American Dynamics MegaPower 3200 Operator's Manual page 22

Function Action
Entering this key combination implies that
you will also enter another 2-digit F2 code
55-F2
combination within three seconds: 99-F2 -
System Reset
60-F2
Displays current day of week
61-F2
Sets day of week to Sunday
62-F2
Sets day of week to Monday
63-F2
Sets day of week to Tuesday
64-F2
Sets day of week to Wednesday
65-F2
Sets day of week to Thursday
66-F2
Sets day of week to Friday
67-F2
Sets day of week to Saturday
Momentarily displays software version
70-F2
number as "V - - -" in the camera title field
of the selected monitor
91-F2
Changes which unit is Active
Writes app data (cameras selected on
keyboards and other info) to Flash.
92-F2 Entering 92-F2 ten seconds before a front
panel reset eliminates the need to
resynchronize cameras to monitors
Loads the dynamically defined character
93-F2
set to the BVOM
Used in combination with 55-F2 to reset
99-F2
the MPCPU. This function does nothing
by itself.
Sets video loss mode to OFF for the
100-F2
called camera
Sets video loss mode to SYNC ONLY for
101-F2
camera
Sets video loss mode to VIDEO LOW for
102-F2
camera
Sets video loss mode to VIDEO MED for
103-F2
camera
Sets video loss mode to VIDEO HIGH for
104-F2
camera
Sets video loss mode automatically for
105-F2
called camera
Sets DBVL mode for all cameras
106-F2
automatically and transfers settings to the
CPUs to synchronize databases
Updates video loss mode settings of all
107-F2 cameras from matrix switcher to the Video
Loss Detection module
Clears the video loss mode for all
108-F2
cameras
Downloads video loss mode of called
109-F2
camera from VLD module to matrix
switcher
MEGAPOWER CPU
OPERATOR'S GUIDE
Function Action
Transfers video loss mode of all cameras
110-F2
from VLD module to matrix switcher
120-F2 End Pattern Definition
121-F2
Define Pattern 1
122-F2
Define Pattern 2
123-F2
Define Pattern 3
130-F2
Save New Pattern
131-F2
Clear Pattern 1
132-F2
Clear Pattern 2
133-F2
Clear Pattern 3
200-F2
Frees remote PTZ slots
202-F2
Resets all Alarms
Displays current arming code for selected
300-F2
monitor
301-F2
SSI Monitor Arming
302-F2 SSA Monitor Arming
303-F2
SSM Monitor Arming
304-F2
SHI Monitor Arming
305-F2
SHA Monitor Arming
306-F2
SHM Monitor Arming
307-F2
BSI Monitor Arming
308-F2
BSA Monitor Arming
309-F2
BSM Monitor Arming
310-F2
BHI Monitor Arming
311-F2
BHA Monitor Arming
312-F2
BHM Monitor Arming
313-F2
DHI/DSI Monitor Arming
314-F2
DHA/DSA Monitor Arming
315-F2
DHM/DSM Monitor Arming
316-F2
Disarm Monitor
317-F2
Enable Manual Override
318-F2
Disable Manual Override
998-F2
Transfer Macro from keyboard to system
999-F2
Transfer Macro from system to keyboard
Note:
(1)
For an explanation of monitor arming codes, refer to
MegaPower CPU Administrator's Guide, Appendix H,
8200-0421-03.
20 of 20
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
8200-0421-02, REV. D
