CAUTION:
Do not install GPUs, network cards, or other PCIe devices on your system that are not validated
and tested by Dell. Damage caused by unauthorized and invalidated hardware installation will null and void the
system warranty.
Optional BOSS S1 card
Removing the M.2 SSD module
Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in the
3.
Remove the BOSS S1
NOTE:
The procedure to remove the BOSS S1 card is similar to removing an expansion card.
Steps
1. Using the Phillips 1 screwdriver, remove the screw securing the M.2 SSD module to the BOSS S1 card.
2. Pull the M.2 SSD module to disconnect from the BOSS S1 card connector.
Figure 41. Removing the M.2 SSD module
Next steps
Replace the M.2 SSD module.
Installing the M.2 SSD module
Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in the
3.
Remove the BOSS S1
Safety
Before working inside your
card.
Safety
Before working inside your
card.
instructions.
system.
instructions.
system.
Installing and removing system components
51
