GMC 1998 Yukon Owner's Manual

page of 445

/ 445
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

I 9 9 5

c ) W N . E R ' S

M A N U A L

C O M F O R T A B L Y

I N

C O M M A N D ' "

Table of Contents

Summary of Contents for GMC 1998 Yukon

Page 1 I 9 9 5 c ) W N . E R ' S M A N U A L C O M F O R T A B L Y C O M M A N D ' "...
Page 7 This section tells you when to perform vehicle maintenance and what fluids and lubricants to use. Customer Assistance Information This section tells you how to contact GMC for assistance and how to get service and owner publications. also gives you information o n “Reporting Safety Defects” on page 8- 10.
Page 8 GENERAL MOTORS, GM, the GM Emblem, GMC, GMC Emblem, the name YUKON and the name SUBURBAN are registered trademarks of General Motors Corporation. This manual includes the latest information at the time it was printed. We reserve the right to make changes in the product after that time without further notice.
Page 9 How to Use this Manual Many people read their owner’s manual from beginning end when they first receive their new vehicle. If you do this, it will help you learn about the features and In this manual, you’ll find controls your vehicle.
Page 10 You will also find a circle with a slash through it in this book. This safety symbol means “Don’t,” “Don’t do this’’ or “Don’t let this happen.” Vehicle Damage Warnings Also, in this book you will find these notices: NOTICE: These mean there is something that could damage your vehicle.
Page 11 Vehicle Symbols These are some of the symbols you may find on your vehicle. For example, These symbols are important these symbols are used on an for you and original battery: yo11r passengers whenever your vehicle is CAUTION driven: POSSIBLE INJURY DOOR LOCK PROTECT...
Page 12 Model Reference This manual covers these models: 4-Door Utility 2-Door Utility Suburban...
Page 13 Section 1 Seats and Restraint Systems Here you’ll find information about the seats in your vehicle and how to use your safety belts properly. You can also learn about some things you should not do with air bags and safety belts. Seats and Seat Controls 1-17 Safety Belts: They’re for Everyone...
Page 14 Seats and Seat Controls This section tells about the seats them and fold them up and down. It also tells reclining front seatbacks and head restraints. Manual Front Seat You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
Page 15 Power Seat(s) (If Equipped) If your vehicle has a power seat on the driver’s or passenger’s side, you can adjust it with these controls at the outside edge of the seat. The switch is located on the side of the seat, next to the door. You can use the round center knob to move the seat to where you want To raise the seat, move the knob up.
Page 16 Heated Front Seats (If Equipped) The control for the driver’s side heated seat is located on the left side of the seat. The control for the right front passenger is located on the right side of the passenger seat. Move the switch forward to MED or HIGH temperature to turn on the heating elements in the seat, The right front passenger’s safety belt must be buckled before the heating elements in that seat will operate.
Page 17 But don’t have a seatback reclined if your vehicle is moving. Sitting in a reclined position when your vehicle is in motion can be dangerous. Even if you buckle up, your safety belts can’t do their job when you’re reclined like this, The shoulder belt can’t do its job because it won’t be against your body.
Page 18 Seatback Latches (2-Door Utility) the seatback isn’t locked, it could move forward in a sudden stop or crash. That could cause injury to the person sitting there. Always press rearward on the seatback to be sure it is locked. The front seatback folds forward to let you access the rear of the vehicle.
Page 19 Easy Entry Seat (2-Door Utility) any easy entry seat isn’t locked, it can move. In a sudden stop or crash, the person sitting there could be injured. And, even sudden stop, a driver sitting in an unlocked easy entry seat could be startled by the sudden movement and hit the wrong control or pedal, causing an accident.
Page 20 Rear Seats If a head restraint is not installed on the seatback or stored in the vehicle properly, it could be thrown about the vehicle in a crash or sudden maneuver. People in the vehicle could be injured. Remove the head restraints only when you need to fold the seat, and be sure that the head restraints are stored securely in the storage bag and placed under the rear seat.
Page 21 To fold the seat, pull on the release handle at the bottom When you release the seat cushion, the seatback is of the seat cushion marked RELEASE. automatically released. Pull the loop on the seatback forward and fold the seatback onto the seat cushion.
Page 22 While the seat is in the folded position, hang the latch plate end of the outer passenger position safety belts on the hooks at the top of each retractor cover, out of the way. To return the seat to the passenger position, just lift up on the seatback and push it rearward until it latches.
Page 23 To fold the seat, pull up on Then, pull the seat cushion up and fold it forward. After folding the seat cushion fully forward, pull the seatback forward and fold the seatback down until it is flat. Then, stow the head restraints by sliding them into the rear of the seatback.
Page 24 Folding the Second Seat (Suburban) If your vehicle has a 60/40 rear seat, either side may be folded down to give you more cargo space. Before folding, place the latch portion of the center safety belt in the center armrest. That way, the center safety belt will be out of the way when the seat is folded and also will be easily available for passengers to use when the seat is returned to the passenger position.
Page 25 To create a load floor, release the panels from the seatback by pushing rearward on the latch and fold them out to cover the rear seat footwell. To return the seat to the passenger position, lift the load floor panels and latch them into the seatback. Then lift the rear seatback up and latches.
Page 26 Entry to the Rear Seat (Suburban Second Seat) 60140 split folding bench seat The right side of the rear has an easy entry feature. That makes it easy to get in and out of the third seat, if you have one. To operate the seat, move the lever at the side of the seat down.
Page 27 A safety belt that is twisted or not properly attached won’t provide the protection needed in a crash. The person wearing the belt couId be seriously injured. After installing the seat, always check to be sure that the safety belts are not twisted and are properly attached.
Page 28 Move the seatback release lever, at the right rear of the seat, toward the center of the vehicle. Then, fold the seatback forward into the seat cusnlon. To unlatch the seat from the floor, pull up on the center release handle at the rear of the seat and lift the rear seat Turn the seat sideways and take it out of the vehicle.
Page 29 Safety Belts: They’re for Everyone This part of the manual tells you how to use safety belts properly. It also tells you some things you should with safety belts. And it explains the air bag system. Don’t let anyone ride where he or she can’t wear a safety belt properly.
Page 30 Your vehicle has a light that comes buckle up. (See “Safety Belt Reminder Light” in the Index.) In most states and Canadian provinces, the law says to wear safety belts. Here’s why: They work. You never know if you’ll be in a crash. If you do have a crash, you don’t know if it will be a bad one.
Page 31 up to speed. Then stop the vehicle. The rider Put someone on it. doesn't stop. 1-19...
Page 32 or the instrument panel The person keeps going until stopped by something. In a real vehicle, it could be the windshield 1-20...
Page 33 or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That's why safety belts make such good sense. Here Are Questions Many People Ask About Safety Belts and the Answers...
Page 34 If I’m a good driver, and I never drive far from home, why should wear safety belts? You may be an excellent driver, but if you’re in an accident even one that isn’t your fault your passengers can be hurt. Being a good driver doesn’t protect you from things beyond your control, such as bad drivers.
Page 35 3. Pick up the latch plate and pull the belt across you. Don't let it get twisted. 4. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure If the belt isn't long enough. see "Safety Belt Extender"...
Page 36 Shoulder Belt Height Adjuster Before you begin to drive, move the shoulder belt adjuster to the height that is right for you. 1-24 To move it down, push in at the word the height adjuster to the desired position. You can move the adjuster up just by pushing up guide.
Page 37 What's wrong with this? The shoulder belt is too loose. It won't give nearly as much protection this way. You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should fit against your body.
Page 38 What’s wrong with this? The belt is buckled i n the wrong place. You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not at the pelvic bones.
Page 39 What’s wrong with this? The belt is over an armrest. You can be seriously injured if your belt goes over an armrest like this. The belt would be much too high. In a crash, you can slide under the belt. The belt force would then be applied at the abdomen, not at the pelvic bones, and that could cause serious or fatal injuries.
Page 40 What's wrong with this? The shoulder belt is worn under the arm. It should be worn over the shoulder at all times. 1-28 You can be seriously injured if you wear the shoulder belt under your arm. In body would move too far forward, which would increase the chance of head and neck injury.
Page 41 &= What’s wrong with this? The belt is twisted across the body. You can be seriously injured by a twisted belt. In a crash, you wouldn’t have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer to fix it.
Page 42 To unlatch the belt, just push the button on the buckle. The belt should go back out of the way. Before you close the door, be sure the belt is out of the way. If you slam the door on it, you can damage both the belt and your vehicle.
Page 43 The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it’s more likely that the fetus won’t be hurt in a crash. For pregnant women, as for anyone, the key to making safety belts effective is wearing them properly.
Page 44 0 “ ’ D - - - - Air bags inflate h great force, faster than the blink of an eye. If you’re too close to an inflating air bag, it could seriously injure you. Safety belts help keep you in position before and during a crash.
Page 45 There is an air bag readiness light on the instrument AI R panel, which shows AIR BAG. The system checks the air bag electrical system for malfunctions. The light tells you if there is an electrical problem. See “Air Bag Readiness Light” in the Index for more information.
Page 46 The right front passenger’s air bag is in the instrument panel on the passenger’s side. 1-34 /r\ CAUr-10N: If something is between an occupant and an air bag, the bag might not inflate properly or it might force the object into that person. The path of an inflating air bag must kept clear.
Page 47 When should an air bag inflate? An air bag is designed to inflate in a moderate to severe frontal or near-frontal crash. The air bag will inflate only if the impact speed is above the system’s designed “threshold level.” If your vehicle goes straight into a wall that doesn’t move or deform, the threshold level is about to 16 mph...
Page 48 What will you see after an air bag inflates? After an air bag inflates, it quickly deflates, so quickly that some people may not even realize the air bag inflated. Some components of the module -- the steering wheel hub for the driver’s air bag, or the instrument panel for the right front passenger’s bag will be hot for a short time.
Page 49 Your vehicle is equipped with diagnostic module, which records information about the air bag system. The module records information about the readiness of the system, when the sensors are activated and driver‘s safety belt usage at deployment. Let only qualified technicians work on your air bag system.
Page 50 Adding Equipment to Your Air Bag-Equipped Vehicle If I add a push bumper or a bicycle rack to the front of my vehicle, will it keep the air bags from working properly? As long as the push bumper or bicycle rack is attached to your vehicle so that the vehicle’s basic struct.ure isn’t changed, it’s not likely to keep the air bags from working properly in a crash.
Page 51 When you sit in a center seating position, you have a lap safety which has no retractor. To make the belt belt, longer, tilt the latch plate and pull it along the belt. To make the belt shorter, pull its free end as shown until the belt is snug.
Page 52 Rear Seat Passengers It’s very important for rear seat passengers to buckle up! Accident statistics show that unbelted people in the rear seat are hurt more often in crashes than those who are wearing safety belts. Rear passengers who aren’t safety belted can be thrown out of the vehicle in a crash.
Page 53 4-DOOr Utility 1. P1cK up the latch plate and pull the belt across you. Don’t let it get twisted. 2. Push the latch plate into the buckle until it clicks. Pull up on the latch plate to make sure it is secure. When the shoulder belt is pulled out all the will lock.
Page 54 2-Door Utility and Suburban 4-DOOr Utility 3. To make the lap part tight, pull down on the buckle end of the belt as you pull up on the shoulder part. 1-42...
Page 55 The lap part of the belt should be worn hips, just touching the thighs. In a crash, this applies force to the strong pelvic bones. And you’d be less likely to slide under the lap belt. If you slid under it. the belt would apply force at your abdomen.
Page 56 1-44 To move the height adjuster down, push in at the word PRESS and move the height adjuster to the desired position. You can move the adjuster up just by pushing up on the shoulder belt guide. After you Inwe the adjuster where you want it, try to n1ove it down without pushing in to make sure it has locked...
Page 57 4-Door Utility 2-Door Utility and Suburban TO unlatch the belt, just push the button on the buckle. 1-45...
Page 58 Rear Safety Belt Comfort Guides for Children and Small Adults Your vehicle may have rear shoulder belt comfort guides. This feature will provide added safety belt comfort for children who have outgrown child restraints and for small adults. When installed on a shoulder belt, the comfort guide pulls the belt away from the neck and head.
Page 59 2. Slide the guide under and past the belt. The elastic cord must be under the belt. Then, place the guide over the belt, and insert the two edges the slots of the guide. 3. Be sure that the belt is not twisted and The elastic cord must be under the belt and the guide of the belt into on top.
Page 60 4. Buckle, position and release the safety belt as described in “Rear Seat Outside Passenger Positions” earlier in this section. Make sure that the shoulder belt crosses the shoulder. 1-48 To remove and store the comfort guid&, qUeEze the so that you can take them out from belt edges together the guides.
Page 61 Smaller Children and Babies Children who are up against, or very close to, an air bag when it inflates be seriously injured or killed. Air bags plus lap-shoulder belts offer the best protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor its air bag system is designed for them.
Page 62 Infants need complete support, including support for the head and neck. This is necessary because an infant’s neck is weak and its head weighs so much compared with the rest of body. In a crash, an infant in rear-facing restraint settles into the restraint, so the crash forces can be distributed across the strongest part of the infant’s body, the back and shoulders.
Page 63 at only 25 mph (40 km/h), a 12-lb. (5.5 kg) baby will suddenly become a 240-lb. (110 kg) force on your arms. The baby would be almost impossible to hold. Secure the baby in an infant restraint. Child Restraints Every time infants and young children ride in vehicles, they should have protection provided by appropriate restraints.
