PCI/VGA Palette Snoop
Leave this field at Disabled. The settings are Enabled, Disabled.
3-10 PC Health Status
This section shows the Status of you CPU, Fan, and Warning for overall system status. This
is only available if there is Hardware Monitor onboard.
Shutdown Temperature
Show PCHealth in POST
> Smart FAN Configurations
VCC3v
Vcore
NB1.25V
+5V
+12V
5VSB
VDIMM
3VSB
Vbat
CPU Temperature
System Temperature
CPUFAN Speed
SFAN1 Speed
SFAN2 Speed
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values
Shutdown Temperature
This item can let users setting the Shutdown temperature, when CPU temperature over this
setting the system will auto shutdown to protect CPU.
Show PC Health in Post
During Enabled, it displays information list below. The choice is either Enabled or Disabled
Smart FAN Configurations
Please refer to section 3-10-1
Vcc3V/Vcore/NB1.25V/+5V/+12V/5VSB/VDIMM/3VSB/Vbat/CPU
Temperature/System Temperature/CPU Fan Speed/ SYSFAN1, SYSFAN2 Speed
This will show the CPU/FAN/System voltage chart and FAN Speed.
3-10-1
Smart FAN Configurations
CPUFAN Smart Mode
CPU SmartFAN Full-Speed
CPU SmartFAN Idle Temp
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values
CPU/SFAN1 Smart FAN Full-Speed Temp
This item allows you setting the FAN works in full speed when the temperature over the value
which out set. If the temperature below the value but over the Idle Temperature, the FAN
will works over 60% of full speed, and the higher temperature will gain higher FAN speed,
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Disabled
Enabled
Press Enter
3.31V
1.28V
1.26V
5.12V
11.88V
5.00V
1.87V
3.37V
3.28V
64 ° C147 ° F
38 ° C/96 ° F
2912RPM
0 RPM
0 RPM
F6:Optimized Defaults
Phoenix – AwardBIOS CMOS Setup Utility
Smart FAN Configurations
Enabled
50
30
F6:Optimized Defaults
Menu Level >
F7:Standard Defaults
Menu Level >
F7:Standard Defaults
40
Item Help
Item Help
