Te c h n i c a l M a n u a l

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna Automower

Summary of Contents for Husqvarna Automower

  • Page 1 Te c h n i c a l M a n u a l...

  • Page 3: Table Of Contents

    3.3 Guide wire ........................ 3.4 Testing the installation ................3.5 One Automower in several gardens ..........3.6 Several Automower machines in one garden ...... 3.7 Incline conditions ....................3.8 Even mowing result on complex working areas ....3.9 Installation examples ..................
  • Page 4 Table of contents The Technical manual for the Automower from Husqvarna™ is a supplement to the Operator’s manual. The Manual contains in-depth information about the Automower and its peripheral equipment. The Technical manual is intended for dealers, service personnel, etc.

  • Page 5: Function

    1. Function 1. Function 1.1 Automower, What is what? 3012-692 The numbers in the picture correspond to: Charging strip 14. Blade disc Cutting height adjustment cover 15. Charging station Catch button to open the cutting height 16. Contact strips adjustment cover 17.

  • Page 6: Introduction

    Words written in bold refer to one of the buttons on the mower's keypad or a button in the service program Autocheck. • Words written in UPPERCASE and italics refer to the position of the main switch and the different operating modes on the mower. Automower from ™...

  • Page 7: Technical Data

    Working capacity 1,800m +/- 20% 1.4 Mower program Automower The behaviour of the Automower from Husqvarna™ is controlled by a microprocessor and software. The software, the mower program, manages all information and the operation of the mower. This Technical Manual for Automower covers edition 2.32 of the mower program.

  • Page 8: Mowing Technique

    Automower can even mow in the rain, however, wet grass easily collects on the mower and the risk of slipping on steep slopes is greater. When there is a risk of thunder the Automower should not stand in the charging station. The 24V connector should also be removed.

  • Page 9: Square Mode Cutting

    Poor or dull blades can result in the grass bending instead of being mown, the tops become frayed and Automower may find it difficult to mow a large working area. Besides, the lawn can become extremely rumpled and uneven.
  • Page 10 Automower will then start square mode cutting. The limit value for when Automower should start square mode cutting is set to 50% at the factory. The limit value is adjustable from the menu Tools - Special settings - Square mode cutt.

  • Page 11: The Loop System's Control Signals

    The F-signal guides the mower in the direction of the charging station. When there is no F-signal, the Automower will not be able to find the charging station. The mower will eventually stop and display the fault message Low battery voltage.

  • Page 12: Loop Signal Strength

    The signal from the boundary wire is called the A-signal. See the picture below for examples of high and low signal strengths. Out-turned corner = high strength Narrow head = low strength In-turned corner = low strength 3012-612 Examples of high and low signal strengths Automower from ™...
  • Page 13 If the Automower does not find the right loop signal strength when it leaves the charging station to follow the loop to a remote area, it will start to mow directly instead.

  • Page 14: Corridor Width

    3012-611 The longer the guide loop the lower the signal strength and the harder it is for the Automower to follow the guide wire. A lower signal strength means that the mower, with a given corridor width, will be run closer to the guide wire.
  • Page 15 In general the widest possible corridor should always be used. Apart from a reduced risk of tracks forming, it is also easier for the Automower to follow the boundary wire or guide wire. The mower does not need to stop as frequently to search for the signal and with that runs more smoothly.

  • Page 16: Search Method To Find The Charging Station

    Automower to pass through a passage is presented. Note that the values are approximate and can always vary in different installations. Table 5: Greatest possible corridor width for the Automower to pass through a specific passage Width of Version 02.32 2004 Version 02.32 2005...
  • Page 17 1. Function When there is a guide wire installed and the delay time for the guide wire has elapsed the Automower will start to search for the guide wire and follow it into the charging station. If the delay time for the boundary wire...