Page 64 Some infant seats come in two parts -- the base secured in the vehicle and the seat part is removable. A forward-facing child restraint positions a child upright face forward the vehicle. These forward-facing restraints are designed to help protect children who are from 20 to 40 Ibs. (9 to 18 kg) and about 26 to 40 inches (66 to 102 cm) in height, or up to around four years a convertible restraint, is...
Page 65 A child in a rear-facing child restraint can be seriously injured if the right front passenger’s air bag inflates. This is because the back of a rear-facing child restraint would be very close to the inflating air bag. Always secure a rear-facing child restraint in a rear seat.
Page 66 Securing a Child Restraint in a Rear Outside Seat Position You’ll be using the lap-shoulder belt. See the earlier part about the top strap if the child restraint has one. Be sure to follow the instructions that came with the child restraint.
Page 67 4. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. To tighten the belt, feed the shoulder belt back into the retractor while you push down on the child restraint. If you’re using a forward-facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 68 You’ll be using the lap belt. Be sure to follow the instructions that came with the child restraint. Secure the child in the child restraint when and as the instructions See the earlier part about the top strap if the child restraint has one.
Page 69 4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the safety belt quickly if you ever had to. 5. To tighten the belt, pull its free end while you push down on the child restraint. If you're using a forward-facing child restraint, you may find it helpful to use your knee to push down on the child restraint as you tighten the belt.
Page 70 Securing a Child Restraint in the Right Front Seat Position Your vehicle has a right front passenger air bag. Never. rear-facing child restraint in this seat. Here’s why: 1-58 A child in a rear-facing child restraint can be seriously in,jured if the right front passenger’s bag inflates.
Page 71 5. Pull the rest of the lap belt all the way out of the 4. Buckle the belt. Make sure the release button is positioned so you would be able to unbuckle the retractor to set the lock. safety belt quickly if you ever had to. 1-59...
Page 72 tighten the belt, feed the lap belt back into the retractor while you push down on the child restraint. You may find it helpful to use your knee to push down on the child restraint as you tighten the belt. Push and pull the child restraint in different directions’to be sure it is secure.
Page 73 Accident statistics show that children are safer are restrained in the rear seat. But safety belts properly. Children who aren’t buckled up can be thrown out a crash. Children who aren’t buckled up can strike other people who are. if they they need to use the Never do this.
Page 74 2-Door Utility and Suburban 4-DOOr Utility...
Page 75 CAUTION: Never do this. Here a child is sitting in a seat that has a lap-shoulder belt, but the shoulder part is behind the child. If the child wears the belt in this way, in a crash the child might slide under the belt. The belt’s force would then be applied right on the child’s abdomen.
Page 76 Checking Your Restraint Systems Now and then, make sure the safety belt reminder light your belts, buckles, latch plates, retractors and anchorages are working properly. Look for any other loose or damaged safety belt system parts. If you see anything that might keep a safety belt system from doing its job, have it repaired.
Page 77 NOTES 1-65...
Page 78 NOTES 1-66...
Page 79 Section 2 Features and Controls Here you can learn about the many standard and optional features shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is working properly and what to do if you have Keys Door Locks Keyless Entry System (If Equipped)
Page 80 Keys rION: Leaving young children in a vehicle with the ignition key is dangerous for many reasons. A child or others could be badly injured or even killed. They could operate power windows or other controls or even make the vehicle move. Don’t leave the keys in a vehicle with young children.
Page 81 Your vehicle has one double-sided key for the ignition and all door locks. If you ever lose your key, your dealer will be able to assist you with obtaining a new one. Door Locks Unlocked doors can be dangerous. Passengers especially children open the doors and fall out.
Page 82 Power Door Locks Press the side door lock switch marked LOCK on either front door to lock all the doors at once. Press the ribbed side of the switch to unlock all the doors at once. On four-door models, the manual switch on each rear door works only that door’s lock.
Page 83 On the passenger side of the rear cargo door or tailgate, there is a power lock switch which can be used to lock unlock all of the doors. LOCK On vehicles with cargo doors, if the rear cargo lock switch is pressed with the cargo doors open, all doors will lock five seconds after the cargo doors are closed.
Page 84 Keyless Entry System (If Equipped) If your vehicle has this option, you can lock and unlock your doors or your tailgate from about 30 feet (9 In) away using the keyless entry transmitter supplied with your vehicle. Your interior lamps will be illuminated for a set period of time when the transmitter signal is received by the Keyless Entry System.
Page 85 Operation To unlock the driver’s door, press the UNLOCK button. The interior lamps will come on for 40 seconds or until the ignition is turned on. If you press this button again within five seconds, all the remaining doors will unlock. Press the LOCK button to lock all the doors.
Page 86 To replace the battery: Insert a small coin, or flathead screwdriver, to separate the bottom of the transmitter from the top. Remove the battery and replace making sure the positive side of the battery is facing down. Snap the top and bottom together. Test the operation of transmitter vehicle.
Page 87 It can be dangerous to drive with the tailgate glass, tailgate or rear doors open because carbon monoxide (CO) gas can come into your vehicle. CO. It can cause You can’t see o r smell unconsciousness and even death. If you must drive with the tailgate glass, tailgate or rear doors open or if electrical wiring or other cable connections must pass through the seal between the body and the tailgate glass, tailgate...
Page 88 To open the driver’s side door, first open the passenger’s side door. Then, pull the handle on the left door edge out and pull the door open. The rear doors have a check assembly to keep them from fully opening during normal use. To fully open either rear door, you must release the check strap.
Page 89 Parking at Night Park in a lighted spot, close all windows and lock your vehicle. Remember to keep your valuables out of sight. Put them in storage area, or take them with you. Parking Lots If you park in lot where someone will be watching your vehicle, it’s best to lock up and take your keys.
Page 90 New Vehicle “Break-In” NOTICE: Your vehicle doesn’t need an elaborate “break-in.” But it will perfornl better in the long run if follow these guidelines: Keep your speed 55 mph (88 k d h ) o r less for the first 500 miles (805 km). Don’t drive at any one speed for the first 500 miles (805 km).
Page 91 LOCK (B): This position locks your ignition, steering wheel and transmission. It’s a theft-deterrent feature. You will only be able to remove your key when the ignition is turned to LOCK. OFF (C): This position lets you turn off the engine but still turn the steering wheel.
Page 92 NOTICE: START for Holding your key in 15 seconds at a time will cause your battery to be drained much sooner. And the excessive heat can damage your starter motor. doesn’t start right away, hold your key in START. If doesn‘t start in 1 0 seconds, push the accelerator pedal all the way down for five more seconds, or until it starts.
Page 93 Engine Coolant Heater (If Equipped) In very cold weather, 0°F engine coolant heater can help. You'll get easier starting and better fuel economy during engine warm-up. Usually, the coolant heater should be plugged in a minimum of four hours prior to starting your vehicle.
Page 94 Automatic Transmission Operation There are several different positions for your shift lever. Your vehicle features an electronic shift position indicator within the instrument cluster. This display must be powered anytinle the shift lever is capable o f being ~noved out of PARK (P).
Page 95 REVERSE (R): Use this gear to back up. NOTICE: Shifting to REVERSE (R) while your vehicle is moving forward could damage your transmission. Shift to REVERSE (R) only after your vehicle is stopped. rock your vehicle back a r ~ l forth to get out of snow. ice or without damaging your transmission, see sand...
Page 96 AUTOMATIC OVERDRIVE (0): for normal driving. If you need more power for passing, and you’re: Going less than about 35 mph (56 km/h), push your accelerator pedal about halfway down. Going about 35 mph (56 km/h) or more, push the accelerator all the way down.
Page 97 Four-wheel Drive (If Equipped) If your vehicle has four-wheel drive, you can send your engine’s driving power to all four wheels for extra traction. To get the most satisfaction out of four-wheel drive, you must be familiar with its operation. Read the part that follows before using four-wheel drive.
Page 98 The front axle portion of the indicator diagram will light up when you shift into four-wheel drive and the front axle engages. Some delay between shifting into four-wheel drive and the indicator’s lighting is normal. If the front axle light does not go out ilnlnediately after you shift out of four-wheel drive, have your dealer check your system.
Page 99 4-Wheel Low (4L): This setting also engages your front axle to give you extra power and a higher driveline ratio. This position should be used only for off-road driving. shift from 2-WHEEL HIGH (2H) to 4-WHEEL HIGH (4H) or from 4-WHEEL HIGH (4H)to 2-WHEEL HIGH (2H) while the vehicle is moving.
Page 100 Recommended Transfer Case Settings Transfer Case Settings AUTO Driving Conditions Normal ’, . . . Variable ..Severe ......
Page 101 Indicator lights in the switches show which setting you are in. The indicator lights will come on briefly when you turn on the ignition and one will stay on. If the lights do not come on, you should take your vehicle to your dealer for service.
Page 102 Shifting to Neutral To shift the transfer case to neutral, f'irst make sure the so that vehicle is parked it will not roll: 1. Set the parking brake. 2. Start the vehicle. 3. Connect the vehicle the towing vehicle. 4. Put the transmission i n NEUTRAL (N). 5.
Page 103 To release the parking brake, hold the regular brake pedal down. Pull the lever, located just above the parking brake pedal, marked BRAKE RELEASE, parking brake. If the ignition is on when the parking brake is released, the brake system warning light will go off. NOTICE: Driving with the parking brake on can cause your rear brakes to overheat.
Page 104 1. Hold the brake pedal down with your right foot set the parking brake. 2. Move the shift lever into PARK (P) position like this: Pull the lever toward you. 2-26 Move the lever up as far as If you have four-wheel drive, be sure the transfer case is in a drive gear Turn the ignition key to LOCK.
Page 105 Leaving Your Vehicle With the Engine Running It can be dangerous to leave your vehicle with the engine running. Your vehicle could move suddenly if the shift lever is not fully in with the parking brake firmly four-wheel drive and your transfer case is in NEUTRAL (N), your vehicle will be free to roll, even if your shift lever is in PARK (P).
Page 106 Shifting Out of PARK (P) Your vehicle has a brake-transmission shift interlock system. You have to fully apply your regular brakes shift from PARK (P) when the ignition is before you RUN. See “Automatic Transmission” in the Index. If you cannot shift out of PARK (P), ease pressure on the shift lever and push the shift lever all the way up into PARK (P) as you maintain brake application.
Page 107 Engine Exhaust Engine exhaust can kill. contains the gas carbon monoxide (CO), which you can’t see smell. It can cause unconsciousness and death. You might have exhaust coming in if: Your exhaust system sounds strange or different. Your vehicle gets rusty underneath. Your vehicle was damaged in a collision.
Page 108 It can be dangerous to get out of your vehicle if the shift lever is not fully in PARK (P) parking brake firmly set. Your vehicle can roll. Don’t leave your vehicle when the engine is If you’ve left the running unless you have to.
Page 109 Power Windows (If Equipped) 4-DOOr Utility and Suburban If you have the optional power windows, the controls 2-Door Utility are on each of the side doors. The driver’s door has a switch for the passenger windows as well. Your power windows will work when the ignition has been turned to ACC or RUN.
Page 110 The driver’s window switch has an express-down feature that allows the window to be lowered without holding the switch. Press and hold the side of the window switch marked AUTO for one second to activate the express-down mode. The express-down mode can be canceled at any time by pressing the opposite side of the switch.
Page 111 Tilt Wheel (If Equipped) A tilt steering wheel allows you to adjust the steering wheel before you drive. You can also raise it to the highest level to give your legs more room when you enter and exit the vehicle. To tilt the wheel, hold the steering wheel and pull the lever.
Page 112 Turn Signal and Lane Change Indicator turn signal has two upward (for right) and two downward (for left) positions. These positions allow you to signal a turn or a lane change. To signal a turn, move the lever all the way up or down. When the turn is finished, the lever will return autornatically.
Page 113 Windshield Wipers You control the windshield wipers by turning the knob with the wiper symbol on it. For a single wiping cycle, turn the knob to MIST. Hold there until the wipers start, then let go. The wipers will stop after one cycle. If you want more cycles, hold the knob on MIST longer.
Page 114 Rear Window Wiper and Washer The rear window wipedwasher switch is on your instrument panel, to the right of the gage cluster. To turn the wiper on, slide the switch all the way For delay wiping, slide the switch even with DELAY the center position of the rear wiper control.
Page 115 Wdsher fluid will spray as long as you push the paddle. When you let go of the paddle, the wipers will continue to wipe for a few seconds and then either stop or return to the preset speed. The use of hood-mounted air deflectors may adversely affect windshield wiper and washer performance.
Page 116 1. Move the cruise control switch to ON. 2. Get up to the speed you want. 3. Push in the SET button at the end of the lever and release 2-38 4. Take your foot off the accelerator pedal. Resuming a Set Speed Suppose you set your cruise control at a desired speed and then you apply the brake.
Page 117 Increasing Speed While Using Cruise Control There are two ways to go to a higher speed: Use the accelerator pedal to get to the higher speed. Push the SET button at the end of the lever, then release the button and the accelerator pedal. You’ll now cruise at the higher speed.
Page 118 Ending Cruise Control There are two ways to turn off the cruise control: Step lightly on the brake pedal or Move the cruise control switch to OFF. Erasing Speed Memory When you turn off the cruise control or the ignition, your cruise control set speed memory is erased.
