9. Attach the snap ring (L) for the bearing on the output
shaft.
N
M
10. Attach the bushing (K) on the output shaft.
11. Attach the grease plug (N).
12. Attach the snap ring (M) for the bearings on the
input shaft.
13. Fill the gearbox with grease (about 10 to 12 g).
14. Install the gearbox to the product in the opposite
sequence to how it was removed. Refer to
disassemble the gearbox on page 39 . Remove the
rod to unlock the axle before you attach the support
flange.
1296 - 001 - 27.09.2019
K
L
To
Repair instructions - 41
