Removing The Left Side Cover - Fujitsu PRIMERGY PG-R1CK7 User Manual

5

Removing the left side cover

1
Remove the 2 retaining thumbscrews (M3) located at the rear.
2
Slide the left side cover.
The side cover is fastened to the chassis
by tabs. Carefully slide the left side
cover toward the rear as shown in the
diagram to release the tabs from the
chassis and remove.
12 Conversion procedure
Do not lose these screws since they will be used later to reat-
tach this cover.
