2. SPECIFICATIONS

2.1. Power Supply Specifications

When using the LAN, the power supply ratings and accuracies are the same as for the digital remote programm
ing using RS-232 or RS-485. See the Technical Manual for Genesys™ Power Supply for those specifications.

2.2. LAN Specifications

ELECTRICAL
Ethernet Meets IEEE 802.3u specifications
Auto-MDIX Accepts patch or cross-over cable connection
Auto-Negotiate Selects fastest of 10Base-T or 100Base-T networks (10 or 100 Megabits per second)
NETWORK CONFIGURATION
MAC Address TDK-Lambda assigned:
IP Address View or set (with restrictions) from front panel
DHCP
Get address from network server. Leasing services
Auto-IP Create own IP address:
Static IP
Any IP fixed by operator
Hostname NetBIOS, ARP and rARP protocols. Operator settable name
Duplicate IP Detection Reject duplicate setting or disconnect from network
Subnet Mask Mask set by DHCP or static
Default Gateway
Address set by DHCP or static
DNS Server Address set by DHCP
LAN Reset
Reset configuration from front panel or SCPI command
LAN PROTOCOLS
TCP
LAN packets follow Transmission Control Protocol
IPv4 Internet Protocol version 4
Instrument Protocols
VXI-11 Supports Core channel, not Abort or Interrupt channels
VISA VXI-11 compliant, uses RPC and Portmapper, SCPI cmds
TCP Sockets Send SCPI commands to port 8003
UDP Sockets Send SCPI commands to port 8005
VXI-11 Discovery Find connected instruments
SNMP Ping Server Verify LAN connection to instrument
HTTP Web page server with Java scripts and applets
COMMANDS
SCPI
SCPI 1999 compliant command, measure and status
IEEE-488.2 Condition and event register tree
Serial Pass-Through
Send native RS-232 commands with abilities beyond SCPI
WEB PAGES
Multiple users
Multiple web pages can be open at once
Identity Identify power supply model, serial number, revision etc.
LAN
Configuration View and set LAN configuration
Active Control GUI Program and read output settings
Send Commands
Send SCPI commands, read errors
Help Link to TDK-Lambda web sites
00:19:f9:xx:xx:xx
169.254.xx.xx
