Initial Setup and Verification
a. USB port
b. Ethernet management port
c. Console port
d. 1G/10G SFP+ ports
e. USB port
f. 10Gb/25Gb/40Gb/50Gb/100Gb capable QSFP28 ports
3. Access the device using a terminal emulator application (such as HyperTerminal in a Windows
environment or Tip in a UNIX environment).
4. Disable any serial communication programs running on the workstation (such as synchronization
programs).
5. Open a terminal emulator application (such as HyperTerminal on a PC, or TERM, Tip, or Kermit in a
UNIX environment), and configure the application as follows:
•
In a Windows environment:
Parameter
Bits per second
Data bits
Parity
Stop bits
Flow control
•
In a UNIX environment, enter the following string at the prompt:
tip /dev/ttyb -9600
If ttyb is already in use, use ttya instead and enter the following string at the prompt:
tip /dev/ttya -9600
Note
The console or serial port is intended primarily for the initial setting of the IP address.
Note
Flow control is not supported on the serial consoles when attached to remote terminal
servers and must be disabled to ensure proper operation.
ExtremeRouting SLX 9640 Hardware Installation Guide
Establishing a serial connection
Value
9600
8
None
1
None
