4
Making Network Connections
Network Connections
Instructions for making patch-panel connections in the wiring closet follow.
1.
Attach one end of a patch cable to an available port on the switch, and the other
end to the patch panel.
2.
If not already in place, attach one end of a cable segment to the back of the
patch panel, and the other end to a modular wall outlet.
3.
Label the cables to simplify future troubleshooting.
4-2
Switch
Patch Panel
Figure 4-2. Network Connections
Equipment Rack
(side view)
Wall
