Passport Talk Group Setting Programming Sub-Screen Field Description Table - Icom IC-F620 Programming Software Manual

P P T G
ASS ORT ALK
Field Description
CH Each line can contain a new group. You can
enter up to 250 groups per PassPort system.
Don't let the "CH" designation of this column
throw you off, each number in this column is
just a reference number and have nothing to do
with the "CH" column in the PassPort
programming screen. If you are entering a
primary group in the radio, it should be always
be the first row here, particularly if you are
enabling the Dec. Pri. TG field in the PassPort
programming screen.
Group Tag Double click here to enter a text description for
this group if your Type field is going to be
"GRP" (as described on page 13). If your Type
field is going to by "MIN" (based on what you
are about to enter in "RX ID" then this tag will
become a MIN Alias tag. You can enter up to
10 characters for this field.
Type This field is for reference only. Depending on
where the Group ID Start field is set and what
information is entered into the RX ID field, this
will appear as either "GRP" or "MIN". This
field will display "GRP" when the number
entered in the RX ID field is at or greater than
the Group ID Start. When the number in the
RX ID field is less than the Group ID Start, this
field will appear as "MIN".
RX ID Enter from 1 to 65519. Used to enter either
group or MIN numbers. When entering groups,
enter the PassPort group number you wish for
this group entry. Your PassPort system
operator usually provides this. MINs enter here
can be used for selective call and can be
selected like any group. Also, when a MIN
from a calling party matches any of the MINs
in this column, its associated Group Tag
description, rather than the MIN number, will
be displayed.
TX ID Enter from 1 to 65519. You must enter
information into the RX ID field before
attempting to change this field. If you attempt
to enter this field first, the program will re-
direct you to RX ID field. After you enter
information in RX ID, this field will show a "<-
" indicating that the contents of the TX ID field
is the same as the RX ID field. This field
should not be changed once its value is set to
"<-".
CS-F620TR Programming Software Manual
S P
ROUP ETTING ROGRAMMING
T
S -S
UB CREEN
ABLE
Default
No user entry.
No user entry
(<- After "RX
ID" field has been
entered)
PassPort Programming Screen
(rev 1.0) -
F D
IELD ESCRIPTION
Suggested
Settings
No user entry.
Mandatory
field - set as
needed. You
cannot enter any
other information
on this row until
data for this field
has been entered.
No user entry
Mandatory
field - set as
needed.
Mandatory
field – leave as set
by entry in "RX
ID" field.
28