Page 119 License Plate Lamps Instrument Panel Lights Rotate the knob to the right again, to the master lighting symbol, to turn on all the lamps listed as well as the headlamps. Rotate the knob to the left, to OFF, to turn off your lamps.
Page 120 When it begins to get dark, your reminder to turn your headlamp switch on. The other lamps that come on with your headlamps will also come When you turn the headlamp switch off, the regular lamps will go off, and your headlamps will change to the reduced brightness of DRL.
Page 121 You can use the DOME OVERRIDE button, located below the parking/headlamp knob, to set the dome lamps to come on automatically when the doors are opened, or remain off. To turn the lamps off, press the switch button once. With the switch button position.
Page 122 Mirrors Inside Daymight Rearview Mirror Pull the tab under the mirror rearward to reduce glare from headlamps behind you after dark. Push the tab forward for normal daytime operation. 2-44 Electrochromic Inside Rearview Mirror with Compass ( I f ' Equipped) Your vehicle may have an electrochromic inside - - .
Page 123 Mirror Operation The right side of the switch located at the bottom of the mirror turns the electrochromic mirror on and off. The when the electrochromic AUTO LED will come mirror is turned on. To turn the mirror on, press and hold the MIRROR button for three seconds.
Page 124 The mirror can be calibrated in one of two ways: Drive the vehicle in circles at five mph less until the display reads a direction, or Drive the vehicle your everyday routine. Compass Variance The mirror is set in zone eight upon leaving the factory. It will be necessary to adjust the compass to compensate for compass variance if you live outside zone eight.
Page 125 Electrochromic Inside Rearview Mirror with Compass and Temperature Display (If Equipped) Your vehicle may have electrochromic inside and outside rearview mirrors. When on, an electrochromic mirror automatically dims to the proper level to minimize glare from lights you after dark. The mirror also includes a display in the upper right corner of the mirror.
Page 126 The normal display will show a temperature reading in Celsius. If an abnormal reading is degrees Fahrenheit displayed, please consult your dealer. Electrochromatic Mirror Operation The right side of the switch, labeled TEMP, located at the bottom of the mirror turns the electrochromic inside and outside mirrors on and off.
Page 127 adjust for compass variance: 1. Use the COMP button located at the bottom of the mirror. 2. Press and hold the COMP button for three seconds until a zone number appears in the display. 3. Find your current location and variance zone number on the following zone map.
Page 128 (If Equipped) your vehicle is equipped with the camper type so you can have a clear mirrors, they can be adjusted view objects behind you. 2-50 1. To adjust the mirrors when hauling a slide-in camper or towing a trailer, rotate the mirror by pushing the mirror head toward the front of the vehicle.
Page 129 2. Rotate the mirror head, so that the mirror surface faces the rear of the vehicle. Electric Outside Rearview Mlrrors (If Equipped) you have electric mirrors, thgy point where you want from inside the vehicle. Select the mirror you want to move by moving the center of the switch, located on the driver’s door armrest,...
Page 130 Electrochromic Outside Rearview Mirrors (If Equipped) These outside rearview mirrors feature an auto-dimming and defrost mode, To turn on the auto-dimming feature, press and hold inside rearview mirror TEMP button for six seconds. See “Electrochromic Inside Rearview Mirror with Compass and Temperature Display” earlier in this section for further information.
Page 131 Installing a Garage Door Opener If you have a garage door opener, the front overhead compartment can be used to conveniently store the opener. I . To install the garage door opener, first open the compartment door by pressing the release button forward.
Page 132 5. Now, with the compartment door closed, push the button marked PUSH to make sure the garage door opener operates properly. With the garage door opener positioned properly and the right number of pegs in place, you should only have to push the PUSH button slightly to operate the opener.
Page 133 Rear Compartment The rear compartment can be used to store a small item, like a book. To open the rear compartment, press the release button located at the rear the compartment door. Instrument Panel Cupholder YOLU- vehicle has a cupholder in the middle of the instrument panel.
Page 134 Your console also has a cupholder that swings out for the back seat passengers to use. There is also a drawer that slides out from the bottom of the console. 2-56 Your vehicle may have a memo holder attached to the front of the console.
Page 135 The cassettekompact disc holder can be removed and replaced with a cupholder that is located in the center console storage area. To remove the cassette/compact disc holder, pull the front of the holder toward you and then lift it up. To insert the cupholder, place it in the console.
Page 136 The storage compartment also has a folding writing table on the top of the armrest. lid. To use the writing table, pull the latch at the rear of the table and swing the writing table forward. Use it to hold a pen.
Page 137 Convenience Net (If Equipped) If you have a convenience net, it is stored in a pouch attached to the spare tire. Cargo Security Shade (4-DoOr Utility Model) f--A,,ZTTION: An improperly stored cargo cover could be thrown about the vehicle during a collision or sudden maneuver.
Page 138 To put the shade in the vehicle, first make sure the shade slot in the holder faces rearward with the round surface facing down. Then, hold the shade at an angle and place the shade holder tab into the slot in the passenger’s side trim panel.
Page 139 Luggage Carrier (If Equipped) If you have the optional luggage carrier, you can load things on top of your vehicle. The luggage carrier has slats and side rails attached to the roof, and crossrails which can be moved toward the front or the rear in the side rails to help secure cargo.
Page 140 For the purpose of wind noise reduction, locate the front crossrail approximately 18 to 24 inches (46 cln to 58 cm) rearward of the front supports. After moving the crossrails, be sure to tighten all the slider screws. Your vehicle has a Center High-Mounted Stoplamp (CHMSL) located above the tailgate glass or above the rear load doors.
Page 141 Rear Ashtray To use a rear ashtray, if you have them, pull at the top of the ashtray door to flip the door open. To remove a rear ashtray, press down on the inside tabs and open the door fully. To use the cigarette lighter, push it in all the way, and let go.
Page 142 Transmitter Universal Sun Visors To block out glare, you can swing down the visors. You can also swing them out to help block glare at the front and side windows. Your visor may have a strap to hold small items, such as maps.
Page 143 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 144 If you have trouble programming the universal transmitter, make sure that you have followed the directions exactly as described and that the battery in the hand-held transmitter is not dead. If you still cannot program it, rotate the hand-held transmitter end over end and try again.
Page 145 To program a garage door opener with the rolling code feature, do the following: 1. Program your hand-held transmitter to the universal transmitter by following the steps provided under “Programming the Transmittel“ earlier in this section. 2. Remove the cover panel from the garage door opener receiver.
Page 146 Instrument Panel 2-68...
Page 147 A. Dome Lamp Switch B. Lamp Controls C. Air Outlets D. Multifunction Lever E. Instrument Cluster E Gearshift Lever G. Audio System H. Comfort Control System I. Glove Box J . Ashtray K. Cupholder L. Auxiliary Power Outlets M. Storage Area or Compact Disc Player (If Equipped) N.
Page 148 SECURITY ANTI LOCK oolo1 APPLY BRAKE SHIFT FROM PARK 2-70...
Page 149 Speedometer and Odometer Your speedometer lets you see your speed in both miles per hour (mph) and kilometers per hour (km/h). Your odometer shows how fa- your vehicle has been driven. in either miles (used in the United States) or kilometers (used in Canada).
Page 150 Warning lights come on when there may be or is a problem with one of your vehicle’s functions. As will see i n the details on the next few pages, some on briefly when you start the warning lights come engine just to let you know they’re working.
Page 151 This light will come on when you start your engine, Ai R and it will flash for a few seconds. Then the light should go out. This means the system is ready. If the air readiness light stays on after you start the engine or comes on when you are driving, your air bag system may not work properly.
Page 152 Voltmeter When your engine is not running, but the ignition is i n the RUN position, this gage shows your battery’s state of charge in DC volts. ” When the engine is running, the gage shows the condition of the charging system. Readings between the and high warning zones indicate operating range.
Page 153 This light should come on briefly when you turn the. ignition key to RUN. If doesn‘t come on then, have it fixed so it will be BRAKE ready to warn you if there‘s a problem. If the light comes on while you are driving, pull off the road and stop carefully.
Page 154 Engine Coolant Temperature Gage This gage shows the engine coolant temperature. *\\I‘ /I//, also provides an indicator of how hard your vehicle is working. During majority of the operation. the gage will read 210°F (100°C) or less. If you are pulling load or going up hills, is normal for the temperature to fluctuate and approach the 260”F( 160°C) mark.
Page 155 NOTICE: If you keep driving your vehicle with this light on, after a while, your emission controls may not work as well, your fuel economy may not be as good and your engine may not run as smoothly. This could lead to costly repairs that may not be covered by your warranty.
Page 156 If‘ the Light Is On Steady You may be able to correct the emission system malfunction by considering the following: Did you recently put fuel into your vehicle‘? If so, reinstall the fuel cap, making sure to fully install the cap. The diagnostic system can determine if the fuel cap has been left off improperly installed.
Page 157 Oil Pressure Gage The oil pressure gage shows the engine oil pressure in psi (pounds per square inch) when the engine is running. Canadian vehicles indicate pressure in Oil pressure may vary with engine speed, outside temperature and oil viscosity, but readings above the low pressure zone indicate the normal operating range.
Page 158 Security Light This light will come o n briefly when you turn the SECURITY The light will stay on until the engine starts. If the light flashes, the Passlock System has entered mode. If the vehicle fails to start, see “Passlock” in the Index.
Page 159 Daytime Running Lamps (DRL) Indicator Light :::O This light will go on whenever the DRL are on. 0 . . When begins get dark, the DRL indicator light is reminder to turn your headlamps. Check Gages Light This light will come on briefly when you are starting the engine.
Page 160 Fuel Gage When the ignition is on, the fuel gage tells you about how much fuel you have left in your tank. The gage will first indicate EMPTY (E) before you are out of fuel, and you should get more fuel possible.
Page 161 NOTES 2-83...
Page 162 NOTES 2-84...
Page 163 Section 3 Comfort Controls and Audio Systems In this section, you’ll find out how to operate the comfort control and audio systems offered with your vehicle. Be sure to read about the particular systems supplied with your vehicle. Comfort Controls Rear Comfort Controls (If Equipped) Air Conditioning Heating...
Page 164 Comfort Controls Heater Control System Fan Knob The knob on the left side of the heating system control panel controls the fan speed. The knob has four speed positions. To increase airflow, move the knob toward HI. To decrease airflow, move it toward LO. To turn the fan off, move the knob OFF.
Page 165 Heater and Air Conditioning Control System (If Equipped) Fan Knob The knob the left side of the heating system control 0 1 1 panel controls the speed. The knob has four speed positions. To increase airflow, move the knob toward HI.
Page 166 Rear Air Conditioning and Heating Systems (If Equipped) If your vehicle has one of these systems, you can increase and decrease the airflow at the rear vents. Depending on the system you have and the setting selected. you can send cooled or heated air to the rear of the vehicle.
Page 167 Rear Heater (Without Rear Air Conditioning) (If Equipped) If you have a rear heater (without rear air conditioning), the control switch is located on the instrument panel. To increase and decrease the flow of heated air to the rear floor vents, move the switch marked REAR HEAT to the blower speed you want.
Page 168 are used for air conditioning Generally, the upper vents and the floor vents for heating. The control knob can be set to any blend setting. To adjust the air temperature, turn the temperature knob on the right of the control panel. For warmer air, turn the knob to the right toward the red, and for cooler air, turn the knob to the left.
Page 169 With the A/C on, move the temperature knob to MAX for maximum cooling. This setting also puts the system in the recirculation mode and helps to maximize your air conditioner’s performance and your vehicle’s fuel economy. This setting also cools the air the fastest. After the vehicle’s interior reaches a comfortable temperature, move the temperature knob to the right to place the air conditioning system in the normal mode.
Page 170 Your center and on the sides vehicle has outlets of your instrument can move panel. You side-to-side and down to direct When you close the outlets altogether. air corning out will increase the flow that .open. These outlets do not completely shut off airflow when in dosed vent position.
Page 171 Rear Window Defogger (If Equipped) If you see lines running across the rear window, you have a rear window defogger. The lines warm the glass. To turn on the rear window defogger, press this button next to the fan control knob. The rear window defogger will only work if the igllition switch is turned...
Page 172 Audio Systems Your Delco@ Electronics audio system has been designed to operate easily and give years of listening pleasure. You will get the most enjoyment out of you acquaint yourself with it first. Find out what your Delco Electronics system can do and how to operate all its controls, to be sure you’re getting the most out of the advanced engineering that went into it.
Page 173 TUNE: Turn the lower knob to tune i n radio stations. SEEK: Press the right arrow to tune to the next higher station and the left arrow to tune to the next lower station and stay there. SCAN: Press both SEEK buttons to listen to seconds of each radio station.
Page 174 AM-FM Stereo with Cassette Tape Player (If Equipped) Playing the Radio VOLUME: This knob turns the syste.111 on controls the volume. To increase volume and turn the radio on, turn the knob to the right. Turn it to the left to decrease volume.
Page 175 In addition to the four stations already set, up more stations may be preset on each band by pressing two adjoining buttons at the same time. Just: 1 . Tune i n the desired station. 2. Press SET. (SET will appear on the display.) 3.
Page 176 CLN: If this message appears on the display, the cassette tape player needs to be cleaned. It will still play tapes, but you should clean it as soon as possible to prevent damage to the tapes and player. See “Care of Your Cassette Tape Player”...
Page 177 Finding a Station ANI-FM: Press this button to switch between AM: FMl and FM2. The display will show your selection. TUNE: Press this knob lightly so it extends. Turn it to choose radio stations. Push the knob back into its stored position when you’re not using SEEK: Press the right arrow to tune to the next higher station and the left arrow to tune to the next...
