- Page 1 The power behind competitiveness Delta UPS Amplon Family RT Gen3 Series, Single Phase 1/ 2/ 3 kVA User Manual www.deltaww.com...
- Page 2 User Manual (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc. (“Delta”). The Manual can only be applied to the operation or the use of this product. Any disposition, duplication, dissemination, reproduction, modification, translation, extraction, or usage of this Manual in whole or in part is prohibited without the prior written permission of Delta.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 : Important Safety Instructions ---------------------- 1 Installation Warnings ---------------------------------- 1 Connection Warnings ---------------------------------- 1 Usage Warnings ---------------------------------------2 Storage ------------------------------------------------3 Standard Compliance ----------------------------------4 Chapter 2 : Introduction -------------------------------------- 5 General Overview -------------------------------------5 Package Inspection ------------------------------------5 Operating Principe ------------------------------------- 7 Exterior &... - Page 4 LCD Display Wordings Index ------------------------- 27 UPS Setting ----------------------------------------- 28 Operation Modes ------------------------------------ 33 Fault Reference Code-------------------------------- 34 Warning Indicator ------------------------------------ 35 Chapter 6 : Optional Accessories ---------------------------- 36 Chapter 7 : Troubleshooting --------------------------------- 37 Chapter 8 : Maintenance ------------------------------------ 40 Appendix 1 : Technical Specifications ----------------------- 42 Appendix 2 : Warranty --------------------------------------- 48 Amplon RT Gen3 Series...
-
Page 5: Chapter 1 : Important Safety Instructions
Do not connect domestic appliances such as hair dryers to the UPS’s out- put sockets. It is not recommended to connect the UPS with the following types of loads. For the load suitability, please contact Delta customer service before purchasing. 1. regenerative loads (e.g. CNC machines and lifts) 2. -
Page 6: Usage Warnings
Please only use the VDE-tested and CE-marked power cables to connect the loads to the UPS. When installing the equipment, please ensure that the sum of the leakage current of the UPS and the connected devices does not exceed 3.5 mA. Usage Warnings Only qualified service personnel can upgrade the UPS’s firmware. -
Page 7: Storage
Only qualified personnel can perform battery replacement. Unauthorized personnel shall be kept away from the batteries. WARNING: Risk of electric shock! The battery circuit is not isolated from the input voltage. Hazardous voltage may occur between the battery terminals and the ground. Do not dispose of the battery or batteries in a fire. -
Page 8: Standard Compliance
After usage: Press and hold the OFF/ ENTER button for at least 2 seconds to turn off the UPS. Make sure the UPS is completely shut down, disconnect the UPS from the utility AC power, remove all loads from the UPS and store the UPS in a dry and well-ventilated indoor area at a temperature of between -20°C (-4°F) and 50°C (122°F) and at a relative humidity (non-condensing) between 10% and 90%. -
Page 9: Chapter 2 : Introduction
There are two models for selection to meet different backup time requirements, which are standard and extended runtime. For the extended runtime model, it can connect to the optional Delta external battery pack. The unit provides output power factor up to 0.9, which produces greater electric power efficiency at low cost. - Page 10 Item Q’ty UPS* 1 PC Input Cable 1 PC USB Cable 1 PC User Manual 1 PC 1 Set Battery Cable Kit (including battery cable × 1 PC, M5 screw × 2 PCS and (for extended runtime model only) M5 nut × 2 PCS) 1 Set Ear Bracket Kit (including M4 screw ×...
-
Page 11: Operating Principe
2.3 Operating Principe The operating principle of the UPS is shown as follows. (Figure 2-1: System Block Diagram) 2.4 Exterior & Dimensions 310 mm (12.2") 86 mm (3.4") 438 mm (17.2") (Figure 2-2: Exterior & Dimensions_ 1kVA) - Page 12 410 mm (16.1") 86 mm (3.4") 438 mm (17.2") (Figure 2-3: Exterior & Dimensions_ 2kVA) Standard Runtime Model 630 mm (24.8") 86 mm (3.4") 438 mm (17.2") Amplon RT Gen3 Series...