  • Page 18: Docking And Charging

    Depending on the placement of the charging station, F = 25 (4 m) the Automower may be forced to leave the F-field to reach the charging station. The mower then follows the boundary wire out of the F-field. First it runs...
  • Page 19 The charging plate (F-coil) is defective. Check the F-signal from the charging station: Place the Automower in the test position and then check the value via the Quick check function (Press and hold the 0 key down for 2 seconds). The F-coil is defective if the value for F is lower than 300.

  • Page 20: Battery

    When charging starts the battery temperature should not be more than 40 ºC. Now let the Automower mow in manual operating mode until the battery is fully discharged. It is also possible to switch the mower from automatic to manual operating mode when it has left the charging station and started to mow.
  • Page 21 The value for Chargings OK, which is a measurement of the age of the battery is then reset, both on the main counter and on the trip counter. A battery can normally take 1000 – 2000 charges. Automower from ™...

  • Page 22: Special Menu Functions

    2.1 List, menu functions 2.2 Quick check _________________________________________________________________________________________________________________ 2.3 Discover the PIN code ____________________________________________________________________________________________ 2.4 The Tools Menu _________________________________________________________________________________________________________ 2.5 Automower main menu, menu overview ______________________________________________________ 2.6 The Tools menu, an overview _____________________________________________________________________________ 2.7 The Tools menu, functions __________________________________________________________________________________ 2.7.1 Operating history (5-1)

  • Page 23: Quick Check

    The closer to the loop the mower is, the higher the value. When the Automower is directly over the loop the value is 0 and when the mower is outside of the loop the value is negative.
  • Page 24 NONE • Collision: Lift: To test the collision sensors: Hold the handle on the underside of the Automower. Press on TiltY: 0 TiltX: 0 different parts of the body. The display shows Mower normal pos. None, Both, Left or Right. Continue to press on the body until you see that both collision sensors work.

  • Page 25: Discover The Pin Code

    2. Special menu functions 2.3 Discover the PIN code If you forget the PIN code for an Automower or when a mower is blocked because an incorrect code has been stated, you can find out the right code: When the main menu is displayed: Hold down the 9 key for five seconds, a combination of five letters will then be displayed.

  • Page 26: Automower Main Menu, Menu Overview

    2. Special menu functions 2.5 Automower main menu, menu overview Automower from ™...

  • Page 27: The Tools Menu, An Overview

    2. Special menu functions 2.6 The Tools menu, an overview Automower from ™...

  • Page 28: The Tools Menu, Functions

    Loop detection • Live data (5-3), to study an Automower in operation, i.e. when it Special settings is not in test mode, but is checked by its own mower program. •...

  • Page 29: Operating Data (5-1-1)

    Time/charge a measurement of on how many occasions when Search times the Automower has reached the N-field this has resulted in a successful docking. Docking efficiency should be as high as possible. Normally the value for docking efficiency is about 90 % or higher.
  • Page 30 • Efficiency (%) = a measurement of how much of the total operating time that the Automower has mown the lawn. Efficiency is the mowing time divided by the charging time+running time. Normally the efficiency value should be around 50%.

  • Page 31: Trip Operation Counters (5-1-2)

    Automower has reached the N-field. • Coll while docking = the accumulated number of occasions that the Automower has reached the N-field, but collided before docking. • Timer mode (h) = the accumulated number of hours that the timer function on the Automower has been activated.

  • Page 32: Fault Messages (5-1-3)

    AMG2 number is stated as a combination of four numbers, for example, Ver 02.32. The program type states Fault messages which type of mower program Automower is Ver: xx.xx B: programmed with. B states the control box version. Software Date:...

  • Page 33: Test (5-2)

    Place the cursor on Wheel motors and press YES to start the test. Grip the handle on the underside of the Automower and lift up the rear wheels. The following is shown on the display during the test: Loop •...
  • Page 34 8 hours of mowing time. A high value indicates that the blade disc is blocked. The current and average current are the values compared and the difference between them determines whether the Automower should start square mode cutting or not. • Speed: xxxx rpm The normal speed is approximately 2,500 rpm.

