16 en | System overview
Control panel LEDs
The control panel LEDs provide status information about the system.
Power failure
Information
3.4

Hard drive carrier LEDs

The chassis supports hot-swappable SAS/SATA hard drives in hard drive carriers. Each hard
drive carrier features two status LEDs on the front of the carrier.
2019.08 | V1 | DOC
Button Description
The reset button is used to reboot the system.
Reset
LED Description
This LED indicates that a power supply module has failed.
This LED indicates the system status.
System status
Continuously on and red
Blinking red (1 Hz)
Blinking red (0.25 Hz)
Solid blue
Blinking blue (300 msec)
This LED indicates network activity on GLAN2 when flashing.
NIC2
This LED indicates network activity on GLAN1 when flashing.
NIC1
This LED indicates activity on the HDDs or peripheral drives when flashing.
HDD
This LED indicates that power is being supplied to the system's power supply
units.
This LED should normally be illuminated when the system is operating.
Power
Description
An overheat condition has occurred. (This
may be caused by cable congestion.)
Fan failure: check for an inoperative fan.
Power failure: check for an inoperative
power supply.
Local UID has been activated. Use this
function to locate the unit in a rack
environment.
Remote UID has been activated. Use this
function to locate the unit from a remote
location.
Installation manual
DIVAR IP all-in-one 7000 (2U)
