DIVAR IP all-in-one 7000 (2U)
Rear view:
3.3

Control panel elements

The control panel located on the front of the chassis features power buttons and status
monitoring LEDs.
Control panel buttons
Bosch Security Systems B.V.
1
2
1
2x power supply modules
3
1x serial port
5
4 USB ports
7
1x VGA display output (do not use, if
separate graphics card has been
added to the system)
9
1x sound card (audio inputs and
outputs)
Note: Available as optional accessory
item, not included by default.
Button
Description
The power button is used to apply or remove power from the power supply to
the system.
Note: Turning off system power with this button removes the main power,
Power
but keeps standby power supplied to the system.
To remove all power, unplug the system before performing maintenance
tasks.
3
4
5
6
2
4
6
8
Installation manual
System overview | en
7
8
9
2x redundant SSD drives for operating
system (RAID1 mirror)
1x network port for BMC (Baseboard
Management Controller) connection
and IPMI (Intelligent Platform
Management Interface) monitoring
2x network ports for data transmission
(teamed)
Note: Do not change the teaming
mode!
1x VGA display output (do not use, if
separate graphics card has been
added to the system)
15
2019.08 | V1 | DOC
