Attaching The Front Cover Brackets - Fujitsu PRIMERGY PG-R1CK7 User Manual

5
Remove the intrusion cable.
6
Reconnect all cables disconnected in step 1.
7
Re-tie the operator panel cables separated in step 2.
10

Attaching the front cover brackets

1
Attach the front cover brackets on the right and left side of the server.
Fasten each bracket to the side of the
server with the 2 tap tight screws (M4)
provided.
10 Attaching the front cover brackets
Intrusion cable
[Left side of the server]
= Screw holes
E