  • Page 35: User Interface (5-2-2)

    The closer to the loop the mower is, the higher the value. When the Quality Sensors Automower is directly over the loop the value is 0 and when the mower is outside of the loop the 5-2-4 Restarts value is negative.
  • Page 36 When the rear loop sensor is malfunctioning the Ar value is constant and the Quality value is 0%. The Automower must stand in a special test position Automower in the test position to receive usable values when testing the F- and N-signals.

  • Page 37: Sensors (5-2-5)

    Tools- Special settings - Calibrate tilt sensor (shortcut 5-6-3). 2.7.3 Live data (5-3) This function can be used to study an Automower in Blade motor operation. Using Live data you receive relevant data for respective component groups or function.

  • Page 38: Loop (5-3-4)

    Automower at the home of a customer. Live data The checkbox is checked when ON is selected. ON means the Automower can only work when there is a loop signal. Demo mode The function is switched off automatically when the mower is switched off and on using the main switch.

  • Page 39: Special Settings (5-6)

    New startup sequence (5-6-2) This function can be used when a second-hand Automower is sold. The new owner will then be asked the start-up questions about language, date, and time when the main switch is turned ON for the first time. In...
  • Page 40 STOP button override (5-6-4) When STOP button override is actuated the Automower can be started and stopped with the help of the number 0 instead of the STOP button. This function is suitable when the display is difficult to read on a working mower, for example, when charging or running in Live data mode.

  • Page 41: Installation

    Automower from Husqvarna™: • The charging station should have a central placement in the working area, so that the Automower can find it as soon as possible. A central placement is of extra importance with complex installations. •...

  • Page 42: Boundary Wire

    1.8.2 Guide loop on page 13. 3.2 Boundary wire To start an Automower requires a charging station and boundary wire to be installed. It is not possible to test drive a mower until the installation is complete. The...
  • Page 43 The Automower interprets an odd number of wires next to each other as an outer edge where is should turn. On the other hand: The mower will run over an even number of wires close to each other.

  • Page 44: Guide Wire

    3. Installation 3.3 Guide wire 3.3.1 Need of a guide wire With the help of a guide wire Automower can quickly and easily find the charging station by following the guide wire instead of searching irregularly or by following the boundary wire.
  • Page 45 3012-651 • The guide loop should be a maximum of 200 metres long. When the guide loop is longer, there is a risk Automower can not follow the guide wire. 3012-650 Automower from ™...
  • Page 46 3. Installation If you shall install the guide wire through a passage: • Automower follows the guide wire on the same side of the wire both to and from the charging station. This means that in towards the charging station the guide wire is on the right side of the mower and away from the charging station the guide wire is on the left side of the mower.
  • Page 47 If Automower does not find the right strength on the loop signal when it leaves the charging station, it will start to mow immediately instead.

  • Page 48: Testing The Installation

    Corridor width, but not when a value of 6 is set. The Test IN (3-2-4) function differs compared to using the Home button to send Automower to the charging station. When the Home button is pressed down, the mower starts to search for the charging station according to the defined settings.
  • Page 49 To test the settings for Follow loop out (3-2-1): State the value 100 % for Proportion for the Corridor width remote area to be tested. Place Automower in the charging station and Test IN select Test OUT (3-2-5). The mower will now leave the charging station...

  • Page 50: One Automower In Several Gardens

    3. Installation 3.5 One Automower in several gardens Automower can be connected/coded for more than one installation, which allows a mower to be used in several gardens. The mower is coded as usual to the first garden and then to the next garden via the function Settings - Security - PIN code (shortcut 4-1-1).

  • Page 51: Incline Conditions

    1:2.5 3.8 Even mowing result on complex working areas Automower is equipped with setting options to assure an even mowing result on complex working areas too. The settings are made on the Exit angles (3-1) and Follow loop out (3-2-1) functions. By not adapting...

