11 Reattaching the front cover
1
Reattach the front cover removed in "6 Removing the front cover" (pg
13).
Insert the 2 lower tabs and respective 3
upper tabs in their slots and firmly press the
front cover to secure into place.
12

Reattaching the left side cover

Perform the removal procedure in reverse to reattach the left side cover to the server. Refer to
"5 Removing the left side cover (12 page)" for details.
20 Conversion procedure
•
Remain wearing the wrist grounding strap until the side
cover is completely attached.
•
Before replacing the left side cover, check to see whether
any tools were left inside the server.
Upper tabs
Lower tabs
