Panasonic EP-MA20KU Operating Instructions Manual page 18

1 Body scanning will commence when the program is selected.
• The body scanning will properly detect height ranges between approximately 55 and 72.8 in. (140 and 185 cm).
Sit as far back in the seat as possible
with your head on the pillow.
1
2
Adjust the pillow height
3
so that the bottom edge
4
of the pillow is at ear level.
See page 29.
1 NECK (Neck)
2 S HOULDER (Shoulder)
2 Approximately 30 seconds after the body scanning starts, the massage heads slowly lower to the
shoulder position, and a soft tapping action begins to determine your shoulder position.
Massage Head
Tapping
action
3 Confirm that the shoulder position has been correctly determined according to the position of the
soft tapping.
• When the shoulder position is incorrect, adjust the shoulder position while the soft tapping is in progress (for
approximately 15 seconds), and use the POSITION button to move the massage heads up or down.
<Controller cover opened>
Body scanning is completed when the tapping finishes.
4
• The legrest adjusts automatically so that the soles of the feet
touch the footrest wells according to your estimated height based
on the shoulder position.
• If the shoulder position is off drastically, turn the power off once,
and repeat from Step 1 with shoulder firmly pressed against the
backrest.
17
3 MIDDLE (Back)
4 L OWER (Lower back)
A single press of
the button will
raise or lower the
massage heads
approximately
1/2 in. (1.2 cm).
The unit will automatically recline to the correct
massage position.
Correct Massage Position
Raised
approx. 50°
• If the massage lounger is reclined further than the
massage position angle, it will not automatically return
to the correct massage position.
• Keep your head on the pillow until the soft tapping
begins. Lifting your head from the pillow will result
in incorrect determination of the shoulder position.
Reclined
approx. 12°
Too high
Correct position of
the massage head
(The point where the
tapping action should
be felt.)
Too low