Page 178 TREB: Press lightly on this knob to release it from its stored position. Turn the knob to the right to increase treble and to the left to decrease treble. When the control is rotated, the AUTO TONE display will go blank.
Page 179 Once the tape is playing, use the VOL: AUTO TONE, BAL, FADE. BASS and TREB controls just as you do for the radio. The tape symbol and be on the display whenever a tape is being played. Anytime a tape is inserted, the top side is selected for play first.
Page 180 (6): Press this button to rapidly forward the tape to the end of the cassette or until you press The radio will play the last selected station while forwarding the tape. The tape direction arrow will blink during the forward operation. AM-FM: Press this button switch from a tape to...
Page 181 AM-FM Stereo with Compact Disc Player and Automatic Tone Control (If Equipped) Playing the Radio PWR-VOL: Press this knob to turn the system on and off. To increase volume, turn this knob to the right. Turn to the left to decrease volume. The knob is capable of rotating continuously.
Page 182 PUSHBUTTONS: The six numbered pushbuttons let you return to your favorite stations. You can set up to 18 stations (six AM. six FM and six FM2). Just: Turn the radio on. 2. Press AM-FM to selecl the band. 3. Tune in the desired station. 4.
Page 183 Adjusting the Speakers BAL: Press lightly on this knob to release stored position. Turn the control to the right to adjust sound to the right speakers and to the left to adjust sound to the left speakers. The middle position balances the sound between the speakers.
Page 184 REV (4): Press and hold REV to return rapidly favorite passage. You will hear the disc selection play at high speed while you press the REV button. This allows you to listen and find out when the disc is at the desired selection.
Page 185 Remote Compact Disc Player (If Equipped) If you have this option, you can play one compact disc (CD) at a time. To load CD into the player. hold the disc with the label side up and insert it carefully into the player (approximately halfway).
Page 186 (4): Press and hold this button to quickly reverse within a track. As the CD reverses, elapsed time will be displayed to help you find the correct passage. FWD (6): Press and hold this button to quickly advance within a track. As the CD advances, elapsed time displayed to help you find the correct passage.
Page 187 Activating the Theft-Deterrent Feature The instructions which follow explain how to enter your secret code to activate the THEFTLOCK system. recommended that you read through all nine steps before starting the procedure. NOTE: I f yo11 allow more than IS seconds to elapse between any steps, the radio autolnatically reverts to time and you must start the procedure over at Step 4.
Page 188 If you enter the wrong code eight times, INOP You will have to wait an 11our appear on the display. with the ignition on before you can try again. When you try again, will only have three chances to enter the correct code before lNOP appears.
Page 189 Understanding Radio Reception AM stations is greater than for FM, The range for most especially at night. The longer range, however, can cause stations to interfere with each other. AM can pick up noise from things like storms and power lines. Try reducing the treble to reduce this noise if you ever get it.
Page 190 Care of Your Cassette Tape Player tape player that is not cleaned regularly can cause reduced sound quality, ruined cassettes or mechanism. Cassette tapes should be stored in their cases away from contaminants, direct sunlight and extreme heat. If they aren‘t, they may not operate properly or m y cause failure of the tape player.
Page 191 When the cleaning cassette has been ejected, the broken tape detection feature is active again. After you clean the player, press and hold EJECT for five seconds to reset the CLN indicator. The radio will display to show the indicator was reset. Cassettes are subject to wear and the sound quality may degrade over time.
Page 192 NOTES 3-30...
Page 193 Section 4 Your Driving and the Road Here you'll find infor~nation about driving on different kinds of roads and in varying weather conditions. We've also included many other useful tips on driving. 4- 2 Defensive Driving Drunken Driving Control of a Vehicle Braking Steering 4-1 1...
Page 194 Defensive Driving The best advice anyone can give about driving is: Drive defensively. Please start with a vesy important safety device vehicle: Buckle up. (See "Sakty Belts" i n the Indcx.) Defensive driving really means '*be ready for anything. On city streets. rural roads or freeways. "always expect the unexpected."...
Page 195 Police records show that almost half of all motor vehicle-related deaths involve alcohol. In most cases, these deaths are the result of someone who was drinking and driving. In recent years, over 17,000 annual motor vehicle-related deaths have been associated with the use of alcohol, with more than 300,000 people injured.
Page 196 It’s the amount of alcohol that counts. For example, if the same person drank three double martinis (3 ounces or 90 ml of liquor each) within an hour, the person’s BAC would be close to 0.12 percent. A person who consumes food just before or during drinking will have a somewhat lower BAC level.
Page 197 Drinking and then driving is very dangerous. Your reflexes, perceptions, attentiveness and judgment can be affected by even a small amount of alcohol. You can have a serious fatal collision if you drive after drinking. Please don’t drink and drive or ride with a driver who has been drinking.
Page 198 Braking action involves perception time and recrctior? time. First, you have to decide to push on the brake pedal. That’s perception tir~e. Then you have to bring up your foot and do it. That’s rccrction time. Average reaction time is about 3/4 of a second. But that‘s only an average.
Page 199 Anti-Lock Brakes (ABS) Your vehicle has anti-lock brakes (ABS). ABS is an advanced electronic braking system that will help prevent a braking skid. When you start your engine and begin to drive away. your anti-lock brake system will check itself. You may hear momentary motor or clicking noise while this test is going on.
Page 200 The anti-lock system can change the brake pressure faster than any driver could. The computer is programmed to make the most of available tire and road conditions. You can steer around the obstacle while braking hard. As you brake, your computer keeps receiving updates on wheel speed and controls braking pressure accordingly.
Page 201 Steering Power Steering If you lose power steering assist because the engine stops or the system is not fi~nctioning, you can steer but it will take much more effort. Speed Sensitive Steering This system varies the amount of steering effort proportionate to your vehicle speed.
Page 202 Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and find a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 203 Off-Road Recovery You may find that your right wheels have dropped off the edge of a road onto the shoulder while you're driving. v / / / edge o f paved surface If the level of the shoulder is only slightly below the pavement, recovery should be fairly easy.
Page 204 Do not get too close to the vehicle you want pass while you’re awaiting an opportunity. For one thing, following t.oo closely reduces your area of vision, especially if you’re following a larger vehicle. Also, you won’t have adequate space if the vehicle ahead suddenly slows or stops.
Page 205 Loss of Control Let’s review what driving experts say about what happens when the three control systems (brakes, steering and acceleration) don’t have enough friction where the tires meet the road to do what the driver has asked. In any emergency, don’t give up. Keep trying to steer and constantly seek an escape route or area of less danger.
Page 206 Off-Road Driving with Your Four-Wheel-Drive Vehicle This off-road guide is for vehicles that have four-wheel drive. Also, see "Anti-Lock Brakes" in the Index. If your vehicle doesn't have four-wheel drive: you shouldn't drive off-road unless you're on solid surface. Off-road driving can be great fun. But have some definite hazards.
Page 207 Cargo on the load floor piled higher than the seatbacks can be thrown forward during a sudden stop. You or your passengers could be injured. Keep cargo below the top of the seatbacks. Unsecured cargo on the load floor can be tossed about when driving over rough terrain.
Page 208 Traveling to Remote Areas It makes sense to plan your trip, especially when going remote area. Know the terrain and plan your route. You are much less likely to get bad surprises. Get of trails and terrain. Try to learn of any accurate maps blocked or closed roads.
Page 209 Scanning the Terrain Off-road driving can take you over many different kinds of terrain. You need to be familiar with the terrain and its many different features. Here are some things to consider. Surface Conditions. Off-roading can take you over hard-packed dirt, gravel, rocks, grass, sand, mud, snow or ice.
Page 210 Driving on Off-Road Hills Off-road driving often takes you up, down or across a hill. Driving safely on hills requires good judgment and an understanding of what your vehicle can and can't There are some hills that simply can't be driven, no matter how well built the vehicle.
Page 211 Driving Uphill Once you decide you can safely drive up the hill, you need to take some special steps. Use a low gear and get a .firm grip on the steering wheel. Get a smooth start up the hill and try your speed.
Page 212 Q.’ What should I do if my vehicle stalls, or is about to stall, and can’t make it up the hill? If this happens, there are some things you should do, and there are some things you must not do. First, here’s what you s l ~ o ~ ~ l d Push the brake pedal to stop the vehicle and keep...
Page 213 &= Suppose, after stalling, I try to back down the hill and decide I just can’t do it. What should I do? Set the parking brake, put your transmission in PARK (P) and turn off the engine. Leave the vehicle and go get some help. Exit side and stay clear of the path the vehicle would take if it rolled downhill.
Page 214 Driving Downhill When off-roading takes you downhill, you'll want to consider a number of things: Will I be able How steep is the d o w ~ ~ h i l l ? vehicle control? What's the surface like? Smooth? Rough? Slippery? Hard-packed dirt? Gravel? Are there hidden surface obstacles'? Ruts:' Logs'? Boulders?
Page 215 Are there some things I should not do when driving down a hill? Yes! These are important because if you ignore them you could lose control and have serious accident. When driving downhill, avoid turns that take you across the incline of the hill. A hill that's not too steep to drive down may be too steep to drive across.
Page 216 Driving Across an Incline Sooner or later, an off-road trail will probably go across the incline of a hill. If this happens, you have to decide whether to try to drive across the incline. Here are some things to consider: A hill that can be driven straight up too steep to drive across.
Page 217 What if I’m driving across an incline that’s not too steep, but hit some loose gravel and start to slide downhill. What should I do? If you feel your vehicle starting to slide sideways, turn downhill. This should help straighten out the vehicle and prevent the side slipping.
Page 218 Driving in Mud, Sand, Snow or Ice you drive When i n mud, snow or sand, your wheels won’t get good traction. You can’t accelerate as quickly, turning is more difficult, and you’ll need longer braking distances. It’s best. to use a low gear when you’re i n mud -- the deeper the mud, the lower the gear.
Page 219 If the water isn’t too deep, then drive through it slowly. At fast speeds, water splashes on your ignition system and your vehicle can stall. Stalling can also occur if you get y o ~ ~ r tailpipe under water. And, tailpipe is under water, you’ll never be able engine.
Page 220 Driving at Night Night driving is more dangerous than day driving. One reason is that some drivers are likely to be impaired by alcohol or drugs, with night vision problems, or fatigue. Here are some tips on night driving. Drive defensively. Don't drink and drive.
Page 221 Night Vision No one can see as well at night as in the daytime. But we get older these differences increase. A 50-year-old driver may require at least twice as much light to see the same thing at night as a 20-year-old. What you do in the daytime can also affect your night vision.
Page 222 Driving in Rain and on Wet Roads Rain and wet roads can mean driving trouble. On a wet road, you can't stop, accelerate or turn your tire-to-road traction isn't as good as on dry roads. 4-30 And, if your tires don't have much tread left, you'll get even less traction.
Page 223 fdst through large water puddles or even Driving going through some car washes can cause problems, too. may affect your brakes. Try to avoid puddles. The water But if you can't, try to slow down before you hit them. Wet brakes can cause accidents. They won't work as well in a quick stop and may cause pulling to one side.
Page 224 Hydroplaning Hydroplaning is dangerous. So much water can build up under your tires that they can actually ride on the water. This can happen if the road is wet enough and you‘re going Fast enough. When your vehicle is hydroplaning, it has little or no contact with the road.
Page 225 City Driving One of the biggest problems with city streets is the amount of traffic on them. You’ll want to watch out for what the other drivers are doing and pay attention to traffic signals. Here are ways to increase your safety i n city driving: Know the best way to get to where you are going.
Page 226 Freeway Driving Mile for mile, freeways (also called thruways, parkways, expressways, turnpikes or superhighways) are the safest of all roads. But they have their own special rules. 4-34 The most important advice on freeway driving is: Keep with traffic and keep to the right. Drive L ~ I speed most of the other drivers are driving.
Page 227 When you want to leave the freeway, move to the proper lane well i n advance. I f you miss your exit, do not, under any circumstances. stop and back up. Drive on to the next exit. The exit ramp can be curved, sonletimes quite sharply. The exit speed is usually posted.
Page 228 Highway Hypnosis Is there actually such a condition as “highway hypnosis”? Or is it just plain falling asleep at the wheel? Call it highway hypnosis, lack of awareness, or whatever. There is something about an easy stretch of road with the same scenery, along with the h u m of the tires on the road, the drone of the engine, and the rush of the wind against the vehicle that can make you sleepy.
Page 229 If you drive regularly in steep country, or if you're planning to visit there, here are some tips that can make your trips safer and more enjoyable. (See "Off-Road Driving" in the Index for information about driving off-road.) Keep your vehicle in good shape. Check all fluid levels and also the brakes, tires, cooling system and transmission.
Page 230 Wi-nter Driving Here at-e some tips for winter driving: Have your vehicle in good shape for winter. You may want to put winter emergency supplies your vehicle. 4-38 Include an ice scraper, a small brush or broom, a supply of windshield washer fluid, a rag, some winter outer clothing, a small shovel, a flashlight, reflective warning triangles.
Page 231 What’s the worst time for this? “Wet ice.” Very cold snow or ice can be slick and hard to drive on. But wet ice can be even more trouble because it may offer the least traction of all. You can get wet ice when it’s about freezing (32°F;...