-
Page 13: Front View
Extended Runtime Model 460 mm (18.1") 86 mm (3.4") 438 mm (17.2") (Figure 2-4: Exterior & Dimensions_ 3kVA) Front View Operation Panel (Figure 2-5: Front View) -
Page 14: Rear View
Rear View Standard Runtime Model UPA102R2RX0B0BA INPUT CIRCUIT BREAKER OUTPUT 10A MAX. INPUT 10A MAX. EXTERNAL BATTERY 24VDC,50A MAX. UPA202R2RX0B0BA EXTERNAL BATTERY 48VDC,50A MAX. OUTPUT OUTPUT 10A MAX. 16A MAX. REPO INPUT INPUT 10A MAX. CIRCUIT BREAKER UPA302R2RX0B0BA EXTERNAL BATTERY INPUT 16A MAX. - Page 15 UPA102R2RX0B035 INPUT CIRCUIT BREAKER OUTPUT 10A MAX. INPUT 10A MAX. UPA202R2RX0B035 OUTPUT OUTPUT 10A MAX. 16A MAX. INPUT INPUT 10A MAX. CIRCUIT BREAKER UPA302R2RX0B035 INPUT 16A MAX. OUTPUT 16A MAX. OUTPUT 10A MAX. INPUT CIRCUIT BREAKER...
- Page 16 UPA102R2RX0B0B1 INPUT CIRCUIT BREAKER OUTPUT 10A MAX. INPUT 10A MAX. EXTERNAL BATTERY 24VDC,50A MAX. UPA202R2RX0B0B1 EXTERNAL BATTERY 48VDC,50A MAX. OUTPUT 10A MAX. INPUT INPUT 10A MAX. CIRCUIT BREAKER UPA302R2RX0B0B1 OUTPUT INPUT 16A MAX. EXTERNAL BATTERY 20A MAX. 72VDC,50A MAX. INPUT CIRCUIT BREAKER Amplon RT Gen3 Series...
- Page 17 Extended Runtime Model UPA102R2RX2N035/ UPA102R2RX2N0B0 INPUT CIRCUIT BREAKER OUTPUT 10A MAX. EXTERNAL BATTERY 36VDC,50A MAX. MINI SLOT RS 232 INPUT 10A MAX. UPA202R2RX2N035/ UPA202R2RX2N0B0 INPUT CIRCUIT BREAKER OUTPUT 16A MAX. OUTPUT 10A MAX. EXTERNAL BATTERY 72VDC,50A MAX. MINI SLOT RS 232 INPUT 16A MAX.
- Page 18 Item AC Input Socket Input Circuit Breaker USB Port RS-232 Port Mini Slot External Battery Pack Connector Output Receptacles REPO Port Amplon RT Gen3 Series...
-
Page 19: Chapter 3 : Installation
Chapter 3 : Installation NOTE : 1. Before installation, please read Chapter 1. Important Safety Instructions thoroughly. 2. Only qualified personnel can perform installation. If you want to install the UPS by yourself, installation must be under the supervision of qualified personnel. 3. - Page 20 Adjust the rails’ length according to your rack and tighten the nuts. (Figure 3-2: Adjust the Rails’ Length and Tighten the Nuts) Use the eight screws and eight washers to attach the rails to your rack. (Figure 3-3: Attach the Rails to Your Rack) Amplon RT Gen3 Series...
-
Page 21: Tower Mounting
Insert the UPS into the rack and tighten the four screws. (Figure 3-4: Insert the UPS into Your Rack) 3.2 Tower Mounting Assemble the provided tower stands. (Figure 3-5: Assemble the Tower Stands) - Page 22 Place the UPS upright and install it inside the tower stands (at least two people are required). After that, follow shown in the figure below to rotate the operation panel. (Figure 3-6: Place the UPS Inside the Tower Stands & Rotate the Operation Panel) Amplon RT Gen3 Series...
-
Page 23: Chapter 4 : Connection
Chapter 4 : Connection UPS Connection & Setup Battery Cable Connection (for Standard Runtime Model only) The UPS (standard runtime model only) is shipped out from the factory without connecting the battery cable for safety consideration. Before installing the UPS, please follow the steps below to connect the battery cable first. - Page 24 To allow shutdown, start-up and status monitoring for unattended UPS, connect one end of the communication cable to the USB port or RS- 232 port and the other to the communication port of your PC. With the monitoring software installed (http://datacenter-softwarecenter.deltaww. com), you can schedule shutdown and start-up of the UPS and monitor the UPS status via your PC.
-
Page 25: Battery Replacement (For Standard Runtime Model Only)
Turn-on of the UPS Press the ON/ Mute button on the front operation panel for two seconds to power on the UPS. NOTE: The UPS will be available for full runtime capability after the initial five-hour charging Installation of Software For optimal system protection, install the UPS monitoring software to fully configure the UPS. - Page 26 Unscrew the two screws and pull Replace the battery pack with out the battery pack. a new one. Install the new battery pack and Reconnect the battery cable. secure the two screws. Re-install the battery cover. Amplon RT Gen3 Series...
