Installation
4. Attach the plastic cups for fixing the tumble
dryer's front feet to the washing machine's
top cover. This is essential, as only when
the tumble dryer's feet are resting in the
plastic cups can you be sure that the dryer
is correctly positioned on the washing
machine.
Break off tag A on the cup fitted on the
right-hand side and tag B on the cup fitted
on the left-hand side. Then remove the
paper from the self-adhesive surface under
the plastic cups.
A
B
5. Fit the plastic cups so that the "tags"
marked with arrows are against the front
edge or side edge of the cover and press
them firmly onto the cover. Then break off
the remaining tags.
6. Push out the knock-out hole on the back
of the dryer (you must not remove it, just
open it) using a hammer and screwdriver.
7. Push the tumble dryer in under the metal
brackets, keeping the front edge raised by
1 - 2 cm.
8. Lower the tumble dryer's front feet into the
plastic cups and adjust the dryer to ensure
that it is balanced.

Adjusting the feet

Screw the feet in or out so that the tumble
dryer is steady and balanced on the floor or
on the washing machine. Then tighten the
lock nuts.
Locking nut