Page 232 If You're Caught in a Blizzard If you are stopped by heavy snow, you could be in serious situation. You should probably stay with your vehicle unless you know for sure that you are near help and you can hike tlvough the snow. Here are some things to do sunlmon help and keep yourself and your passengers safe:...
Page 233 Snow can trap exhaust gases under your This can cause deadly (carbon monoxide) gas to get inside. CO could overcome you and kill you. You can’t see it or smell it, so you might not know it is in your vehicle. Clear away snow from around the base of your vehicle, especially any that blocking your exhaust pipe.
Page 234 Shifting the transfer case into NEUTRAL (N) can cause your vehicle to roll even if the transmission is in PARK (P), for an automatic transmission. You or others could be injured. Make sure the parking brake is firmly set before you shift the transfer case into NEUTRAL (N).
Page 235 Four- Wheel Drive Vehicles Use the following proced~11-e to correctly tow your vehicle on all four wheels: Firmly set the parking brake. Place the transmission in PARK (P). Securely attach the vehicle being towed to t.he tow vehicle. With the engine running, shift the transfer case to NEUTRAL (Nj.
Page 236 The CertificatiodTire label also tells you the maximum weights for the front and rear axles, called Gross Axle Weight Rating (GAWR). To find out the actual loads on your front and rear axles, you need to go to a weigh station and weigh your vehicle.
Page 237 CAUTION: Things you put inside your vehicle can strike and injure people in a sudden stop or turn, or in a crash. Put things in the cargo area of your vehicle. Try to spread the weight evenly. Never stack heavier things, like suitcases, inside the vehicle so that some of them are above the tops ofthe seats.
Page 238 NOTICE: Pulling a trailer improperly can damage your vehicle and result in costly repairs not covered by your warranty. To pull a trailer correctly, follow the advice in this part, and see your dealer for important information about towing a trailer with your vehicle.
Page 239 If you have automatic transmission. you can in OVERDRIVE You may want to shift the (@). transmission to THIRD (3) or, if necessary, a lower gear selection if the transmission shifts too often (e.g.$ under heavy loads and/or hilly conditions). Three important considerations have to do with weight: the weight of the trailer, the weight of the trailer tongue...
Page 240 Vehicle C- 1500 (2WD) Utility K- 1500 (4WD) Utility C- 1500 (2WD) Suburban K- 1500 (4WD) Suburban 4-48 Axle Ratio Engine 3.08 5.7L 3.42 3.73 3.42 5.7L 3.73 3.42 6.5L Diesel 3.73 3.42 5.7L 3.73 3.42 6.5L Diesel 3.42 5.7L 3.73 3.42 6.SL Diesel...
Page 241 Vehicle K-2500 (4WD) Suburban Axle Ratio Engine 5.7L 3.73 4.10 6.5L Diesel 3.73 4.10 7.4L 3.73 4.10 4.10 5.7L 6.SL Diesel 3.73 4.10 7.4L 3.73 4.10 Max. Trailer Wt. 6.000 Ibs. (2 724 kg) 7,500 lbs. ( 3 405 kg) 6,500 Ibs.
Page 242 You can ask your dealer for our trailering information advice, or you can write us at the address listed i n your Warranty and Owner Assistance Information Booklet. In Canada, write to: General Motors of Canada Limited Customer Communication Centre 1908 Colonel Sam Drive Oshawa, Ontario L H 8P7...
Page 243 Total Weight on Your Vehicle’s Tires Be sure your vehicle’s tires are inflated to the upper limit for cold tires. You’ll find these numbers on the Certification label at the rear edge of the driver’s door or see ”Tire Loading” in the Index. Then be sure ”0 over the GVW l i m i t for your vehicle, including the weight of the trailer tongue.
Page 244 Trailer Brakes If your trailer weighs more than 1,000 lbs. (450 kg) loaded, then needs its own brakes adequate. Be s ~ r e to read and follow the instructions for the trailer brakes so you’ll be able to install, adjust and maintain them properly.
Page 245 Towing a trailer requires a certain amount of experience. Before setting out for the open road, you’ll want to get to know your rig. Acquaint yourself with the feel of handling and braking with the added weight of the trailer. And always keep in mind that the vehicle you are driving is now a good deal longer and not nearly as responsive as your vehicle is by itself.
Page 246 Making Turns NOTICE: Making very sharp turns while trailering could cause the trailer to come in contact with the vehicle. Your vehicle could be damaged. Avoid making very sharp turns while trailering. When you're turning with trailer, n ~ k e wider turns than nolmal.
Page 247 Parking on Hills You really should not park your vehicle. with a trailer attached, on hill. If something goes wrong, your rig could start to move. People can be in-jured, and both your vehicle and the trailer can be damaged. But if you ever have to park your rig on do it: Apply your regular brakes.
Page 248 When You Are Ready to Leave After Parking on a Hill 1. Apply your regular brakes and hold the pedal down while you: Start your engine; Shift into a gear; and Release the parking brake. 2. Let up on the brake pedal. 3.
Page 249 Additional Heavy-Duty Wiring A eight-wire harness is stored under the rear end of your vehicle. The five-wire light-duty harness is located at the left hand rear inner lower quarter panel. The additional heavy-duty wiring is located forward of the rear bumper and is attached to the center of the rear crossmember or the forward vertical surface of the platform hitch (if equipped).
Page 250 Power Winch If you wish to use a power winch on your vehicle, only use it when your vehicle is stationary or anchored. NOTICE: Using a power winch with the transmission in gear may damage the transmission. When operating a power winch, always leave the transmission in NEUTRAL (N).
Page 251 Sectic 5 Problems On The Road Here you’ll find what to do about some problems that can occur on the road. Hazard Warning Flashers Other Warning Devices JL~IIIP Starting Towing Your Vehicle 5-13 Engine Overheating (Gasoline Engines) 5- 15 Cooling System Gasoline Engines 5-22 Engine Fan Noise...
Page 252 Hazard Warning Flashers Your hazard warning flashers let you warn others. They also let police know you have a problem. Your front and rear turn signal lamps will flash on and off. Press the button at the top of the steering column all the way down to make your front and rear turn signal lamps flash on and off.
Page 253 Jump Starting If your battery (or batteries) has run down, you may want to use another vehicle and some jumper cables to start your vehicle. But please use the following steps to do it safely. NOTICE: Ignoring these steps could result in costly damage to your vehicle that wouldn’t be covered by your vehicle warranty.
Page 254 2. Get the vehicles close enough so the jumper cables can reach, but be sure the vehicles aren’t touching each other. If they are, it could cause a ground connection don‘t want. You wouldn’t be able to YOLI start your vehicle, and the bad grounding could damage the electrical systems.
Page 255 CAUTION: near a battery can cause battery gas to explode. People have been hurt doing this, and some have been blinded. Use a flashlight if you need more light. Be sure the batteries have enough water. You don’t need to add water to the Delco Freedom@ battery (or batteries) installed in every new GM vehicle.
Page 256 6. Connect the red positive cable to the positive terminal of the vehicle with the dead battery. 8. Now connect the black negative cable to the good battery's negative cable. Don't let the other end touch anything until the next step. The other end of the negative cable doesn't go to the dead...
Page 257 Attach the cable at least 18 inches (45 cm) away from the dead battery, but not near engine parts that move. The electrical connection is just as good there, but the chance of sparks getting back to the battery much less. Now start the vehicle with the good battery and run the engine for a while.
Page 258 Towing Your Vehicle Try to have your GM dealer or a professional towing service tow your vehicle. See “Roadside Assistance?’ i n the Index. If your vehicle has been changed since factory-new, by adding such things as fog lamps, aero skirting, or special tires and wheels, these things could be damaged during towing.
Page 259 A vehicle can fall from a car carrier if it isn’t adequately secured. This can cause a collision, serious personal injury and vehicle damage. The vehicle should be tightly secured with chains or steel cables before it is transported. Don’t use substitutes (ropes, leather straps, canvas webbing, etc.) that can be cut by sharp edges underneath the towed vehicle.
Page 260 Two-Wheel-Drive Vehicles If your vehicle is two-wheel drive, use the following directions: 1. Engage the parking brake. 2. Turn the ignition key to OFF. 3. Clamp the steering wheel in a straight-ahead position with a clamping device designed for towing service. not use the vehicle’s steering column lock for this.) 4.
Page 261 Rear Towing Two- Wheel-Drive Vehicles Limits 55 ~ n p h Torr: ( 8 8 k111/11) lrlllimitecl c l i s t c r t l c r If your vehicle is two-wheel drive, use the following directions: Engage the parking brake. Turn the ignition key to OFF.
Page 262 Four-Wheel-Drive Vehicles If your vehicle is four-wheel drive, use the following directions: I . Engage the parking brake. 2. Turn the ignition key to ON. 3. Clamp the steering wheel in a straight-ahead position with a clamping device designed for towing service. (Do not use the vehicle’s steering column lock for this.) 4.
Page 263 Engine Overheating (Gasoline Engine) You will find a coolant temperature gage vehicle’s instrument panel. See “Engine Coolant Temperature Gage” in the Index. I f your vehicle has a diesel engine, see “Engine Overheating” in the Diesel Engine Supplement. If Steam Is Coming From Your Engine on your Steam from an overheated engine can burn you badly, even if you just open the hood.
Page 264 If No Steam Is Coming From Your Engine I f you get the overheat warning but see or hear no steam, the problem may not be too serious. Sometimes the engine can get a little too hot when you: Climb a long h i l l on a hot day. Stop after high-speed driving.
Page 265 Cooling System Gasoline Engines When you decide it’s safe to lift the hood, here’s what you’ 11 see: A. Coolant Recovery Tank B. Radiator Pressure Cap C. Engine Fan(s) If your vehicle has air conditioning, the auxiliary electric engine cooling fan under the hood can start up even when the engine is not running and can injure you.
Page 266 If it isn’t, you may have a leak i n the radiator hoses, heater hoses, radiator, water pump or somewhere else the cooling system. Heater and radiator hoses, and other engine parts, can be very hot. Don’t touch them. If you do, you can be burned.
Page 267 NOTICE: In cold weather, water can freeze and crack the engine, radiator, heater core and other parts. Use the recommended coolant and the proper coolant mixture. You can be burned if you spill coolant on hot engine parts. Coolant contains ethylene glycol and it will burn if the engine parts are hot enough.
Page 268 CAUTION: Steam and scalding liquids from a hot cooling system can blow out and burn you badly. They you turn the radiator are under pressure, and if pressure cap even a little they can come out at high speed. Never turn the cap when the cooling system, including the radiator pressure cap, is hot.
Page 269 How to Add Coolant to the Radiator 1. You can remove the radiator pressure cap when the cooling system, including the radiator pressure cap and upper radiator hose, is no longer hot. Turn the pressure cap slowly counterclockwise until it first stops.
Page 270 3. Fill the radiator with the proper DEX-COOL@ coolant mixture, up to the base of the filler neck. (See “Engine Coolant” in the Index for more information about the proper coolant mixture.) 5-20 4. Then fill the coolant recovery tank to the COLD mark.
Page 271 6. Start the engine and let it run until you can feel the upper radiator hose getting hot. Watch out for the engine cooling fan(s). 7. By this time, the coolant level inside the r* filler neck may be lower. I f the level is lower, add more of the proper DEX-COOL@ coolant mixture through the filler neck until the level reaches the base of the filler neck.
Page 272 Engine Fan Noise Your vehicle has a clutched engine cooling fan. When the clutch is engaged, the fan spins faster to provide more air to cool the engine. In most everyday driving conditions, the fan is spinning slower and the clutch is not fully engaged.
Page 273 ciiuge an Changing a tire can injury. The vehicle can slip off the jack and roll over you or other people. You and they could be badly injured. Find a level place to change your tire. To help prevent the vehicle from moving: 1.
Page 274 &Door Utility Models A. Hoist Assembly B. Hoist Shaft C. Ratchet D. Jack Handle E. Retainer E Vdve Stern, Pointed Down G . Spare Tire 5-24 Follow these instructions to lower the spare tire: One side of the ratchet has an UP marking. The other side has a DOWN marking.
Page 275 To take the jack out, turn the wing nut to the left and take it and the retainer off. Take the jack and storage box out and take the tools out of the box. a pair of emergency gloves Your vehicle may have secured to the jack.
Page 276 To take the jack out, turn the wing nut to the left and take it and the retainer off. Take the -jack and storage box out and take the tools out of the box. Your vehicle may have a pair of emergency gloves secured to the jack.
Page 277 DOWN Marking UP Marking One side of the ratchet has an UP marking. The other With the UP marking on the ratchet filcing side has a DOWN marking. the jack head rotate the ratchet to the right. That will lift a little.
Page 278 If your vehicle has wheel nut caps, use the wheel wrench and ratchet to remove them. Turn the wheel wrench to the left, with DOWN facing you, to remove the wheel nut caps. Then take off the hub cap. also If the wheel trim ring, use the wheel wrench to pry along the edge and remove it.
Page 279 Front Position 3. Position the jack under the vehicle. If the flat tire is on the front of the vehicle, position the jack on the frame behind the flat tire. If the flat tire is on the rear o f the vehicle, position the jack on the axle near the flat tire between spring and the shock absorber.
Page 280 Front Position 4. With UP on the ratchet facing you, raise the vehicle by rotating the ratchet and wheel wrench to the right. Raise the vehicle far enough off the ground so there is enough room for the spare tire to fit. 5-30 Rear Position 5.
Page 281 Rust or dirt on the wheel, or on the parts to which it fastened, make the wheel nuts become loose after a time. The wheel could come off and cause accident. When you change a wheel, remove any rust dirt from the places where the wheel attaches to the vehicle.
