3.4 VARIOUS MODELS AND TERMS

The Typhoon Monitor is available in manual and electric remote controlled models.
Electric remote control models are available in a standard model (suitable for on top of pumpers), ladder model, and platform model.
The ladder and platform models have horizontal travel stops factory installed at 90° left and right (180° total).
TILLER
(BOTH AXIS)
ELEVATION
LOCK
HORIZONTAL
LOCK
ELEVATION
HANDWHEEL
HORIZONTAL
TILLER
HORIZONTAL
LOCK
Typhoon Tiller and Handwheel
ANTI-BACK DRIVE
GEARBOX
Typhoon RC for Ladders
©Copyright Task Force Tips LLC 2004-2020
MODEL &
SERIAL NUMBER
ON LABEL
Typhoon Tiller
MONITOR MOUNTED
Figure 3.4
Various Typhoon Models and Terms
PORT FOR
PRESSURE GAGE
ELEVATION
HANDWHEEL
HORIZONTAL
HANDWHEEL
Typhoon Dual Handwheel
ELECTRIC NOZZLE
CONNECTION
CONTROL STATION
Typhoon RC
Typhoon RC for Platforms
6
MANUAL
OVERRIDE
KNOB
