SET MODE PROGRAMMING SCREEN

S M P
ET ODE ROGRAMMING
programming screen allows the programmer to edit general radio display and audio
parameters.
The preceding screen shot shows the defaults for this programming screen. Double click
on the field you wish to edit. The next table is a description for each row:
S M
ET ODE
Row Description
Backlight Select "OFF", "Dim", "Auto" and "ON". Selecting "Off" disables backlight
completely. Selecting "Dim" sets backlight to be on constantly at a dim
level. Selecting "On" sets the backlight to remain on continuously. Do not
use "Auto".
Beep Select "ON" or "OFF". Selecting "On" will activate a short "beep" when
keys are pressed. Note: some beeps, such as the one for the lockout timer,
cannot be turned off.
Beep Level Select "1" through "5" or "1 Linked" through "5 Linked". Selecting "1"
through "5" (with "5" being the loudest) will cause the beeps to sound at a
constant volume regardless of the setting of the volume knob. Selecting "1
Linked" through "5 Linked" (with "5 Linked" again being the loudest)
"ties" the beeps to the volume control. Experiment with this setting to see
what works best for the customer.
SQL Level Enter a number from 0 to 255 (0 "the loosest"). Manually sets squelch
levels.
AF Min Enter from 0 to 255 (0 lowest). Sets the lowest level that speaker audio can
Level be set to. This is useful to prevent the radio operator from turning the radio
all the way down (and forgetting to turn it up) and potentially missing a call.
CS-F620TR Programming Software Manual
S I
CREEN CON
P S
ROGRAMMING CREEN
: Located in Common folder. This
F D
IELD ESCRIPTION
Set Mode Programming Screen
(rev 1.0) -
T
ABLE
Default
Auto
ON
3
0
0
57
