NordicTrack Commercial 2450 User Manual
  1. Manuals
  2. Brands
  3. NordicTrack Manuals
  4. Treadmill
  5. 2450 Treadmill
  6. User manual

NordicTrack Commercial 2450 User Manual

Hide thumbs Also See for Commercial 2450:
Table of Contents

Advertisement

Quick Links

nordictrack.com
Model No. NTL17122.2
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today, go
to my.nordictrack.com.
MEMBER CARE
For service at any time, go to
support.nordictrack.com.
Or call 1-833-680-IFIT
(1-833-680-4348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for NordicTrack Commercial 2450

Summary of Contents for NordicTrack Commercial 2450

  • Page 1 Serial Number Decal REGISTER YOUR PRODUCT To register your product and activate your warranty today, go to my.nordictrack.com. MEMBER CARE For service at any time, go to support.nordictrack.com. Or call 1-833-680-IFIT (1-833-680-4348) Mon.–Fri. 6 a.m.–6 p.m. MT Sat.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. NORDICTRACK and IFIT are registered trademarks of iFIT Inc. Google Maps is a trademark of Google LLC. The Bluetooth ®...

  • Page 3: Important Precautions

    6. Use the treadmill only as described in this purchase a surge suppressor, see your local manual. NORDICTRACK dealer, call the telephone number on the front cover of this manual, or 7. The treadmill is intended for home use only.
  • Page 4 19. Read, understand, and test the emergency 26. When folding or moving the treadmill, make stop procedure before using the treadmill sure that the storage latch is holding the (see HOW TO TURN ON THE POWER on frame securely in the storage position. Do page 19).
  • Page 5 STANDARD SERVICE PLANS...

  • Page 6: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK ® reading this manual, please see the front cover of this COMMERCIAL 2450 treadmill. The COMMERCIAL manual. To help us assist you, note the product model 2450 treadmill provides an impressive selection of fea- number and serial number before contacting us.

  • Page 7: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 8: Assembly

    ASSEMBLY 1. To use the assembly steps in this manual, first see the helpful tips below. • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the •...
  • Page 9 2. Make sure that the power cord is unplugged. Identify the Right Upright (114), and lay it near the Base (118) as shown. Next, connect the Belly Pan Wire (96) to the Upright Wire (120) in the Right Upright (114). The connectors should slide together eas- ily and snap into place with an audible click.
  • Page 10 4. Do not pinch the Wires (119, 120) during this step. With the help of a second person, hold the handrail assembly (D) on the Left and Right Uprights (113, 114). Attach the handrail assembly with four 3/8" x 2 3/4" Screws (2) and four 3/8"...
  • Page 11 6. Identify the Right Inner Grip (102), and attach it to the right side of the handrail assembly (D) with four #8 x 3/4" Screws (4); start all four Screws, and then tighten them. Do not overtighten the Screws. Attach the Left Inner Grip (101) to the left side of the handrail assembly (D) in the same way.
  • Page 12 8. Have a second person hold the console assem- bly (E) near the handrail assembly (D). Connect the wires (F) from the console assembly (E) to the wires (G) from the handrail assembly (D). The connectors should slide together easily and snap into place with an audible click.
  • Page 13 10. Rotate the console assembly (E) back to its original position. Firmly tighten the two M6 x 25mm Screws (8) that you attached in step 8. Next, identify the Right Pivot Cover (137). Attach the Right Pivot Cover to the Console Pivot Bracket (138) with an M4 x 20mm Screw (6);...
  • Page 14 12. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (74) to the position shown. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 14 is completed.
  • Page 15 14. Remove the 5/16" Nut (49) and the 5/16" x 2 1/4" Bolt (27) from the bracket on the Latch Crossbar (76). 49 K Next, align the upper end of the Storage Latch (75) with the bracket on the Latch Crossbar (76), and insert the 5/16"...
  • Page 16 Keep the included hex keys in a secure place; one of the hex keys is used to adjust the walking belt (see pages 31 and 32). Note: Extra hardware may be included. To register your product and activate your warranty today, go to my.nordictrack.com.

