13 Attaching the rack front cover
1
Attach the rack front cover.
Fasten the rack front cover to the front
of the server with the 4 tap tight screws
(M4) provided.
14

Converting to a rackmount model

Perform the following steps to implement the rack conversion kit and install the server in the
rack:
For details on attaching the slide rails, refer to your rack type instructions.
Attaching the inner rail
1
Separate the inner rails from the slide rail.
Holding the lock pressed (see diagram), slowly pull the inner rail outward to remove.
Slide rail
Inner rail
Lock
