Appendix C: Specifications - Enterasys Matrix-V V2H124-24FX Hardware Installation Manual

Appendix C: Specifications

Physical Characteristics
Ports
24 100BASE-FX MT-RJ multimode fiber ports
Media Slots
2 slots for optional 100BASE-FX, 1000BASE-T, 1000BASE-T/SFP, or
stacking modules
Network Interface
Ports 1-24: MT-RJ connector
100BASE-FX: 62.5/125 micron multimode (two fibers per outlet)
100BASE-FX: 50/125 micron multimode (two fibers per outlet)
Buffer Architecture
8 Mbytes
Aggregate Bandwidth
8.8 Gbps
Switching Database
8K MAC address entries
LEDs
System: PWR, Diag, RPU, Stack
Ports: Link/Activity
Weight
3.12 kg (6 lbs 9 oz)
Size
44.0 x 23 x 4.3 cm (17.32 x 9.05 x 1.69 in.)
Temperature
Operating: 0°C to 50°C (32°F to 122°F)
Storage: -40°C to 70°C (-40°F to 158°F)
Humidity
Operating: 5% to 95% (non-condensing)
C-1