Page 282 Front Position 8. Lower the vehicle by rotating the ratchet and wheel wrench to the left. Lower the jack completely. 5-32 Rear Position Tighten each wheel nut by rotating the wheel wrench to the sight.
Page 283 :_> ( - J ( - - - J 10. Tighten the nuts firmly i n a crisscross sequence shown. Rotate the wheel wrench to the right. Incorrect wheel nuts or improperly tightened wheel nuts can cause the wheel to become loose and even come off‘.
Page 284 NOTICE: Improperly tightened wheel nuts can lead to brake pulsation and rotor damage. To avoid expensive brake repairs, evenly tighten the wheel nuts in the proper sequence and to the proper torque specification. 1 1. Put the wheel trim back on. For vehicles with plastic wheel nut caps, tighten the caps until they are finger tight, then tighten them an additional one-half of a turn with the ratchet and wheel wrench.
Page 285 Jacking Tool Storage A. Wheel Wrench B. Jack Handle C. Ratchet D. Jacking Tool Storage Box E. Jack Handle Extension Jack Storage 2-Door Utility Model Retainer B. Nut C. Jack D. Jack Storage Box E. Bracket 5-35...
Page 286 Jack Storage 4-Door Utility Model A. Retainer B. Nut C. Jack D. Jack Storage Box E. Bracket 5-36 ,Jack Storage Suburban A. Retainer B. Nut C. Jack Storage Box D. Bracket E. Jack...
Page 287 Store the flat tire i n the cargo area of two-door utility and Suburban models and secure store the flat tire: I . Put the cover back on the tire if your vehicle has one. 2. Put the tlat tire i n cargo area of the vehicle, over the retainer bolt.
Page 288 Spare Tire Suburban 1. I-Bolt 6. Nut 2. J-Bolt 7. Cover Carrier 8. Use Lower Adapter Hole for eight-Lug 4. Spare Tire Rim Only 5 . Adapter Be sure the J-bolt is hooked properly for your model or tire size as shown. 5-38 Spare Tire 4-Door Utility Model...
Page 289 For four-door utility models equipped with an underbody spare tire carrier, follow these instructions to restore a spare or flat tire: Lay the tire on the ground at the rear of the vehicle. Position the tire so that the valve stem is pointed down and to the rear of the vehicle.
Page 290 NOTICE: Spinning your wheels can destroy parts of your vehicle as well as the tires. If you spin the wheels too fast while shifting your transmission back and forth, you can destroy your transmission. For information about using tire chains see "Tire Chains"...
Page 291 CAUTION: The recovery hooks, when used, are under a force. Always pull the vehicle straight out. Never pull on the hooks at a sideways angle. The hooks could break off and you or others could be injured from the chain or cable snapping back. NOTICE: Never use the recovery hooks to tow the vehicle.
Page 292 NOTES 5-42...
Page 293 Section 6 Service and Appearance Care Here you will find information about the care of your vehicle. This section begins with service and fuel information, and then it shows how to check important fluid and lubricant levels. There is also technical information about your vehicle, and part devoted to its appearance care.
Page 294 Service Your dealer knows your vehicle best and wants you to be happy with it. We hope you’ll go to yo~lr dealer for a l l your service needs. You’ll get genuine GM parts and GM-trained and supported service people. We hope you’ll want to keep your GM vehicle all GM.
Page 295 You can be injured and your vehicle could be damaged if you try to do service work on a vehicle without knowing enough about it. Be sure you have sufficient knowledge, experience, the proper replacement parts and tools before you attempt any vehicle maintenance task.
Page 296 sure the posted octane is at least 87. If the octane is less than 87, you may get heavy knocking noise when you drive. If it’s bad enough, it can damage your engine. If you’re using fuel rated at 87 octane or higher and you hear heavy knocking, your engine needs service.
Page 297 To provide cleaner air, all gasolines are now required to contain additives that will help prevent deposits from ,forming in your engine and fuel system, allowing your emission control system to function properly. Therefore, you should not have to add anything to the fuel.
Page 298 Filling Your Tank (Gasoline Engine) If your vehicle has a diesel engine, see “Filling Your in the Diesel Engine Supplement. Tank (Diesel Engine)” The fuel cap is located behind a hinged door on the left side of your vehicle. Gasoline vapor is highly flammable. It burns violently, and that can cause very bad injuries.
Page 299 To remove the cap, turn it slowly to the left (counterclockwise). If you get gasoline on yourself and then something ignites it, you could be badly burned. Gasoline can spray out on you if you open the fuel filler cap too quickly. This spray can happen if your tank is nearly full, and is more likely in hot weather.
Page 300 Filling a Portable Fuel Container CAUTION: a portable fuel container while it is in Never fill your vehicle. Static electricity discharge from the container can ignite the gasoline be badly burned and your vehicle damaged if this occurs. help avoid injury to Dispense gasoline into only...
Page 301 Hood Release To open the hood, first pull the handle inside the vehicle. Then go to the front of the vehicle and pull up on the secondary hood release, located just to the passenger’s side of the center of the grill. Lift the hood.
Page 302 “VORTEC” 5700 Engine When you lift up the hood you’ll see: 6-10...
Page 303 A. Battery B. Air Cleaner C. Radiator Cap D. Coolant Recovery Tank E. Air Filter Restriction Indicator E Engine Oil Dipstick G. Automatic Transmission Dipstick H. Fan I. Power Steering Fluid Reservoir J. Engine Oil Fill K. Brake Fluid Reservoir L.
Page 304 "VORTEC" 7400 Engine When you lift up the hood you'll see: 6-12...
Page 305 A. Battery B. Coolant Recovery Tdnk C. Air Cleaner D. Radiator Cap E. Air Filter Restriction Indicator F. Engine Oil Dipstick G. Automatic Transmission Dipstick H. Engine Oil Fill I. Fan J. Power Steering Fluid Reservoir K. Brake Fluid Reservoir L.
Page 306 Engine Oil (Gasoline Engine) I f your vehicle has a diesel engine. see “Engine Oil (Diesel Engine)” in the Diesel Engine Supplement. good idea to check your engine oil every time you It’s oet fuel. In order get an accurate reading, the o i l must be warm the vehicle must be on level ground.
Page 307 NOTICE: Don’t add too much oil. If your engine has so much oil that the oil level gets above the upper mark that shows the proper operating range, your engine could be damaged. The engine oil fill cap on the “VORTEC” 5700 is located on the driver’s side engine valve cover.
Page 308 RECOMMENDED SAE VISCOSITY GRADE ENGINE FOR BEST FUEL ECONOMY AND COLD STARTINC, S E L E 6 THE LOWEST cn,E VISCOSITY GRADE OIL FOR THE EXPECTED TEMPERATURE RANGE. LOOK FOR MIS WEATHER SYMBOL 1OW-30 1-30 COLD WEATHER DO NOT USE SAE 2OW-50 OR ANY OTHER GRADE OIL NOT RECOMMENDED 6-16 in the chart, SAE 5W-30 is best for your...
Page 309 Engine Oil Additives Don’t add anything to your oil. Your dealer is ready to advise if you think something should be added. When to Change Engine Oil If any one of these is true for YOLI, maintenance schedule: Most trips are less than 5 to 10 miles (8 to 16 km). This is particularly important when outside temperatures are below freezing.
Page 310 Air Cleaner (Gasoline Engines) Your air cleaner is located between the battery and coolant recovery tank. 6-18 The air cleaner assembly has an indicator that lets you know when the air filter is dirty and needs to be serviced. The indicator is located in the air intake tube between the air cleaner and the engine.
Page 311 To remove the air filter, unhook the retainer clips and remove the cover. Lift the filter and the connected duct out of the air cleaner housing. Hold the duct and remove the filter by both pulling and twisting the filter away from the duct.
Page 312 Refer to the Maintenance Schedule to determine when to replace the air filter. See “Owner Checks and Services” in the Index. Operating the engine with the air cleaner off can cause you or others to be burned. The air cleaner only cleans the air, it stops flame if the engine backfires.
Page 313 NOTICE: Too much or too little fluid can damage your transmission. Too much can mean that some of the fluid could come out and fall on hot engine parts or exhaust system parts, starting a fire. Be sure to get an accurate reading if you check your transmission fluid.
Page 314 With your foot on the brake pedal, move the shift lever through each gear range, pausing for about three seconds in each range. Then, position the shift lever in PARK (P). Let the engine run at idle for three minutes or more. off the engine, follow these steps: Then, without shutting The red transrnission dipstick is located at the rear of...
Page 315 How to Add Fluid Refer to the Maintenance Schedule to determine what kind of transmission fluid to use. See "Recommended Fluids and Lubricants" in the Index. Add fluid only after checking the transmission tluid while is hot. (A cold check is used only as a reference.) If the fluid level is low, add only enough of the proper fluid to bring the level up to the HOT area for a hot check.
Page 316 What to Use Refer to the Maintenance Schedule to determine what kind of lubricant to use. See “Recommended Fluids and Lubricants” in the Index. Four-wheel Drive Most lubricant checks in this section also apply to four-wheel-drive vehicles. However, they have two additional systems that need lubrication.
Page 317 Automatic Transfer Case I f the level below the bottom of the filler plug hole, you‘ll need to add some lubricant. Add enough lubricant to raise the level the bottom of the filler plug hole. What to Use Refer to the Maintenance Schedule to determine what kind of lubricant to use.
Page 318 When the differential is cold, add enough lubricant to 1/2 inch (12 raise the level to m m ) plug hole. When the differential is at operating temperature (warm), add enough lubricant to raise the level to the bottom of the filler plug hole. What to Use Refer to the Maintenance Schedule to determine what kind of lubricant to use.
Page 319 What to Use Use a mixture of one-half w t e r (preferably c'1e'~m distilled) and one-half DEX-COOL@ coolant which won't damage alu~ninum parts. If you use this mixture, you don't need to add anything else. Adding only plain water to your cooling system can be dangerous.
Page 320 Checking Coolant The coolant recovery tank is located on the passenger's side at the rear corner of the engine compartment. When your engine is cold, the coolant level should be at the COLD mark, or a little higher. When your engine is warm, the level should be up to the HOT mark, or a little higher.
Page 321 Radiator Pressure Cap The radiator pressure cap must be tightly installed with the arrows on the cap lined up with the overflow tube on the radiator filler neck. NOTICE: Your radiator cap is a 15 psi (105 kPa) pressure-type cap and must be tightly installed to prevent coolant loss and possible engine damage from overheating.
Page 322 Power Steering Fluid When to Check Power Steering Fluid not necessary to regularly check power steering It is fluid unless you suspect there is a leak in the system or you hear an unusual noise. A fluid loss in this system could indicate a problem.
Page 323 Windshield Washer Fluid What to Use When you need windshield washer fluid, be sure to read the manufacturer’s instructions before use. If you will be operating your vehicle in an area where the temperature may fall below freezing, use fluid that has sufficient protection against freezing.
Page 324 Brakes Brake Fluid Your brake master cylinder reservoir is here. It is filled with DOT-3 brake fluid. There are only two reasons why the brake fluid level in the reservoir might go down. The first is that the brake fluid goes down an acceptable level during normal brake lining wear.
Page 325 Checking Brake Fluid You can check the brake fluid without taking Just look at the brake fluid reservoir. The fluid level should be above MIN. If it isn’t, have your brake system checked to see if there is a leak. After work is done on the brake hydraulic system, make sure the level is above the MIN but not over the MAX mark or the top of the window on the side of...
Page 326 NOTICE: Using the wrong fluid can badly damage brake system parts. For example, just a drops of mineral-based oil, such as engine oil, in your brake system can damage brake system parts so badly that they’ll have to be replaced. Don’t let someone put in the wrong kind of fluid.
Page 327 Your rear drum brakes don’t have wear indicators, but if you ever hear rear brake rubbing noise, have the rear brake linings inspected immediately. Also, the rear brake drums should be removed and inspected each time the tires are removed for rotation or changing. When you have the front brake pads replaced, have the rear brakes inspected, too.
Page 328 Battery Every new vehicle has a Delco Freedom’ battery. You never have to add water to one of these. When it’s time for a new battery, we recommend a Delco Freedom battery. Get one that has the replacement number shown the original battery’s label.
Page 329 3. Unplug and remove Sealed Beam Headlamps the headlamp. 1. Remove the four screws from the headlamp retainer. 4. Plug in the new headlamp and put in place. 5 . Install the retainer to the headlamp and tighten 2. Pull the headlamp out and remove the retainer the screws.
Page 330 Composite Headlamps I . Remove the two hex head pins at the top of the radiator support, as shown. 2. Pull the headlamp lens assembly out. 6-38 3. Unplug the electrical connector. 4. Turn the bulb to the left and remove it. 5.
Page 331 Front Parking/Turn Signal Lamps with Sealed Beam Headlamps 1. Remove the two screws at the inside edge of the parking/turn signal lamp assembly. 2. Remove the lamp assembly by swinging the inside edge and sliding it out at the outside edge. 3.
Page 332 Front Parking/Turn Signal Lamps with Composite Headlamps 1. Remove the four screws and take out the parkingkurn signal lamp assembly. 2. Squeeze the tab on the side of the lamp socket while turning the socket to the left. 6-40 3. Pull the socket out of the lamp assembly.