  • Page 52: Installation Examples

    Automower would not pass through this passage. On the other hand, with Corridor width 3 the installation is approved. Automower can pass through this passage. However, a narrow corridor can result in tracks forming on the lawn, especially around a large island.
  • Page 53 3. Installation Example number 2 In this example the guide loop is longer than 200 metres. There is a risk that the Automower stops following the guide wire. The charging station should therefore be moved. Non approved 3012-621 Follow loop...
  • Page 54 Example number 3 In this example different exit angles have been set. Automower will easily reach all parts of the working area. The risk of tracks forming is less with these settings compared with allowing the mower to follow the boundary wire out of the charging station.
  • Page 55 Proportion With the help of a guide wire, the Automower finds the charging station easily from Area 1. On the other hand, there is a risk of the mower not finding its way out of the area if it does not find the guide wire and start to follow it before the delay time for the boundary wire has elapsed.
  • Page 56 3. Installation Example number 5 In this example the guide loop is longer than 200 metres. There is a risk that the Automower stops following the guide wire. The charging station should therefore be moved. Non approved 3012-628 Follow loop...
  • Page 57 Guide wire Exit angles Area 1, 2 Delay 20 minutes 7 minutes Start angle 1 – End angle 1 (2) 90° and 200° Corridor width Start angle 2 – End angle 2 (1) 240° and 270° Proportion first Automower from ™...
  • Page 58 3. Installation Example number 7 In this example Automower, with the help of the settings, will reach the entire working area. Fully approved 3012-633 Follow loop Boundary wire Guide wire Follow loop out Area 1 Area 2 Delay 11 minutes...
  • Page 59 Fully approved 1.5m 1.5m 3012-637 Follow loop Boundary wire Guide wire Follow loop out Area 1 Area 2 Delay 11 minutes 7 minutes Direction Guide Guide Corridor width Distance 40 metres 20 metres Proportion Automower from ™...

  • Page 60: Autocheck, Service Program

    4. Autocheck, Service program The service program Autocheck is a tool to help trouble shoot as well as send and retrieve information to/from an Automower from Husqvarna™. You can also, via Autocheck, update the mower program in an Automower. Autocheck is intended for Automower models from 2003.

  • Page 61: Using Autocheck

    The folder Documents contains pdf-files of among others the Operator’s Manual for Automower. The folder Program contains the two files that Autocheck automatically retrieves when updating the mower program in an Automower. New files for the mower program must be saved in this folder. IMPORTANT INFORMATION The entire contents of the folders are used by Autocheck and must not be deleted.

  • Page 62: Autocheck Assistant

    4.4.2 Communication on page 63. When a connected Automower stands for a while without any programming, registering or the like being made, the mower enters sleep mode. The display is completely dimmed.

  • Page 63: The Properties Menu

    4.4.2 Communication The Communication function informs Autocheck which COM-port you will use when connecting an Automower. Many computers have more than one COM port and the right one must be defined so that the Autocheck can make contact with the connected mower.
  • Page 64 4.4.7 Dealer data In the Dealer data function those of you who are dealers enter your contact details. The details are then included on all printouts from Autocheck. Automower from ™...

