH-40K Power Rating 20kVA/20KW 30kVA/30KW 40kVA/40KW Waveform Sine Wave Nominal Voltage 220/380 Vac; 230/400 Vac; 240/415 Vac Voltage Range 300 ~ 477 Vac (100% load) Frequency 50/60 Hz Input Frequency Range 45 ~ 65 Hz... - Page 60 Temperature Environment Ambient Storage -20 ~ 50°C Temperature Relative Humidity 5% ~ 95% (non-condensing) NOTe: 1. Please refer to the rating label for the safety rating. 2. All specifications are subject to change without prior notice. Ultron HPH Series UPS...
-
Page 61: Appendix 2 : Warranty
Appendix 2 Warranty Appendix 2 : Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from origi- nal defects in material and workmanship within the warranty period. If the product has any failure prob- lem within the warranty period, Seller will repair or replace the product at its sole discretion according to the failure situation. - Page 64 5012332300...