Page 333 Sidemarker Lamps with Sealed Ream and Composite Headlamps Remove the four screws and pull out the parking/turn signal lamp assembly. 2. Reach through the opening and turn the sidemarker bulb socket to the left and remove 4. Put a new bulb into the socket and push is tight.
Page 334 Roof Marker Lamps 1. Remove the screws and lift off the lens. 2. PLIH the bulb straight out of the socket. 3. Put a new bulb into the socket and push it in until is tight. 4. Replace the lens and tighten the screws. Rear Lamps 1.
Page 335 Windshield Wiper Blade Replacement For proper type and length, see “Normal Maintenance Replacement Parts” in the Index. To replace the windshield wiper blade assembly: 1. Lift the wiper arm and rotate the blade until it is facing away from the windshield. 2.
Page 336 Poorly maintained and improperly used tires are dangerous. Overloading your tires can cause overheating as a result of too much friction. You could have an air-out and a serious accident. See “Loading Your Vehicle” in the Index. Underinflated tires pose the same danger as overloaded tires.
Page 337 NOTICE: Don’t let anyone tell you that underinflation or overinflation is all right. It’s not. If your tires don’t have enough air (underinflation get the following: Too much flexing Too much heat Tire overloading Bad wear Bad handling Bad fuel economy. If your tires have too much air (overinflation you can get the following: Unusual wear...
Page 338 The purpose of regular rotation is to achieve more uniform wear for all tires on the vehicle. The first rotation is the most important. See “Scheduled Maintenance Services” in the Index for scheduled rotation intervals. When rotating your tires, always use one of the correct rotation patterns shown here.
Page 339 When It’s Time for New Tires One way to tell when it’s time for new tires is to check the treadwear indicators, which will appear when your tires have only 1 /16 inch (1.6 less of tread remaining. You need a new tire if any of the following statements are true: You can see the indicators at three or more places around the tire.
Page 340 Mixing tires could cause you to lose control while driving. If you mix tires of different sizes or types (radial and bias-belted tires), the vehicle may not handle properly, and you could have a crash. Using tires of different sizes may also cause damage to your vehicle.
Page 341 may depart significantly from the norm due to variations in driving habits, service practices and differences in road characteristics and climate. € 3 , Traction The traction grades, from highest to lowest, are C, and they represent the tire’s ability to stop on wet measured under controlled conditions on pavement specified government test surfaces of asphalt and concrete.
Page 342 Each new wheel should have the same load-carrying capacity, diameter, width, offset and be mounted the same way as the one it replaces. If you need to replace any of your wheels, wheel bolts or wheel nuts, replace them only with new GM original equipment parts.
Page 343 Tire Chains NOTICE: If your vehicle has P265/75R16 or IlT265/75R1 6 size tires, don’t use tire chains. They can damage your vehicle because there’s not enough clearance. Use another type of traction device only if its manufacturer recommends it. for use on your vehicle and tire size conlbination and road conditions.
Page 344 Never. use these to clean your vehicle: Gasoline Benzene Naphtha Carbon Tetrachloride Acetone Paint Thinner Turpentine Lacquer Thinner Nail Polish Remover They can all be hazardous -- some more than others -- and they can all damage your vehicle, too. Don’t use any of these unless this manual says you can.
Page 345 Using Multi-Purpose Interior Cleaner on Fabric 1. Vacuum and brush the area 2. Always clean a whole trim panel or section. Mask surrounding trim along stitch or welt lines. 3. Mix powdered cleaner following the directions on the container label. 4.
Page 346 Stains caused by candy, ice cream, tnayonna~se, chili sauce and unknown stains can be removed 1. Carefully scrape off excess stain. 2. Clean with cool water and allow to dry. 3. If a stain remains, clean it with dry spot remover. Cleaning Vinyl Use warm water and a clean cloth.
Page 347 Cleaning Interior Plastic Components Use only a mild soap and water solution on a soft cloth or sponge. Commercial cleaners may affect the surface finish. Care of Safety Belts Keep belts clean and dry. Do not bleach or dye safety belts. If you do, it may severely weaken them.
Page 348 Cleaning the Outside of the Windshield, Backglass and Wiper Blades If the windshield is not clear after using the windshield washer, or if the wiper blade chatters when running, wax, sap or other material may be on the blade or windshield. Clean the outside of the windshield with GM Windshield Cleaner, Bon Ami@ Powder (non-scratching glass cleaning powder), GM Part No.
Page 349 Cleaning Exterior LampdLenses Use lukewarm or cold water, a soft cloth and a liquid hand, dish or car washing (mild detergent) soap to clean exterior lamps and lenses. Follow instructions under "Washing Your Vehicle." Finish Care Occasional waxing or mild polishing of your vehicle by hand may be necessary to remove residue from the paint finish.
Page 350 Protecting Exterior Bright Metal Parts Bright metal parts should be cleaned regularly to keep their luster. Washing with water is all that is usually needed. However, you may use chrome polish on chrome or stainless steel trim, if necessary. Use special care with aluminum trim. To avoid damaging protective trim, never use auto or chrome polish, steam or caustic soap to clean alL1tninul-n.
Page 351 Finish Damage Any stone chips, fractures or deep scratches in the finish should be repaired right away. Bare metal will corrode quickly and may develop into a major repair expense. Minor chips and scratches can be repaired with touch-up materials available from your dealer or other service outlets.
Page 352 Appearance Care Materials Chart PART NUMBER SIZE 994954 23 in. x 25 i n . 1050172 (0.473 L) 1050 I73 16 oz. (0.473 L) IO50 174 16 07,. (0.473 L) I 0502 14 (0.946 L) 1050427 (0.680 L) 1052870 (0.473 L) 10529 18*:% (0.237 L)
Page 353 Vehicle Identification Number (VIN) This is the legal identifier for your vehicle. It appears on a plate in the front corner of the instrument panel, on the driver’s side. You can see it if you look through the windshield from outside your vehicle. The VIN also appears on the Vehicle Certification and Service Parts labels and the certificates of title and registration.
Page 354 Electrical System Add-on Electrical Equipment NOTICE: Don’t add anything electrical to your vehicle unless you check with your dealer first. Some electrical equipment can damage your vehicle and the damage wouldn’t be covered by your warranty. Some add-on electrical equipment can keep other components from working as they should.
Page 355 Fuses and Circuit Breakers The wiring circuits in your vehicle are protected from short circuits by a combination of fuses, circuit breakers and fusible thermal links in the wiring itself. This greatly reduces the chance of fires caused by electrical problems.
Page 356 Fuse/Circuit Breaker Usage StopJTCC Switch, Buzzer, CHMSL, Hazard Lamps, Stoplamps Transfer Case Courtesy Lamps, Cargo Lanlp, Glove Box Lamp, Dome/Reading Lamps, Vanity Mirrors, Power Mirrors 6-64 FuseKircuit Breaker Usage Instrument Cluster, Switch, Keyless Entry, Low Coolant Module, Illuminated Entry Module, DRAC (Diesel Engine) Rear Comfort Controls Cruise Control...
Page 357 FuseKircuit Breaker Usage 4WD Indicator, Cluster, Front and Rear Comfort Controls, Instrument Switches, Radio Illumination, Chime Module DRL Relay, Fog Lamp Relay Front and Rear Turn Signals, Back-up Lamps, BTSI Solenoid Radio (Ignition) 4WAL/VCM, ABS, Cruise Control Radio (Battery) PRNDL, Automatic Transmission, Speedometer, Check Gages, Warning Lights Security/Steering...
Page 358 A U X E A U X A Name Circuits Protected ECM-B Fuel Pump, PCM/VCM RR DEFOG Rear Window Defogger IGN-E Auxiliary Fan Relay Coil, A/C Compressor Relay, Hot Fuel Module FUEL SOL Fuel Solenoid (Diesel Engine) GLOW PLUG Glow plugs (Diesel Engine) HORN Horn, Underhood Lamps 6-66...
Page 359 Replacement Bulbs LAMP OR BULB HEADLAMPS 2 Headlamp System (Sealed Beam) Low/High Beam Headlamp System (Composite) Low Beam High Beam LAMP OR BULB EXTERIOR Front Marker Lamp Front Parking and Turn Lamp Rear Parking Lamp Rear Stop and Turn Lamp Back- up Lamp Roof Marker Lamp* License Plate Lamp...
Page 360 LAMP OR BULB INTERIOR Dome Lamps Reading Lamps Roof Console Lamps:$ Door Courtesy Lamp Four-Wheel-Drive Indicator** Four-Wheel-Drive Shift Lever** Instrument Panel Compartment Lamp Ashtray Lamp Sunshade Vmity Mirror *Suburban Only ‘i::i:Manual Transfer Case 6-68 TRADE NO. 21 1-2 2/42’’...
Page 361 Capacities and Specifications Please refer to “Recommended Fluids and Lubricants“ in the Index for more information. Engine Identification Gasoline Engines Engine Type RPO Code VIN Code Fuel System ’kSequential Fuel Injection Wheels and Tires MODEL C 1500 K 1500, C-K 2500 C-K 2500 Tire Pressure “VORTEC”...
Page 362 Normal Maintenance Replacement Parts Replacement part numbers listed in this section are based on the latest information available at the time of printing, and are subject to change. If a part listed in this manual is not the same as the part used in your vehicle when it was built, or if you have any questions, please contact your GM truck dealer.
Page 363 Cooling System Capacity (Approximate) After refill, the level must be rechecked. See “Cooling System’‘ in the Index. ENGINE “VORTEC” 5700 “VORTEC” 7400 Crankcase Capacity (Approximate) After refill, the level must be rechecked. Add enough engine oil so that the fluid is within the proper operating range. See “Engine Oil”...
Page 364 NOTES 6-72...
Page 365 Section 7 Maintenance Schedule This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety, dependability and emission control performance. Introduction Part Scheduled Maintenance Services Short Trip/City Definition Short Trip/City Intervals Long Trip/Highway Definition Long Trip/Highway Intervals Short Trip/City Maintenance Schedule 7-27 Long...
Page 366 KEEP ENGINE OIL AT THE PROPER LEVEL AND CHANGE AS RECOMMENDED IMPORTANT: Introduction Your Vehicle and the Environment Proper vehicle maintenance not only helps to keep your vehicle in good working condition, but also helps the environment. All recommended maintenance procedures are important.
Page 367 CAUTION: Performing maintenance work on a vehicle can be dangerous. In trying to do some jobs, Do your own maintenance be seriously injured. work only if you have the required know-how and the proper tools and equipment for the job. If you have any doubt, have a qualified technician do the work.
Page 368 Part A: Scheduled Maintenance Services Using Your Maintenance Schedule We at General Motors want to help you keep your vehicle in good working condition. But we don’t know exactly how you’ll drive it. You may drive very short distances only a few times a week. Or you may drive long distances all the time in very hot, dusty weather.
Page 369 Maintenance Schedule Short Trip/City Definition Follow the Short TripKity Maintenance Schedule if any one of these conditions is true for your vehicle: Most trips are less than 5 to 10 miles (8 to 16 km). This is particularly important when outside temperatures are below freezing.
Page 370 Maintenance Schedule Short Trip/City Intervals Gasoline Engines Every 100,000 Miles (166 000 km): Inspection. Spark Plug Replacement. Automatic Transmission Service (normal conditions). Positive Crankcase Ventilation (PCV) Valve Inspection. Every 150,000 Miles (240 000 km): Cooling System 60 months, whichever occurs first). Service (or every ng Tkiphlighway Definition Spark Plug Wire...
Page 371 Maintenance Schedule LLong Tripmighway Intervals Every 7,500 Miles (12 500 km): Engine Oil and Filter Change (or every 12 months, whichever occurs first). Chassis Lubrication (or every 12 months, whichever occurs first). Drive Axle Service. Tire Rotation. Every 15,000 Miles (25 000 km): Shields and Underhood Insulation Inspection (GVWR above 8,500 lbs.
Page 372 Short Trip/City Maintenance Schedule The services shown in this schedule (166 000 km) should be performed after 100,000 miles ( I 66 000 km) at the same intervals. The services shown at 150,000 miles (240 000 km) should be performed at the same interval after 150,000 miles (240 000 km).
Page 373 Short TripKity Maintenance Schedule 3,000 Miles 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 374 Short Trip/City Maintenance Schedule 9,000 Miles (15 000 km) (Continued) Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check redfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote 12,000 Miles (20 000 km) Change engine oil and filter (or every 3 months, whichever occurs first).
Page 375 Short TriplCity Maintenance Schedule For Two-Wheel-Drive vehicles only: Clean and repack the front wheel bearings (or at each brake relining, whichever occurs first). Vehicles With GVWR Above 8,500 Ibs. Only: Inspect shields and underhood insulation for damage or looseness. Adjust or replace as required. This is Noise EIllissiorr Control Service.
Page 376 Short Trip/City Maintenance Schedule 21,000 Miles (35 000 km) (Continued) Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote 24,000 Miles (40 Change engine oil and filter (or every 3 months, whichever occurs first).
Page 377 Short TripKity Maintenance Schedule 30,000 Miles (50 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 378 Short TripKity Maintenance Schedule M i l e s (55 000 km) (Continued) 33,000 Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid velocity joints and axle seals for leaking. (See footnote **.) 36,000 Miles (60 000 km) Change engine oil and filter (or every 3 months, whichever occurs first).
Page 379 Short TripKity Maintenance Schedule 42,000 Miles (70 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Einission Control Service. Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote #. j Check rear/front axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 380 Short Trip/City Maintenance Schedule 48,000 Miles (80 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 381 Short Trip/City Maintenance Schedule 51,000 Miles (85 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emission C u m d Service. Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check rear/front axle fluid level and add fluid as needed.