  • Page 65: The Tools Menu

    4.6.1 Mower program In the Mower program function you can view information related to the mower program on a connected Automower. When you select this function the Mower program window opens. This contains, among others, data about the mower program in the connected mower, hardware and the type of mower.
  • Page 66 Displays saved error messages and operating data, e.g. running time and charging time. 4.8.4 Programming Function to load a new mower program on an Automower. 4.8.5 Settings Function to read all the mower’s settings. These can be changed without using the mower’s keypad.
  • Page 67 Auto test is the ideal function to use to gain a total trace of components, for example, when you do not know what may be wrong on an Automower. 3012-561 Select the components you would like to test.
  • Page 68 4.8.2 Manual test Manual test allows you to test all components on an Automower. The function consists of four parts: Power/Motors, User interface, Sensors, and Loop. When using Manual test, unlike Auto test, you need to start and stop the components you wish to test. When you have started a test, for example, of the wheel motors, these will run until you click on Stop.
  • Page 69 Otherwise the fromthe wheel motor, the control box may be mower will drive off and may damage the faulty. service cable. • Inspect the cabling and electrical connectors on the wheel motors and to the mower’s control box. Automower from ™...
  • Page 70 Keep your hands and feet at a safe distance. Click on the Blade motor > button. Read the value in the box and on the bar. The value/blade motor speed should be about 2,500 rpm. Automower from ™...
  • Page 71 4. Autocheck, Service program Manual test: Testing the charge 3012-564 Place the Automower in the charging station and turn ON the main switch. Tick the Mower is charging checkbox. When charging works as it should a positive value of about 1750mA should be shown in the value box for the Battery current and the horizontal bar should be green.
  • Page 72 ON. OFF is displayed in the box when the main switch is OFF. Click on Test alarm to test the mower’s speaker. The alarm is heard for a few seconds when the speaker is working and it then switches off automatically. Automower from ™...
  • Page 73 In the Active collision sensors box you should now see None, Left, Right or Both. This is also shown in the picture to the right of the screen. Continue to press on the body until you see that both sensors work. Automower from ™...
  • Page 74 The X-angle indicates a front – rear inclination and the Y-angle a left – right inclination. When Automower stands on a perfectly flat surface, 3012-567 the values should be about +/-3. Otherwise the tilt sensor needs to be calibrated.
  • Page 75 Point to a value or a heading and the relative field and loop are shown in the picture at the bottom of the screen. Below the column with values it is stated whether the mower is standing with the front loop sensor Inside loop or Outside loop. Automower from ™...
  • Page 76 When the Default value for the S-signal next to the guide wire: Automower is directly over the loop the value is 0 about (-) 250 – 320. and when the mower is outside of the loop the F-signal: Remote signal that helps the Automower value is negative.
  • Page 77 4. Autocheck, Service program 4.8.3 Operating history Operating history is an ideal function to use when you wish to see how well an Automower has worked. The function is divided into three parts: Operating data, Operating data, Trip and Fault memory.
  • Page 78 The Copy all data to new control box function is used when the control box on an Automower needs to be replaced. All settings and complete operating history in the mower can, by using this function, be saved to...
  • Page 79 Search times indicates partly an average value of how long each search for the charging station has taken, partly a maximum value that indicates how long the longest search took. The last 20 search times are shown in the list. 3012-573 Automower from ™...
  • Page 80 If the value for Chargings OK, see page 30, is to remain an indicator of the battery's total age, Trip Op. counters should only be reset when replacing the battery. Automower from ™...
  • Page 81 Click on the Table, latest button to revert to the list with the last 100 faults. All occurring faults saved in the fault memory can be deleted: Click on Clear Fault memory. Click Yes when asked Clear fault memory list? Automower from ™...
  • Page 82 Automower. 3012-576 The latest program can be downloaded from the Automower support site. This requires Internet access. Click on Get mower program from support site to download. After downloading, information about which program has been installed on your computer is shown.
