- Page 1 TECHNICAL MANUAL Venice door entry monitor - ViP system Art. 6814W Passion.Technology. Design.
-
Page 2: Technical Specifications
• We advise against running the system wires through the same duct as the power cables (230V or higher). • To ensure Comelit products are used safely: carefully observe the indications provided in the manuals / instruction sheets and make sure the system created using Comelit products has not been tampered with / damaged. -
Page 3: Installation
NETWORK AND COMMUNICATION HARDWARE FEATURES HARDWARE FEATURES PROTOCOLS Ethernet 10/100 Type of LAN network Comaptibility with Number of inputs Mbit/s Video Entry Comelit Communication ports RJ45 (Ethernet) IP address assignment DHCP, AUTO IP, Ethernet ports static IP Compatibility with Network connection RJ45... -
Page 4: Configuration Wizard
Confi guration CONFIGURATION WIZARD Select the desired language and confi rm by pressing Yes and continue with guided confi guration. Language Language Language Confirm language choice? Italiano Italiano Italiano English English English Français Français Français Español Español Español Set the ViP address for the device and choose whether you want to install the door entry monitor as: •... -
Page 5: Operating Distances
ACCESSING THE ADVANCED SETTINGS MENU 10:54 10/04/2021 Intercoms Cameras Actuators A/V answering service List of calls Setup SETUP SELECTION User setup menu Installer setup menu INSTALLER PASSWORD 0000 Operating distances 1 mm² (Ø 1,2 mm AWG 17) Type of power supply Maximum distance (m) SPOE 24 VDC UTP5 cat. -
Page 6: Basic Wiring Diagram
Basic wiring diagram 1442B 100-240 V 1442B 100-240 V Use POE ports to connect the art. 6814W 6814W 6814W ORANGE WHITE ORANGE GREEN 6814W WHITE GREEN 1595 120-230 V TX TX RX RX NO NC UT8020 UT9200 20 m max. Local door-opener button... - Page 7 Variant with second external unit 1442B 100-240 V 1442B 100-240 V Use POE ports to connect the art. 6814W Connections among uplink ports and 1440 only with Comelit red cable 1449 6814W ORANGE WHITE ORANGE GREEN 6814W WHITE GREEN 6814W O U T...
- Page 8 Variant with PoE standard switch 1442B 100-240 V 1442B Use POE ports to connect 100-240 V the art. 6814W 6814W 6814W 6814W STANDARD SWITCH BROWN & WHITE BROWN BLUE & WHITE BLUE ORANGE WHITE ORANGE GREEN WHITE GREEN 12 VDC 0,25A TX TX RX RX...