Page 382 Short TripKity Maintenance Schedule 57,000 Miles (95 000 knz) (Continued) Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote 60,000 Miles (100 Change engine oil and filter (or every 3 months, whichever occurs first).
Page 383 Short Trip/City Maintenance Schedule Replace fuel filter. Emissior7 Cot1tr-ol Ser-\.?ic.e. (See footnote?.) Conduct Exhaust Gas Recirculation (EGR) system inspection as described i n the service manual. Ernissiorl Control Service. (See footnote?.) ,411 Conduct evaporative control system inspection. Check all fuel and vapor lines and hoses for proper hook-up.
Page 384 Short TripKity Maintenance Schedule 66,000 Miles (110 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emission Control Service. Lubricate chassis components (or evely 3 months, whichever occurs first). (See footnote #.> Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 385 Short TripKity Maintenance Schedule Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information. (See footnote 75,000 Miles (125 000 km) Change engine oil and filter (or every 3 months, whichever occurs first).
Page 386 Short Trip/City Maintenance Schedule 78,000 MiZes (130 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). An Emis.sior7 Coutrol Sewico. Lubricate chassis components (or every 3 months, whichever (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 387 Short TripKity Maintenance Schedule Check rear/front axle fluid level and add .fluid velocity .joints and axle seals for leaking. (See footnote Rotate tires. See "Tire Inspection and Rotation" in the Index for proper rotation pattern and additional information. (See footnote 87,000 Miles (145 000 km) Change engine oil and filter (or every 3 months, whichever occurs first).
Page 388 Short TripKity Maintenance Schedule 90,000 Miles (I50 000 knz) (Continued) For Two-Wheel-Drive vehicles only: Clean and repack the front wheel bearings (or at each brake relining, whichever occurs first). Replace fuel filter. Emission Control Service. (See footnote?.) Rotate tires. See “Tire Inspection and Rotation” in the Index for proper rotation pattern and additional information.
Page 389 Short TripKity Maintenance Schedule 96,000 Miles (160 000 km) Change engine oil and filter (or every 3 months, whichever occurs first). AI? Emission Service. fro1 Lubricate chassis components (or every 3 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid velocity joints and axle seals for leaking.
Page 390 Short TriplCity Maintenance Schedule 100,000 Miles (I66 000 km) Inspect spark plug wires. An Evlzissiol? Control Service. Replace spark plugs. An Emission Control Senrice. Change automatic transmission fluid and filter if the vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature regularly reaches 90°F C) or higher.
Page 391 Long WdHighway Maintenance Schedule The services shown in this schedule up to 100,000 miles 166 000 k m ) should be performed after (166 000 km) at the same intervals. The services shown at 150,000 miles (240 000 km) should be performed at the same interval after 150,000 miles (240 000 km).
Page 392 Long Tripmghway Maintenance Schedule 7,500 Miles (12 500 km) Change engine oil and filter (or every 12 months, whichever Emission Control Sen?ice. Lubricate chassis components (or every 12 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 393 Long Trip/Highway Maintenance Schedule 22,500 Miles (37 500 km) Change engine oil and filter (or every 12 months, whichever occurs first). AI? Emission Control Service. Lubricate chassis components (or every 12 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 394 30,000 Miles 000 km) (Continued) Replace fuel filter. An Emission Control Service. (See footnoteJf.) Vehicles With GVWR Above 8,500 lbs. Only: Inspect shields and underhood insulation for damage or looseness. Adjust or replace as required. This is Noise Emission Control Service. Applicable sold in the United Stutes.
Page 395 Long Tripklighway Maintenance Schedule Check rear/front axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote Vehicles With GVWR Above 8,500 Ibs. Only: Inspect shields and underhood insulation for damage or looseness. Adjust or replace as required. This is Noise Emission Contrvl Service.
Page 396 Long Triphlighway Maintenance Schedule Miles (87 500 km) 52,500 Change engine oil and filter (or every 12 months, whichever occurs first). An Emission Control Service. Lubricate chassis components (or every I2 months, whichever occurs first). (See footnote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking.
Page 397 Lung Trip/Highway Vaintmance Sqhedule Replace fuel filter. Emission Control .Ser\>ico. (See footnote?.) Inspect fuel tank, cap and lines for damage or leaks. Inspect fuel cap gasket for any damage. Replace parts as needed. (See footnote?.) Vehicles With GVWR Above 8,500 lbs. Only: Inspect shields and underhood insulation for damage or looseness.
Page 398 Long TripMighway Maintenance Schedule 67,500 Miles (112 500 km) (Continued) heck rearlfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaking. (See footnote otate tires. See "Tire Inspection and Rotation" in the Index for proper dation pattern and additional information.
Page 399 Long TripMighway Maintenance Schedule 82,500 Miles (137 500 km) Change engine and filter (or every 12 months, whichever occurs first). Emission Corltrol Sen+c.e. Lubricate chassis components (or every 12 months, whichever occurs First). (See foott1ote Check readfront axle fluid level and add fluid as needed. Check constant velocity joints and axle seals for leaki.ng.
Page 400 ,mg Trip/Highway Maintenance Schedule 90,000 Miles (I50 000 km) (Continued) Vehicles With GVWR Above 8,500 lbs. Only: lnspect shields and underhood insulation for damage or looseness. Adjust or replace as required. This is Noise Emissiou Control Service. Applicubl(~ only to vel7iclc.s i n [he United Stcrtes.
Page 401 Long Tripmighway Maintenance Schedule 100,000 Miles ( I 66 000 km) Inspect spark plug wires. Emission Service. CoI~tl-ol Replace spark plugs. Emission Corztrol Service. Change automatic transmission fluid and filter if the vehicle is mainly driven under one or more of these conditions: In heavy city traffic where the outside temperature regularly reaches 90°F (32°C) or higher.
Page 402 Part B: Owner Checks and Services Listed below are owner checks and services which should be performed at the intervals specified to help ensure the safety, dependability and emission control performance of your vehicle. Be sure any necessary repairs are completed at once. Whenever any fluids or lubricants are added to your vehicle, make sure they are the proper ones.
Page 403 Also look for any opened or broken air bag coverings, and have them repaired or replaced. (The air bag system does not need regular maintenance.) Wiper Blade Check Inspect wiper blades for wear or cracking. Replace blade inserts that appear worn or damaged or that streak or miss areas of the windshield.
Page 404 Starter Switch Check CAUT’^”J: move suddenly. If it does, you or others could be injured. Follow the steps below. Before you start, be sure you have enough room around the vehicle. Firmly apply both the parking brake (see “Parking Brake” in the Index if necessary) and the regular brake.
Page 405 Ignition Transmission Lock Check While parked, and with the parking brake set, try to turn the ignition key to LOCK in each shift lever position. The key should turn to LOCK only when the shift lever is in PARK (P). The key should come out only in LOCK.
Page 406 Part C: Periodic Maintenance Inspections Listed below are inspections and services which should be performed at least twice a year (for instance, each spring and fall). You should let your dealer’s service department or other qualified service center do these jobs.
Page 407 Drive Axle Service Check readfront axle fluid level and add Check constant velocity joints and axle seals for leaking. Transfer Case (Four-wheel Drive) Inspection Every 12 months or at oil change intervals, check front axle and transfer case and add lubricant when necessary. On manual shift transfer case, oil the control lever pivot point and a l l exposed control linkage.
Page 408 Part D: Recommended Fluids and Lubricants NOTE: Fluids and lubricants identified below by name, part number or specification may be obtained from your dealer. USAGE FLUID/LUBRICANT Engine Oil Engine Oil with the American Petroleum Institute Certified For (Gasoline Gasoline Engines “Starburst” Engine) symbol of the proper viscosity.
Page 409 USAGE FLUIDLUBRICANT Chassis Chassis Lubricant (GM Part Lubrication No. 12377985 or equivalent) or lubricant meeting requirements of NLGI 2, Category LB or GC-LB. Front Wheel Wheel Bearing Lubricant meeting Bearings requirements of NLGI Category GC or GC-LB (GM Part No. 105 1344 or equivalent). Differential, Axle Lubricant (GM Part Front and Rear...
Page 410 USAGE FLUIDLUBRICANT Multi-Purpose Lubricant, Hood and Door Hinges Superlube@ (GM Part No. 1234624 1 or equivalent). Multi-Pur ose Lubricant, Body Door Hinge Pins, Superlube (GM Part No. 12346241 or equivalent). Tailgate Hinge and Linkage, Folding Seat and Fuel Door Hinge 7-46 USAGE FLUIDLUBRICANT...
Page 411 Part E: Maintenance Record After the scheduled services are performed, record the date, odometer reading and who performed the service in the boxes provided after the maintenance interval. ODOMETER DATE READING Any additional information from “Owner Checks and Services” or “Periodic Maintenance” can be added on the following record pages.
Page 412 7-48...
Page 413 Section 8 Customer Assistance Information Here you will find out how to contact GMC if you need assistance. This section also tells you how to obtain service publications and how to report any safety defects. Customer Satisfaction Procedure Customer Assistance for Text Telephone...
Page 414 Customer Satisfaction Procedure GMC dealers have the fhcilities, trained technicians and up-to-date information to promptly address any concerns you may have. However, if a concern has not been resolved to your complete satisfaction. take the following steps: STEP ONE -- Discuss your concern with a member of dealership management.
Page 415 STEP TWO I f after contacting of dealership management, it appears your concern cannot be resolved by the dealership without further help, contact the GMC Consumer Relations Manager by calling I -800-GMC-8782 1-800-462-8782, Customer Assistance prompt.) In Canada. contact GM of Canada Customer Communication Centre in Oshawa by calling 1-800-263-3777 (English) or 1-800-263-7854 (French).
Page 416 Vehicle delivery date and present mileage Nature of concern We encourage you to call us so we can give your inquiry prompt attention. However, if you wish to write GMC, address your inquiry to: GMC Customer Assistance 3 1 E. Judson Street 1607-04...
Page 417 Roadside Assistance GMC’s Roadside Assistance provides stranded owners with over-the-phone roadside repairs, location of the nearest GMC dealer or the following special services: Flat Tire Change: Installation of spare tire will be covered at no charge (customer is responsible for repair or replacement of tire).
Page 419 Roadside Assistance is available 24 hours a week, 365 days a year, including weekends and holidays. Should you have any questions about roadside assistance, call the GMC Roadside Assistance Center or contact your dealer. Canadian Roadside Assistance Vehicles purchased in Canada have an extensive Roadside Assistance program accessible from anywhere in Canada or the United States.
Page 420 The Commitment Plus Courtesy Transportation Program is not part of the Bumper to Bumper Limited Warranty. GMC reserves the right to make any changes or discontinue the Courtesy Transportation Program at any time without notification. For additional program details, contact your GMC dealer.
Page 421 Plan (CAMVAP). General Motors reserves the right to change eligibility limitations and/or to discontinue its participation in this program. Both GMC and your GMC dealer are committed to making sure you are completely satisfied with your new vehicle. Our experience has shown that, if a situation...
Page 422 Some state laws may require you to use this proe aram before filing a claim with a state-run arbitration program or in the courts. For further information, contact the BBB at 1-800-955-5 100 or the GMC Customer Assistance Center at I -800-GMC-8782 1-800-462-8782). Warranty Information Your vehicle comes with a separate warranty booklet that contains detailed warranty information.
Page 423 REPORTING SAFETY DEFECTS TO GENERAL MOTORS In addition to notifying NHTSA (or Transport Canada) i n a situation like this, we certainly hope you'll notify Please call us at 1-800-GMC-8782 LIS. (1-800-462-8782) or write: GMC Consumer Relations E. Judson Street 1607-04...
Page 424 1998 GMC SERVICE PUBLICATIONS ORDERING INFORMATION The following publications covering the operation and servicing of your vehicle can be purchased by filling out the Service Publication Order Form in this book or credit card information to Helm, Incorporated (address below.)
Page 425 ORDER TOLL FREE (NOTE: For Credit Card Holders Only) 1-800-782-4356 6:OO PM EST) (Monday-Friday 8:OO AM FAX Orders Only 1-31 3-865-5927 PUBLICATION FORM NUMBER Service Manual Car & Light Truck Transmission Unit Repair ~~~~~ Owner’s Manual In Portfolio Owner’s Manual Without Portfolio NOTE: Dealers and Companies please provide dealer or company name, and also the name of the person to whose attention the shipment should be sent.
Page 426 NOTES 8-14...
Page 427 Section 9 Index Bag ........Adding Equipment .
Page 428 Brake Adjustment ..............Fluid .
Page 429 Climate Control. Optional ......Climate Control. Standard ......
Page 430 E a s y Entry Seat (2-Door Utility) ....I -7 Electric Tailgate Glass Release .....
Page 431 G a g e s ....Engine Coolant Temperature ......Engine Oil Pressure .
Page 432 ..... . K e y Lock Cylinder Service ......Keyless Entry System .
Page 433 ........Mirrors .
Page 434 . . . Replaci-ng Safety Belts 1-64...
Page 435 Rear Seat Outside Passenger Positions ... . 1-40 Rear Seat Passengers ......Reminder Light .
Page 436 Speech Impaired. Customer Assistance ....8-4 ......Speed Sensitive Steering .
Page 437 Towing ....... . FromtheFront ....... From the Rear .
Page 438 Wheel ........Alignment ......Nut Torque .