  • Page 83 If you still receive the message No contact: Perform the following actions, one at a time. If you do not receive any contact with the mower, continue with the next action. Automower from ™...
  • Page 84 Garden, Security, Sound levels, Startup settings and Miscellaneous. This function can be used to collect all information concerning the settings in the Automower connected to the computer. You can also change these settings and then transmit the changes to the mower.
  • Page 85 Set time. To change Timer settings: Enter the required start and stop times or click on Reset. Click on Present or the appropriate Program button in the Change program box to save the settings in the mower. Automower from ™...
  • Page 86 You can state values between 0% and 100% for Proportion first. The value 0% means that the mower will always leave the charging station in exit sector 2. The value 100% means the mower will always leave the charging station in exit sector 1. 3012-511 Automower from ™...
  • Page 87 3012-581 Garden: Follow loop in Under the In tab you set the delay in minutes from when the Automower starts to search for the charging station until it should follow the boundary wire and/or the guide wire. The default delay times are 11 minutes for boundary wire and 7 minutes for guide wire.
  • Page 88 For example, the values 20% for Area 1 and 10% for Area 2 mean that Automower on 20% of all occasions leaves the charging station in the direction of Area 1 and in 10% towards Area 2. For...
  • Page 89 Code validity time and Alarm time. Code validity time means that after this number of days Automower stops and will not work again until 3012-585 the correct PIN code is entered. The number of minutes for Alarm time denotes how long the alarm will sound when tripped.
  • Page 90 Here you can read and, if you like, change the sound levels selected on the connected mower. The operating sounds indicate what Automower is currently doing. These can be activate or deactivated. Different sound levels can be set for the keypad.
  • Page 91 You can use different settings in the different programs. If the time and date stated in each box is incorrect, you can not change this in this function. You need to use the function Clock/Timer, see page 85. 3012-587 Automower from ™...
  • Page 92 Customer settings. 3012-588 Settings: Square mode cutting When an Automower rarely seems to perform square mode cutting or performs it too often, and the other actions have not helped (see 1.6 Square mode cutting on page 9), the problem may be rectified by...
  • Page 93 Click on Present in the Change program box. Settings: Demo mode In order to make it easier to demonstrate an Automower it is equipped with a demo mode. You can use different settings in the different programs for Demo mode.
  • Page 94 In the Compare function you can compare two entries to see the differences. For example, whether the same mower has been saved on two different occasions. Automower from ™...
  • Page 95 You can search for saved mowers by sorting them according to serial number or customer. You can find the mower you are interested in from the list and then click on Show selected entry. The selected mower is marked in the list in bold. 3012-736 Automower from ™...
  • Page 96 Save changes to add information to a previously saved entry. C. Operating history D. Operating history, trip E. Fault memory Search times G. Settings: Clock/Timer and Garden H. Settings: Security, Sound Levels, Startup settings and Miscellaneous. Latest Auto test Automower from ™...
  • Page 97 Excel. This file can also be printed. When you click on Open with Excel, you will be prompted whether to accept macros: Check the box Always accept macros from Husqvarna and then click Yes. Automower from...
  • Page 98 Now click on >Entry #1. Now select the entry you wish to compare and click on >Entry #2. You select the information you wish to compare by clicking on the tabs General, Settings or Operating history. 3012-741 Automower from ™...
  • Page 99 Documents from 2003 are available. The page also includes a link to the Automower support site and the consumer site. On the support site you can download the latest versions of Autocheck, the mower program and documentation.
  • Page 100 4.8.8 Se Service plan is a function to print a checklist of actions when servicing an Automower. Data about the connected mower’s production date, program version, running time and serial number are shown when you open this function. Click on Print service plan to print out a service plan with pre-printed data about the connected mower.