-
Page 27: Chapter 5 : Operation
Chapter 5 : Operation Multi-function Buttons Multi-function Function Button Turn on the UPS: Press and hold the ON/ MUTE button for at least 2 seconds to turn on the UPS. Mute the alarm: When the UPS is in battery mode, press and hold this button for at least 5 seconds to disable or enable the alarm system. -
Page 28: Lcd Panel
Multi-function Function Button Switch LCD message: Press this button to change the LCD message for input voltage, input frequency, battery voltage, output voltage and output frequency. It will re- turn to default display when pausing for 10 seconds. SELECT Setting mode: Press and hold this button for 5 seconds Button to enter setting mode when the UPS is in standby mode or bypass mode. - Page 29 Display Function Remaining backup time information Indicates the remaining backup time in a pie chart. Indicates the remaining backup time in numbers. H: hour, M: minute, S: second Fault information Indicates that the warning/ fault occurs. Indicates the warning/ fault code. The code is listed in detail in 5.7 Fault Reference Code Mute operation...
-
Page 30: Audible Alarm
Display Function Indicates that the bypass circuit is working. Indicates that the ECO mode is enabled. Indicates that the inverter circuit is working. Indicates that the output is working. Battery information Indicates the battery level by 0-25%, 26-50%, 51-75%, and 76-100%. Indicates that batteries have faults. -
Page 31: Lcd Display Wordings Index
5.4 LCD Display Wordings Index Abbreviation Display Content Meaning Enable Disable Escape High loss Low loss Battery Converter Temperature Charger Bypass frequency unstable EEPROM error... -
Page 32: Ups Setting
UPS Setting There are three parameters to set up the UPS. Parameter 1 Parameter 2 Parameter 3 Parameter 1: It is for function selection. Refer to the table below. Parameter 2 and Parameter 3 are the setting options or values for each program. - Page 33 02: Enable/ disable frequency converter Parameter 2 & 3: Enable or disable frequency converter mode. You may choose the following two options. CF ENA: enable frequency converter mode CF DIS: disable frequency converter mode (default) 03: Output frequency setting Parameter 2 & 3: Set the output frequency. If the battery mode is enabled, you may choose the following initial frequency.
- Page 34 04: Enable/ disable ECO Parameter 3: Enable or disable ECO function. You may choose the following two options. ENA: enable ECO mode DIS: disable ECO mode (default) 05: ECO voltage range setting Parameter 2 & 3: Set an acceptable high voltage point and a low voltage point for ECO mode by pressing the ON/ MUTE or SELECT button.
- Page 35 06: Enable/ disable bypass when the UPS is off Parameter 3: Enable or disable bypass function. You may choose the following two options. ENA: enable bypass DIS: disable bypass (default) 07: Bypass voltage range setting Parameter 2 & 3: Set an acceptable high voltage point and a low voltage point for bypass mode by pressing the ON/ MUTE or SELECT button.
- Page 36 Parameter 3: Set the total battery Ah value of the UPS (unit: Ah). 7 ~ 999: Set the total battery capacity from 7 to 999. Please set this figure if the Delta external battery pack is connected. If the UPS is standard runtime model, the default setting is 9 Ah.
-
Page 37: Operation Modes
00: Exit Setting Exit the setting mode. Operation Modes Online Mode When the input voltage is within the acceptable range, the UPS will provide pure sine wave and stable AC power to output. The UPS will also charge the batteries in online mode. -
Page 38: Fault Reference Code
Battery Mode When the input voltage is beyond the acceptable range or a power failure occurs, the UPS will have backup power from the batteries and an alarm will sound every 4 sec- onds. Bypass Mode When the input voltage is within the acceptable range but the UPS is overloaded, the UPS will enter bypass... -
Page 39: Warning Indicator
Fault Code Icon Inverter output short Battery voltage too high Battery voltage too low Over temperature Overload Charger failure Warning Indicator Warning Icon (flashing) Alarm Low battery Sounding every second Sounding twice every Overload second Battery is not connected Sounding every second Over charge Sounding every second Over temperature... -
Page 40: Chapter 6 : Optional Accessories
Increase of the dry contact number. Card Mini MODBUS Provision of the MODBUS communication func- Card tion for the UPS. Delta External Provision of backup power to the UPS when Battery Pack power outages occur. Rail Kit Installation of the UPS in a rack. -
Page 41: Chapter 7 : Troubleshooting
Chapter 7 : Troubleshooting 1. When a problem occurs, please check if the following situation exists before contacting Delta service personnel. Is the main input voltage present? 2. Please have the following information ready if you would like to contact the Delta service personnel. - Page 42 Problem Possible Cause Solution Remove excess loads The UPS is overloaded. from the UPS output. The UPS is overloaded. Devices connected to the The icons Remove excess loads UPS are fed directly by from the UPS output. flash on the LCD the electrical network via display and the alarm the bypass.