  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical Use a Surge Suppressor devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into Your treadmill, like other electronic equipment, can be an outlet on the same circuit.
  • Page 18 CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the speed and incline of the treadmill with The advanced treadmill console offers a selection of the touch of a button. As you exercise, the console will features designed to make your workouts more effec- display instant exercise feedback.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 20 HOW TO SET UP THE CONSOLE 5. Calibrate the incline system. Before using the treadmill for the first time, set up the First, touch the menu button (three horizontal lines console. symbol), touch Settings, touch Maintenance, touch Calibrate Incline, and then touch Begin to calibrate 1.
  • Page 21 HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the incline increase and decrease buttons or one of the See HOW TO TURN ON THE POWER on page 19.
  • Page 22 6. Turn on the fan if desired. HOW TO USE A FEATURED WORKOUT The fan features several Note: To use a featured workout, the console must speed settings. Press the be connected to a wireless network (see HOW TO fan buttons repeatedly to CONNECT TO A WIRELESS NETWORK on page 27).
  • Page 23 4. Start the workout. 5. Use headphones if desired. Touch Start Workout to start the workout. Turn on your Bluetooth headphones and place them near the console. Then touch Connect to During some workouts, an iFIT coach will guide Audio Device and select your headphones from the you through a video workout.
  • Page 24 3. Draw your map. HOW TO USE AN IFIT WORKOUT Navigate to the area on the map where you want To use an iFIT workout, the console must be connected to draw your workout by sliding your fingers on the to a wireless network (see HOW TO CONNECT TO A screen.
  • Page 25 4. Select an iFIT workout that you have previously HOW TO CHANGE CONSOLE SETTINGS added to your schedule on iFIT.com. IMPORTANT: Some of the settings and features IMPORTANT: Before iFIT workouts will load, described may not be enabled. Occasionally, a you must add them to your schedule on firmware update may cause your console to function iFIT.com (see step 1).
  • Page 26 3. Customize the time zone and other settings. 6. Calibrate the incline system of the treadmill. To customize the time zone or other settings, touch Touch Calibrate Incline, and then touch Begin to Equipment Settings and then touch the desired calibrate the incline system.
  • Page 27 HOW TO CONNECT TO A WIRELESS NETWORK An information box will ask if you want to connect to the wireless network. Touch Join to connect to The console is Wi-Fi enabled, allowing you to set up a the network or touch Cancel to return to the list of wireless network connection.

  • Page 28: Fcc Information

    THE OPTIONAL HEART RATE MONITOR rate during your workouts. The optional heart rate monitor will enable you to continuously monitor your Whether your heart rate while you exercise, helping you to reach goal is to your personal fitness goals. To purchase a heart rate burn fat or to monitor, please see the front cover of this manual.

  • Page 29: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 30: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown (A), the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used.
  • Page 31 SYMPTOM: The walking belt slows when walked on c. Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never a. Use only a surge suppressor that meets all of the apply silicone spray or other substances to specifi cations described on page 17. the walking belt or the walking platform unless instructed to do so by an authorized service b.
  • Page 32 b. If the walking belt slips when walked on, fi rst SYMPTOM: The displays of the console do not remove the key and UNPLUG THE POWER function properly CORD. Using the hex key, turn both idler roller screws clockwise, 1/4 of a turn. When the walking a.

  • Page 33: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 34: Part List

    PART LIST Model No. NTL17122.2 R1121A Key No. Qty. Description Key No. Qty. Description 3/8" x 1 1/4" Screw Clip 3/8" x 2 3/4" Screw M25 Nut Incline Stop Bracket M10 Nut #8 x 3/4" Screw 1/2" Plastic Bushing Ground Screw Fan Screw M4 x 20mm Screw Rear Foot...
  • Page 35 Key No. Qty. Description Key No. Qty. Description Left Inner Grip Console Base Cover Right Inner Grip Upper Console Cover Right Outer Grip Lower Console Cover Right Upright Inner Cover Console Back Plate Right Inner Console Base Cover Saddle Bracket Left Handrail Pivot Cover Right Handrail...

  • Page 36: Exploded Drawing

    EXPLODED DRAWING A Model No. NTL17122.2 R1121A...
  • Page 37 EXPLODED DRAWING B Model No. NTL17122.2 R1121A...
  • Page 38 EXPLODED DRAWING C Model No. NTL17122.2 R1121A...
  • Page 39 EXPLODED DRAWING D Model No. NTL17122.2 R1121A...

  • Page 40: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...

This manual is also suitable for:

Ntl17122.2