  • Page 101: Repair Instructions

    5. Repair instructions 5. Repair instructions All repairs to the Automower from Husqvarna™ should be made indoors on a clean work bench to protect sensitive components from moisture and dirt. IMPORTANT INFORMATION Oil, grease and dirt on electrical contactors can cause intermittent faults on the Automower.

  • Page 102: Dismantling And Assembling The Automower

    5. Repair instructions 5.1 Dismantling and assembling the Automower IMPORTANT INFORMATION Clean any grass and dirt from the Automower before you begin dismantling. 5.1.1 Dismantling the body The body is screwed to the chassis with four screws, hex 4. Tip! Only loosen the rear screws two turns, so that the rear part of the body is not loosened.

  • Page 103: Dismantling The Charging Station

    Remove the connector for the contact strip, the connector for the charging plate and the connector for the guide wire if fitted, from the circuit card. Unscrew the two screws, torx 20, holding the front on the tower. Lift off the front. 3012-337 Automower from ™...

  • Page 104: Replacing The Circuit Card, Charging Station

    Remove the plate’s cable through the hole in the tower. Fit the tower on the new plate. When connecting the plates cable to the circuit card: Ensure the cable’s rubber grommet is seated correctly in the hole in the tower. Assembling the charging station. Automower from ™...

  • Page 105: Replacing The Contact Strips, Charging Station

    When the mower’s battery does not recharge this may be due to worn contact strips in the charging station. Inspect the contact strips and charging strips on the Automower. The contact strips should be replaced when blackened. Also clean the charging strips on the Automower.

  • Page 106: Replacing The Lower Section Cable Harness

    5. Repair instructions 5.6 Replacing the lower section cable harness The lower section cable harness on the Automower runs from the control box connection to the components: A. Rear loop sensor. (white) B. Service connector. (white) C. Speaker. (white) D. Right wheel motor.(yellow)

  • Page 107: Replacing The Upper Section Cable Harness

    5. Repair instructions 5.7 Replacing the upper section cable harness Upper section cable harness in the Automower connects the control box with: Display circuit board. Left collision sensor. Right collision sensor. Lift sensor. 3012-706 To change the cabling: Dismantle the body and chassis.

  • Page 108: Replacing The Control Box

    A new start-up sequence starts when the main switch is turned to the ON position after replacing the control box, provided that the data on the old control box has not been transferred to the new via Autocheck first. Automower from ™...

  • Page 109: Replacing The Display

    If the cable is connected 3012-315 incorrectly, the buttons will not correspond with the menu functions. Check that the display works. Screw on the display cover. Assemble the body. Automower from ™...

  • Page 110: Replacing The Keypad

    Unscrew the two screws, torx 20, holding the speaker. Lift out the old speaker and replace with a new speaker. Refit the screws and connect the cable. Check that the speaker works. Fit the chassis and body. 3012-446 Automower from ™...

  • Page 111: Replacing The Main Switch

    Connect the new micro switch to the display circuit card. Make sure the switch’s rubber seal is fitted correctly on the display cover. Screw on the display cover. Check that the microswitch and stop button work. Assemble the body. Automower from ™...

  • Page 112: Replacing The Battery

    Battery type: CR 2025 3V. Dismantle the body and chassis. Remove the old battery from its holder on the control box. 3012-343 Insert the new battery, with + side facing upwards. Fit the chassis and body. Automower from ™...

  • Page 113: Replacing The Sensors

    If a mower that is fitted with white collision sensors (mowers produced from 2003 or 2004) changes to black collision sensors (mowers produced from 2005 and onwards) the settings must be changed. This is done in Autocheck under the menu Tools-Machine version. Automower from ™...

  • Page 114: Replacing The Blade Motor

    2). Unscrew the four screws, torx 20, holding the blade motor. Turn the Automower and open the cover for the cutting height adjustment. Place your fingers under the edge of the wheel for the cutting height adjustment and lift off the wheel.

  • Page 115: Replacing The Wheel Motor

    Replace the wheel. Make sure they are fitted to the right axle. Replace the hub. It is not necessary to apply new thread locking fluid. The screws can be reused about 5 – 10 times. 10. Check that the wheel motor works. Automower from ™...

  • Page 116: Tightening Torques

    535 12 11-01 Screw 535 13 03-14 Tightened Upper section crosswise. (Torx-20) IMPORTANT INFORMATION Check that upper and lower sections are assembled cor- rectly, that there is no dirt in between and that no cables are pinched. Automower from ™...
  • Page 117 Charging 535 25 33-01 station, Complete Body, 535 12 43-02 Screw 535 13 03-14 Charging (Torx-20) station Circuit card, 544 00 13-01 Screw 535 13 03-10 Complete (Torx-20) Cover 535 12 44-01 Screw 535 13 03-14 (Torx-20) Automower from ™...

