1.1.2 Fresh air processing unit

Table 1-1.3: Fresh air processing unit capacity range
Capacity
Capacity index
Notes:
1. V6R series outdoor units are compatible with the 2nd generation DC Fresh air processing unit.

1.2 Heat recovery ventilator

Table 1-1.4: Heat recovery ventilator capacity range
Capacity 200m
Notes:
1. V6R series outdoor units are compatible with the DC type heat recovery ventilator.

1.3 High Temperature Hydro Module

Table 1-1.5: 1.3 High Temperature Hydro Module capacity range
Capacity
Capacity index

1.4 Outdoor Units

Table 1-1.6: Outdoor unit capacity range
Capacity
8HP
10HP
12HP
14HP
16HP
18HP
20HP
22HP
24HP
26HP
28HP
30HP
32HP
34HP
36HP
38HP
40HP
42HP
44HP
46HP
48HP
50HP
52HP
54HP
56HP
58HP
60HP
Notes:
1. The combinations of units shown in the table are factory-recommended. Other combinations of units are also possible.
12.5kW 14kW
125 140
3 3
/h 300m /h 400m
14kW
140
20kW
200
3 3
/h 500m /h 800m
Model Name
MV6-R252WV2GN1
MV6-R280WV2GN1
MV6-R335WV2GN1
MV6-R400WV2GN1
MV6-R450WV2GN1
MV6-R500WV2GN1
MV6-R560WV2GN1
MV6-R615WV2GN1
MV6-R670WV2GN1
MV6-R730WV2GN1
MV6-R785WV2GN1
MV6-R850WV2GN1
MV6-R900WV2GN1
MV6-R950WV2GN1
MV6-R1015WV2GN1
MV6-R1065WV2GN1
MV6-R1120WV2GN1
MV6-R1175WV2GN1
MV6-R1230WV2GN1
MV6-R1285WV2GN1
MV6-R1345WV2GN1
MV6-R1400WV2GN1
MV6-R1460WV2GN1
MV6-R1515WV2GN1
MV6-R1570WV2GN1
MV6-R1635WV2GN1
MV6-R1685WV2GN1
V6R VRF 50/60Hz
25kW
250
3 3
/h 1000m /h 1500m
Combination Type
/
/
/
/
/
/
/
12HP+10HP
14HP+10HP
14HP+12HP
16HP+12HP
18HP+12HP
16HP+16HP
18HP+16HP
18HP+18HP
20HP+18HP
20HP+20HP
16HP+14HP+12HP
16HP+16HP+12HP
16HP+16HP+14HP
16HP+16HP+16HP
18HP+16HP+16HP
18HP+18HP+16HP
18HP+18HP+18HP
20HP+18HP+18HP
20HP+20HP+18HP
20HP+20HP+20HP
28kW
280
3 3
/h 2000m /h
