DD+DIS015.02E
3.4
Safety switch (1) Open the doors of the digitizer
Air filter
3.5
General
cPCI fan
Edition 1, Revision 1

Power Unit

·
Soft cloth
·
Air filter
(CM+9.5146.1799.2)
while the machine is switched
on.
(2) As soon as the left door is
opened only a little, all
assemblies except the cPCI-
Rack and its fan must be
deenergized.
(3) Exchange air filter right-side
door by drawing it out of its
hold (see beside).

cPCI-Rack

·
Vacuum cleaner
·
Soft cloth
·
Air filter
(CM+9.5146.1799.2)
(1) Remove visible dust and dirt
with the vacuum cleaner.
(2) Open the doors when the
machine is switched on.
(3) The power supply of the cPCI-
Rack and its fan must still be
on.
ADC Compact Plus
(Type 5146 / 100/200)
Maintenance
514512AL.CDR
Figure 3
Figure 4
Figure 5
Chapter 9 / 7