  • Page 118: Trouble Shooting

    6. Trouble shooting 6. Trouble shooting When an Automower from Husqvarna™ does not work correctly, first take the following actions before continuing with trouble shooting: Update the mower program in Automower to the latest edition. Many problems are solved directly by the new mower program, see Table 2: Version of the mower program on page 8.
  • Page 119 10 seconds and then reconnect the power cord in the wall socket again. The connection between the Automower Place the Automower in the charging station and and the charging station has been lost. state the PIN-code again via Settings- Security - PIN code (shortcut 4-1-1).
  • Page 120 Trapped The Automower has become caught in Free the Automower and rectify the reason for it something. becoming trapped. Both, or one of, the rear screws on the Lift the body from the rear section and feel whether it body has not been tightened correctly.
  • Page 121 The charging plate (F-coil) is defective. Check the F-signal from the charging station: Place the Automower in the test position and then check the value via the Quick check function (Press and hold the 0 key down for 2 seconds). The F-coil is defective if the value for F is lower than 300.
  • Page 122 The charging plate (N-coil) is defective. Check the N-signal from the charging station: Place the Automower in the test position and then check the value via the Quick check function (Press and hold the 0 key down for 2 seconds). The N-coil is defective if the value for N is lower than 100.
  • Page 123 Table 11: Fault messages Fault message Cause Action Left wheel motor blocked The Automower has jammed. Remove the object. Right wheel motor blocked Grass or other object may have become Check the drive wheel and remove the grass or other wrapped around the drive wheel.

  • Page 124: Fault Symptom, General

    The charging plate (N-coil) is defective. Check the N-signal from the charging station: Place the F-field, but does not the Automower in the test position and then check interpret the N-signal. the value via the Quick check function (Press and hold the 0 key down for 2 seconds).

  • Page 125: Fault Symptom, Loop System

    The corridor width is too high for Reduce the corridor width successively until through a narrow opening Automower to pass through the Automower can pass through the passage. In order or passage when passage. to prevent Automower from running on a small...
  • Page 126 Action system Automower does not run The set delay time does not permit Check that the set delay time to permit Automower to along the boundary wire Automower to start following the start following the boundary wire has elapsed. To...
  • Page 127 When Automower is set to follow the boundary wire or the guide wire with the help of the Test IN function...
  • Page 128 (-) 195 – 264 246 – 283 (-) 191 – 260 242 – 279 (-) 187 – 242 238 – 276 (-) 183 – 223 234 – 275 (-) 179 – 216 230 – 274 (-) 175 – 209 Automower from ™...

  • Page 129: Maintenance And Service

    Check for play on the skid plate. There should be no play on the plate so that it touches the blades’ screw heads. 7.2 Winter storage Before the Automower is put away for the winter the following should be done: • Clean the entire mower thoroughly.

  • Page 130: Service Schedule

    7.3 Service schedule The table below contains a checklist of points and actions to be taken when servicing the Automower. When faults or a need of cleaning are discovered, this must be rectified before the mower is used again.
  • Page 131 23 and mower program. page 82 Make an Auto test of all page 67 components. Check on site that docking and page 18 charging work correct. Perform a battery check page 20 Automower from ™...
  • Page 132 7. Maintenance and service Automower from ™...
  • Page 133 Automower from ™...
  • Page 134 Automower from ™...
  • Page 136 The Automower is protected by several patents. EP 0 550 473 EP 1 025 472 US 6.300.737 EP 1058 958 EP 1 302 147 US 6.525.509 US 6.586.908 SE 511 254 US 6.465.982 Automower is a trademark of the Electrolux Group. 115 01 71-26 2006W01...