- Page 43 Problem Possible Cause Solution Charge the batteries for at least 5 hours Batteries are not fully and check the bat- charged. tery capacity. If the Battery backup time is problem still exists, shorter than nominal consult your dealer. value. Contact your dealer Batteries are damaged.
-
Page 44: Chapter 8 : Maintenance
Chapter 8 : Maintenance NOTE: Please ask your local dealer or customer service for more maintenance information. Do not perform maintenance if you are not trained for it 1. UPS Cleaning Regularly clean the UPS, especially the slits, openings and filters (if any), to ensure that the air freely flows into the UPS to avoid overheating. - Page 45 1. Keep the usage temperature at 20°C ~ 25°C (68°F ~ 77°F). 2. When the UPS needs to be stored for an extended period of time, the lead-acid batteries must be recharged once every three months and the charging time must not be less than 24 hours each time. As for the lithium-ion and other batteries, please contact your battery supplier for the charging frequency and charging duration.
-
Page 46: Appendix 1 : Technical Specifications
Appendix 1 : Technical Specifications Standard Runtime Model Model RT-1K RT-2K RT-3K 1kVA/ 2kVA/ 3kVA/ Capacity 0.9kW 1.8kW 2.7kW 120 ~ 300 Vac (based on load at 50%) Voltage Range 180 ~ 280 Vac (based on load at 100%) Frequency 40 ~ 70 Hz Range Input... - Page 47 Model RT-1K RT-2K RT-3K Short-circuit 25A, 100 ms 50A, 100 ms 80A, 100 ms Current (RMS) Current 3:1 (max.) Crest Ratio Output (continued) ≤ 3% THDv (linear load); Harmonic Distortion ≤ 6% THDv (non-linear load) Waveform Pure sine wave (Battery Mode) Online Mode Efficiency ECO Mode...
- Page 48 Model RT-1K RT-2K RT-3K Noise Level ≤ 50 dBA (1 meter (3.28 ft)) Operating 0 ~ 3000 meters (0 ~ 9842.52 ft)* Altitude Storage -20 ~ 50°C (-4 ~ 122°F) Environment Temperature (continued) Storage 5 ~ 95% Humidity Ingress Protection (IP) IP20 Class 310 ×...
- Page 49 Model RT-1K RT-2K RT-3K Nominal 208* /220/230/240 Vac Voltage Voltage ± 1% (battery mode) Regulation Frequency Range 50/60Hz ± 0.5 % (Online Mode) Frequency Range 50/60Hz ± 0.5 % (Battery Mode) Ambient temperature < 35°C (95°F) 105% ~ 110%: the UPS shuts down after 10 minutes in battery mode or transfers to bypass mode when the utility is normal.
- Page 50 Model RT-1K RT-2K RT-3K Depending on applications Battery Type (optional Delta external battery pack is available) Battery Battery Voltage Charging 1A/2A/4A/6A (default) Current* Communication Interfaces USB port* /RS-232 port* /Mini slot IEC Pollution PD 2 Degree (PD) Compliance Over Voltage...
- Page 51 Model RT-1K RT-2K RT-3K 310 × 438 × 410 × 438 × 460 × 438 × 86 mm 86 mm 86 mm Dimensions W × D × H (12.2” × 17.2” (16.1” × 17.2” (18.1” 17.2” Physical × 3.5”) × 3.5”) ×...
-
Page 52: Appendix 2 : Warranty
Appendix 2 : Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship within the warranty period. If the product has any failure problem within the warranty period, Seller will repair or replace the product at its sole discretion according to the failure situation. - Page 55 - Regional Office U.S.A Australia Delta Electronics (Americas) Ltd. Delta Energy Systems Australia Pty Ltd. 46101 Fremont Blvd. Fremont, CA 94538 Unit 20-21, 45 Normanby Road, Notting Hill VIC 3168, Australia T +1 510 344 2157 T +61 3 9543 3720 E ups.na@deltaww.com...
