Figure 59. Removing the control panel cage
Next steps
Remove the control
panel.
Removing the control panel
Prerequisites
1. Follow the safety guidelines listed in the
Safety
instructions.
2. Follow the procedure listed in
Before working inside your
system.
Steps
1. Disconnect the control panel cable from the control panel.
CAUTION:
Do not use excessive force when removing the control panel cables as it can damage the connectors.
2. Using the Phillips 2 screwdriver, remove the screws that secure the control panel to the control panel cage.
3. Slide the control panel out of the control panel cage.
Installing and removing system components
69
