Venice door entry monitor - ViP system
Art. 6814W/6814B
EN
TECHNICAL
MANUAL
MYCOMELIT, L'APP PER IL PROFESSIONISTA
IT
MYCOMELIT: THE APP FOR PROFESSIONALS
EN
MYCOMELIT, L'APPLI POUR LES PROFESSIONNELS
FR
MYCOMELIT DE APP VOOR DE PROFESSIONAL
NL
MYCOMELIT DIE PROFI-APP
DE
MYCOMELIT, LA APP DEL PROFESIONAL
ES
MYCOMELIT: A APLICAÇÃO PARA O PROFISSIONAL
PT
FREE DOWNLOAD
Advertisement
Table of Contents
Related Manuals for Comelit 6814B
Summary of Contents for Comelit 6814B
- Page 1 MYCOMELIT: THE APP FOR PROFESSIONALS MYCOMELIT, L'APPLI POUR LES PROFESSIONNELS MYCOMELIT DE APP VOOR DE PROFESSIONAL MYCOMELIT DIE PROFI-APP MYCOMELIT, LA APP DEL PROFESIONAL MYCOMELIT: A APLICAÇÃO PARA O PROFISSIONAL FREE DOWNLOAD Venice door entry monitor - ViP system Art. 6814W/6814B...
-
Page 2: Technical Specifications
• We advise against running the system wires through the same duct as the power cables (230V or higher). • To ensure Comelit products are used safely: carefully observe the indications provided in the manuals / instruction sheets and make sure the system created using Comelit products has not been tampered with / damaged. -
Page 3: Installation
NETWORK AND COMMUNICATION HARDWARE FEATURES HARDWARE FEATURES PROTOCOLS Ethernet 10/100 Type of LAN network Comaptibility with Number of inputs Mbit/s Video Entry Comelit Communication ports RJ45 (Ethernet) IP address assignment DHCP, AUTO IP, Ethernet ports static IP Compatibility with Network connection RJ45... -
Page 4: Configuration Wizard
Configuration CONFIGURATION WIZARD Select the desired language and confirm by pressing Yes and continue with guided configuration. Language Language Confirm language choice? Italiano Italiano English English Français Français Español Español Set the ViP address for the device and choose whether you want to install the door entry monitor as: •... -
Page 5: Operating Distances
ACCESSING THE ADVANCED SETTINGS MENU 10:54 10/04/2021 Intercoms Cameras Actuators A/V answering service List of calls Setup SETUP SELECTION User setup menu Installer setup menu INSTALLER PASSWORD 0000 Operating distances 1 mm² (Ø 1,2 mm AWG 17) Type of power supply Maximum distance (m) SPOE 24 VDC UTP5 cat. -
Page 6: Basic Wiring Diagram
Basic wiring diagram 1442B 100-240 V 1442B 100-240 V Use POE ports to connect the art. 6814W/6814B 6814W 6814B 6814W 6814B ORANGE WHITE ORANGE GREEN 6814W 6814B WHITE GREEN 1595 120-230 V TX TX RX RX NO NC UT8020 UT9200... - Page 7 Variant with second external unit 1442B 100-240 V 1442B 100-240 V Use POE ports to connect the art. 6814W/6814B Connections among uplink ports and 1440 only with Comelit red cable 1449 6814W 6814B ORANGE WHITE ORANGE GREEN 6814W WHITE GREEN...
- Page 8 Variant with PoE standard switch 1442B 100-240 V 1442B Use POE ports to connect 100-240 V the art. 6814W/6814B 6814W 6814B 6814W 6814B 6814W 6814B STANDARD SWITCH BROWN & WHITE BROWN BLUE & WHITE BLUE ORANGE WHITE ORANGE GREEN WHITE GREEN...
